15" CRT
JH 15C06 CTX - 15 inch Industrial Monitor
Created : 13 Jul, 2001
Modifi ed : 18 Jan, 2002
Title
Subject
Description: Internet release for customers.
Jakob Hatteland Display AS
Åmsosen, N-5578 Nedre Vats, Norway
Phone: +47 5276 3700, Fax: +47 5276 5444
Jakob Hatteland Display AS
Created by: Stein Eikesdal
: IND100036-1
: JH15C06CTX-UserManual
www.hatteland.com
CONT
BRIGHT
Rev.2

Advertisement

Table of Contents
loading

Summary of Contents for Hatteland JH 15C06 CTX

  • Page 1 15” CRT CONT BRIGHT JH 15C06 CTX - 15 inch Industrial Monitor Jakob Hatteland Display AS Created : 13 Jul, 2001 Modifi ed : 18 Jan, 2002 Created by: Stein Eikesdal Title : IND100036-1 Subject : JH15C06CTX-UserManual Description: Internet release for customers.

  • Page 2: Table Of Contents

    The monitor is tested according to the maritime standard EN60945 (IEC945). CONT BRIGHT JH 15C06 CTX - 15 inch Industrial Monitor CONTENTS: OPERATION......................3 Power switch, Monitor Adjustment Controls............3 USER CONTROLS PANEL..................4 User Controls, Select Function Buttons / Adjust Buttons........

  • Page 3: Operation

    OPERATION Product: JH 15C06 CTX Power Light Indicator Power Switch Contrast Knob Brightness Knob Degauss Button POWER SWITCH: Power ON: To turn the monitor on, press the power switch in the upper area marked “1” The power light indicator (Power LED)will turn green.

  • Page 4: User Controls Panel

    USER CONTROLS PANEL Product: JH 15C06 CTX Power Led Adjust Adjust Buttons MENU Select Function Buttons USER CONTROLS: The On Screen Manager (OSD Menu) controls are located under the metal hatch on the left side of the monitor. To begin understanding the menu and its usage, just follow these steps for a quick start.

  • Page 5: Osd Menu Usage

    OSD MENU USAGE Product: JH 15C06 CTX STATUS MENU: (Sub-Menu) This sub-menu displays the technical information, such as the current video mode resolution, horizontal and vertical frequency. RECALL Press the “+” button to recall the factory preset for position, size and geometry.

  • Page 6: Horizontal Size, Vertical Size, Trapezoid, Pincushion, Parallel, Rotation

    OSD MENU USAGE Product: JH 15C06 CTX SIZE MENU: (Sub-Menu) This sub-menu will enable the user to adjust Horizontal Size and Vertical Size of the display area. HORIZONTAL SIZE Expand the display area left or right. Decrease or increase by using “-” or “+” buttons.

  • Page 7: Color Balance, Language

    OSD MENU USAGE Product: JH 15C06 CTX COLOR MENU: (Sub-Menu) This sub-menu will enable the user to adjust the Red, Green and Blue saturation (RGB) of the picture. Mode 1 and 2 are fi xed factory preset and can not be modifed. Mode 3 is user adjustable.

  • Page 8: Physical Connections

    PHYSICAL CONNECTIONS Product: JH 15C06 CTX Rear side of monitor Power Terminal Touch screen (opt) Signal cable POWER TERMINAL Make sure the monitor is turned off before connecting. Insert the powercable into the 220 VDC power terminal. You may secure the cable further by mounting it to the base mounted cable tie clamp.

  • Page 9: Pin Assignments

    PIN ASSIGNMENTS Product: JH 15C06 CTX VGA D-SUB 15P CONNECTOR FEMALE: 15 14 13 Pin Number: Description: red video green video blue video ground no connection red return green return blue return no connection ground ground bi-directional data (SDA) horizontal sync. (or H/V) vertical sync.

  • Page 10: Troubleshooting

    TROUBLESHOOTING Product: JH 15C06 CTX COMMON ERRORS: If for some reason there should be something wrong with the picture quality or no picture present, check the symptoms carefully and try to cure it with the hints below: NO PICTURE / LED BEHAVIOUR: Power Switch and computer power switch should be in the ON position.

  • Page 11: Preset Signal Table

    PRESET SIGNAL TABLE Product: JH 15C06 CTX PRESET SIGNAL TIMING TABLE: Microprocessor-based preset functions stores geometry settings. The following industrial standard settings have been pre-programmed by the factory. Resolution Vert. Frequency(Hz) Horiz. Frequency(Hz) Video Mode • 720 x 400 31.50 •...

  • Page 12: Notes

    NOTES Product: JH 15C06 CTX Product: JH 15C06 CTX...

  • Page 13: Specifications

    SPECIFICATIONS Product: JH 15C06 CTX CRT characteristics: Environmental Considerations: CRT size : 15” / 381 mm Operating: Temperature -15 deg. C to +55 deg. C Viewable image size : 13.8” / 350 mm Humidity 30% to 93% (non condensing) Deflection : 90 deg.
