Summary of Contents for Diamond Multimedia GC1000
-
Page 2: Table Of Contents
GC1000 HD Gaming Capture Box Installation Manual Contents V1.0 Chapter 1: GC1000 HD Gaming Capture Box Hardware Installation ............... 1 1.1 Package Contents ........................... 1 1.2 System Requirements ........................1 1.3 Hardware Installation ........................1 Chapter 2: HD Gaming Capture Box Quick Installation ................... 3 2.1 The Driver Installation of HD Gaming Capture Box .............. -
Page 3: Chapter 1: Gc1000 Hd Gaming Capture Box Hardware Installation
3. Connect the HDMI cable from your gaming console or any other device supporting HDMI and the other end to the HDMI labled IN on the GC1000. Connect a second HDMI cable from the HDMI out of the GC1000 to the HDMI input on your televsion. Make sure you select the correct source input on your television. - Page 4 Connect the yellow video cable to the green input labled Component (Y) IN on the GC1000. Connect the red and white audio cables to the audio input of the GC1000. Using a second composite cable (not included) from the GC1000, connect the yellow video cable from the Component green coded (Y) out from the GC1000 to your television.
-
Page 5: Chapter 2: Hd Gaming Capture Box Quick Installation
Chapter 2: HD Gaming Capture Box Quick Installation The GC1000 HD Gaming Capture Box package comes with complete Windows software utilities. These utilities can be found on the DVD-ROM in this package. During installation, it is highly recommended to disable any sub-programs. These include applications such as antivirus software and system monitoring applications. -
Page 6: The Driver Installation Of Hd Gaming Capture Box
Now the driver has been installed successfully on your computer and click “OK” to finish driver installation and go to next step. 2.2 Diamond Video Capture Application Installation The InstallShield Wizard will guide you through installation of DMCap application. Click “Next”... - Page 7 Click “Finish” Select yes and then “Finish”to restart your computer. 10. Open the DMCap Video Capture Program by double clicking the icon on your desktop.
- Page 8 11. Leave the default HD Capture Device setting and click “Next” 12. For North American standards leave the default selection and click next. 13. For HDMI connections select HDMI and then Exit. For Composite (Yellow, Red and White Connections choose Composite and then exit. For Component YPbPr (Red, Green and Blue) choose YPbPr.
- Page 9 4.volume up 5. volume down 6. volume mute 7. video playback 8. video source input 9. setup For Video Editing and Burning please install the CyberLink Power Director Program. Note: Power Director does not support direct capture from the GC1000.
-
Page 10: Chapter 3 : Faq
Ans：Click on “Start” on the left-down desktop and choose “Setting”. Once in “Control Panel” window, click on “Add or Remove Programs”. Click on the plus icon of “Change or Remove Programs” then choose “Diamond Video Capture GC1000 Driver” to remove the device drivers Fig.2... - Page 11 Technical Support Diamond Technical Support staff is here to help resolve any issues that you may be experiencing with the installation of the Diamond product. Prior to contacting technical support please make sure you have the following information available. 1. Model #: (Printed on the bar code, located on the box) 2.
- Page 12 Diamond product are warranted to be free from defects in materials or workmanship under normal use and service for a period of for (90) ninety days from date of purchase at retail. Diamond ’s sole obligation under this warranty shall be, at Diamond ’s option, to: (i) repair the defective product or part;...
- Page 13 ARISING OUT OF OR IN CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION OF ITS PRODUCTS, EVEN IF DIAMOND, ITS SUPPLIERS OR ITS RESELLER HAS BEEN ADVISED OF THE POSSIBLITY OF SUCH DAMAGES. DIAMOND ’S SOLE LIABILITY WITH RESPECT TO ITS PRODUCT IS LIMITED TO REPAIR OR REPLACEMENT OF THE PRODUCT, AT DIAMOND ’S OPTION.
