- Page 1 2 channel mixer User Manual...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use the apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8. - Page 3 IMPORTANT SAFETY INSTRUCTIONS 17. All warnings on the appliance and in the operating instructions should be adhered to. 18. Heat - The appliance should be situated away from heat sources such as radiators, heat registers, stoves, or other appliances (including amplifiers) that produce heat. 19 .Power Sources - This product should be operated only from the type of power source indicated on the rating label.
-
Page 4: Product Features
2-band equalizer for microphone Talk over for microphone Long life replaceable crossfader with 2 curve Setting Crossfader Start compatible with VOXOA CD/MP3 Player High quality channel fader with reversible function Crossfader style cueing control Dual 10 LED monitor display (selectable PGM 1/2 or Master output) -
Page 5: Part Names And Functions
PART NAMES AND FUNCTIONS OPERATION PANEL... - Page 6 PART NAMES AND FUNCTIONS 1. Source input selector switch These switches are used to select the input source assigned to each channel. Each channel may only be assigned one input source at a time. 2. PGM/Master switch The position of this switch will determine the level meter mode. In the “Master” position, the meter will detail the out level of the left and right channels.
- Page 7 PART NAMES AND FUNCTIONS 11. Channel fader (CF) mode switch Reverses the direction of Channels fader. 12. Crossfader curve switch Used to select the 2 different rising curve patterns for the crossfader function. 13. MIC ON/OFF/TALKOVER switch To set mic on and off, when switch at the talkover position, the mic on, the sound level for everything other than mic will decrease to around 14 dB.
-
Page 8: Rear Panel
PART NAMES AND FUNCTIONS REAR PANEL 30 29 28 27 26 28 27 21. Power switch Turn this unit power ON/OFF. CAUTION : Before you turn the power on be sure you have made all connections to the mixer. Also be sure you amplifiers are turned off. -
Page 9: Front Panel
PART NAMES AND FUNCTIONS 27. Ph/Line input jacks The type of input must directly reflect the selected mode of the SOURCE SELECT SWITCH . Turntables equipped with MM pickup cartridge (All DJ turntable use MM pickup cartridges) may be connected to these jacks as long as the SOURCE SELECT SWITCH(1) is in the left side “PH/LN”... - Page 10 Microphone(s) and monitor headphones. Make sure all faders are at “zero” and the unit is off. Take care to connect only one cable at a time. Pay attention to L and R position of jacks, on both the VOXOA M10 and outboard gear.
- Page 11 CONNECTIONS Turntable Turntable Microphone 3.5mm Power Amplifier Recorder CD/MP3 Player CD/MP3 Player Headphones...
-
Page 12: Specifications
SPECIFICATIONS 1.GENERAL SECTION POWER SOURCE : DC 6V, 2000mA POWER CONSUMPTION : 12 Watts DIMENSIONS : 235 (W) x287 (D) x 106.4 (H)mm Weight : 1.65 kg 235 mm 2. INPUT/OUTPUT IMPEDANCE & SENSITIVITY : (MASTER 0dBV OUTPUT, LOAD=100KOHM, MAX. GAIN, EQ FLAT) LINE : 10K OHM /-14dBV (200mV) +/-2dB PHONO :... - Page 13 SPECIFICATIONS 6. MAXIMUM OUTPUT : (THD=1%, MAXIMUM GAIN, EQ FLAT) MASTER : MORE THAN +18dBV (8.0V) at load=100K OHM PHONES : MORE THAN +4dBV (1.6V) at load=32 OHM REC : MASTER MAX OUTPUT -10+/- 2dB. at load=100K OHM 7. SN RATIO : (MAXIMUM GAIN, MASTER 0dBV OUTPUT, EQ FLAT, W/ 20KHz LPF, A-WEIGHTED) LINE : LESS THAN -80dBV PHONO :...
- Page 14 VERSION 1.0 Printed in China...
