Summary of Contents for Dolphin Net Base
- Page 1 ® Dolphin Net Base Four-Slot Communication Cradle for the ® Dolphin 7900 Mobile Computer ® Dolphin 9500 Mobile Computer ™ ® Dolphin 9900 Mobile Computer Quick Start Guide...
-
Page 3: Unpacking The Net Base
Base. If any items are missing or anything appears to be damaged, contact your Customer Account Representative. Keep the original packaging in case you need to return the Net Base for service or store the Net Base while not in use. -
Page 4: Hardware Overview
Dock LED COMM LED Dock LED Lights solid green when the terminal is properly seated. The terminal can communicate with the Net Base only when properly seated in the well. COMM LED Indicates the status of data transfer between the Dolphin terminal and the Net Base. -
Page 5: Power Supply
4. Plug the power cord into a standard wall outlet. 5. Plug the CAT-5 Ethernet cable into either of the RJ-45 connectors on the back of the Net Base. 6. Plug the Ethernet cable into the network. 7. On the power adapter, turn the ON/OFF switch to the ON position. -
Page 6: Connecting The Dolphin Terminal To The Net Base
Navigation bar. 4. Upon connection, the Dolphin terminal is assigned an IP address from the Net Base, which can be used by any application on the Dolphin terminal. 5. When you exit RASMan or remove the terminal from the Net Base, the terminal plays a sound and the disconnected icon appears in the Navigation bar. -
Page 7: Configuring The Network
3. Power up and wait until the COMM LEDs stop flashing. The COMM LEDs stop flashing when the Net Base has found the DHCP server. 4. On your workstation, open the web browser and enter the Net Base serial number exactly as it appears on the label. - Page 8 4. Enter the user name <handheld> and default login password <handheld> to log into Net Base configuration utility. The Net Base menu program displays. SD00032Login: handheld Password: ******** 1) View System Configuration 2) View Current Values 3) Express Setup 4) Advanced Setup...
- Page 9 Configuring the Net Base with a Static IP Address 1. Connect the serial cable to the Serial DB-9 Connector on the back of the Net Base and a COM port on the host computer. Do NOT connect to the network at this time.
-
Page 10: Accessing The Net Base Through A Browser
IP address, you can access the Net Base through your internet browser. 1. Open your internet browser. 2. In the Address line, type the IP address assigned to the Net Base and press ENTER. 3. The login screen appears showing the Current Values. - Page 11 Link Bar Link Click this link to … Current Values Display the current values; this is the default screen. Statistics Display the following system statistics: • Iface - The type of interface • Docked - Charging status • Connect - Status of an active PPP session •...
-
Page 12: Mounting Options
1/2 in. OD x 7/32 in. ID x 3/64 in. thick Nut: 3/16 in. dia 1. Slide the DIN Rail into the slot on the bottom panel. 2. Turn the Net Base and DIN Rail right side up. 3. Secure the DIN Rail to the horizontal mounting surface. -
Page 13: Using The Wall Mount Kit
Hardware (see page 1-11). 2. On each end of the Net Base, insert a screw into the round end of each of the four screw slots on the bottom panel. Then, slide each screw towards the narrow end of the slot until it snaps in place. -
Page 14: Online Technical Assistance
Technical Assistance If you need assistance installing or troubleshooting your device, please call your distributor or the nearest technical support office: North America/Canada Telephone: (800) 782-4263 Fax number: (315) 554-6705 E-mail: natechsupport@honeywell.com Latin America Telephone: (803) 835-8000 Telephone: (800) 782-4263 E-mail: latechsupport@honeywell.com Brazil Telephone: +55 (21) 3535-9100... -
Page 15: Online Product Service And Repair Assistance
Product Service and Repair Honeywell International Inc. provides service for all its products through service centers throughout the world. To obtain warranty or non-warranty service, contact the appropriate location below to obtain a Return Material Authorization number (RMA #) before returning the product. North America Telephone: (800) 782-4263 Fax: (803) 835-8012... -
Page 16: Limited Warranty
Limited Warranty Honeywell International Inc. ("HII") warrants its products to be free from defects in materials and workmanship and to conform to HII’s published specifications applicable to the products purchased at the time of shipment. This warranty does not cover any HII product which is (i) improperly installed or used; (ii) damaged by accident or negligence, including failure to follow the proper maintenance, service, and cleaning schedule;... -
Page 17: How To Extend Your Warranty
Honeywell International Inc. extends these warranties only to users of the products. These warranties are non-transferable. The duration of the limited warranty for the Dolphin Net Base is one year. How to Extend Your Warranty Honeywell International Inc. offers a variety of service plans on our hardware products. - Page 19 ©2005–2008 Honeywell International Inc. All rights reserved. Web Address: www.honeywell.com/aidc Trademarks Dolphin, Dolphin RF, HomeBase, Mobile Base, and QuadCharger are trademarks or registered trademarks of Hand Held Products, Inc. or Honeywell International Inc. Microsoft, Windows, Windows Mobile, Windows CE, Windows NT,...
- Page 20 Honeywell International Inc. 700 Visions Drive P.O. Box 208 Skaneateles Falls, NY 13153-0208 NETBASEALL-QS Rev B 10/30/08...
