RTS KrimpVark User Manual

Super long standby and high-definition audio
Hide thumbs
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KrimpVark and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RTS KrimpVark

Summary of Contents for RTS KrimpVark

  • Page 2 RTS Help Line Dear client should you experience any difficulties or problems on your RTS Product (s) please feel free to contact our office at 086100 2525 Weekdays between 08H00 and 17H00 We will gladly assist you with your purchased...

  • Page 3: Table Of Contents

    CONTENTS Introduction………………………………………1 Unpacking and check devices……………………2 Accessory List……………………………………2 Main Features……………………………………3 Technical information……………………………4 Identification………………………………………6 Preparation for Using……………………………7 PC Software Programming Setting………………12 Operation Guide…………………………………13 Maintenance………………………………………17 Troubleshooting…………………………………19 Appendix: CTCSS QT and DCS DQT Chart ……22...

  • Page 4: Introduction

    Krimpvark is developed for wide using. It offers you a normal communication when you are in the rural area, forest zone, pasturing area or sea area. The fine appearance of Krimpvark meets your needs of personality - 1 -...

  • Page 5: Unpacking And Check Devices

    Unpacking and check the devices Please take the radio out carefully from the package, and check again before disposing of the packing to make sure that all the following items are contained in the packaging. If any of them are missing or damaged during transportation, please contact with the vendor for service.

  • Page 6: Main Features

    Main Feature 1、400--470MHz full frequency 2、Chinese and English channel report 3、High and low power optional 4、wide and narrow band optional 5、CTCSS/50 and DCS/83 squelch system to avoid the disturbance from other radio station. 6 、 VOX function ,free your hands ， easy operation 7、BCL（busy channel lock）function to know the busy state...

  • Page 7: Technical Information

    1． Emergency alarm function gives you more peace. 2． Rime elimination function will eliminate the noise when stop talking. Technical Information GENERAL Frequency range 400MHz-470MHz Number of channel Channel spacing 12.5kHz / 25kHz Modulation method －10℃ --- ＋ Operating temperature range 55℃...
  • Page 8 TRANSMITTER ≤5ppm Frequency stabilization ≤3.5W Output power ≤1.3A Emission current Maximum frequency deviation ±5kHz Audio distortion <10% Adjacent channel power <70dB Residual radiation <-60dB RECEIVER Reference sensitivity <-122dBm (12dB SINAD) Sensitivity lock <-126dBm ≥500mW Audio Power ≤300mA Receiving current Audio distortion <10% ≥60dB Adjacent channel selection...

  • Page 9: Identification

    Identification - 6 -...
  • Page 10 1. Pendent hole 2.Belt Clip Stator 3. Indicated Light 4. Antenna 5 .Volume Knob 6. Channel Knob; 7. Belt Clip; 8. PTT 9. Earphone Jack 10. FM Radio/Monitor/Reception+ 11. Speaker 12. Call/Reception- 13. MIC 14. Charging Contact Plate 15. USB Charging Jack 16. Antenna Terminal - 7 -...

  • Page 11: Preparation For Using

    Preparation before Using Install Lithium battery pack Install the battery rear case properly as following pictures show Picture1 picture2 Install battery rear case Install the battery rear case properly as following pictures show Picture1 picture2 picture3 Fix the belt clip fix the belt clip properly as the following pictures show: - 8 -...
  • Page 12 Picture1 picture2 picture3 Take off the Belt Clip Press the belt clip stator (as arrow shows) as following picture 1 shows, push up the belt clip as the arrow of picture 2 shows, then take off the belt clip as picture 3 shows. Picture1 picture2 picture3...
  • Page 13 Install the Antenna Rotate the antenna clockwise into the antenna terminal as the arrow of picture 1 shows, and then tighten the antenna as picture 2 shows. Picture1 picture2 Charging the Lithium Battery Pack The battery pack is without completely charging when finished, and please charge it before using.
  • Page 14 Green light shines when start charging, red light is on while it is charging and the green light indicate that the charging is finished. Note ： KRIMPVARK has two independent charging channels for the whole machine and battery pack, but it cannot charge by the two way at the same time, otherwise it will be failed charge.

  • Page 15: Pc Software Programming Setting

    Software programming setting PC programming method 1．Please visit http://www.repeater.co.za and download the Krimpvark programming software. Operation Guide Transmit 1．Hold 【PTT】after the red light is on to talk and lose the button to stop. Monitor 1． Short-press 【Radio/Monitor/Reception+】 按 to open noise in force and press it again to exit.
  • Page 16 【Radio/Monitor/Reception+】to exit. FM-radio function operation 1．Press 【Radio/Monitor/Reception+】功 in 2s when heard ”di” to open FM-radio. Press 【Radio/Monitor/Reception+】or 【Call/Reception- 】 to scan automatically, and it will stop when coming to the radio which has signals. For other radio station, please press 【Radio/Monitor/Reception+】or 【Call/Reception-】...
  • Page 17 until rotate the channel selector to your desired channel. The green indicated light will flash if you didn’t rotate the channel selector after operating the Emergency Call Function. Low Power Detection 1. The device works properly, when the voltage is higher than 3.6V; 2.

  • Page 18: Maintenance

    Maintenance Transceiver KRIMPVARK you purchased is an exactitude design electronic products and please use it carefully. Following maintenance ways may help extend its lifetime. 1、lease don’t try to disassemble the transceiver because non-technicians’ processing may cause damage to the device.
  • Page 19 distortion to plastic parts.。 5、Please keep the transceiver dry, because rain and moisture will erode the electronic circuits. 6、Please power off the transceiver and remove its battery pack immediately once there is peculiar smell or smog emit from the device. - 16 -...

  • Page 20: Troubleshooting

    Troubleshooting Trouble Solution The battery pack has been exhausted. Please change a new No reaction battery or recharge the battery. when The battery pack may be not power-on installed correctly. Please install it again. Please check the frequency and CTCSS/DCS you use are Unable to the same as other members use talk with...
  • Page 21 Other (not Change the frequency from group Please change your members) CTCSS/DCS NO. And it has to sound heard change all signal sound of the in channels. group transceivers. The battery The use-life of the battery is used out soon over, please change new battery.
  • Page 22 Appendix：CTCSS and DCS list 50 CTCSS 67.0 85.4 107.2 136.5 165.5 186.2 210.7 254.1 69.3 88.5 110.9 141.3 167.9 189.9 218.1 71.9 91.5 114.8 146.2 171.3 192.8 225.7 74.4 94.8 118.8 151.4 173.8 196.6 229.1 77.0 97.4 123.0 156.7 177.3 199.5 233.6 79.7 100.0 127.3 159.8 179.9 203.5 241.8 82.5 103.5 131.8 162.2 183.5 206.5 250.3 83 DCS...
  • Page 23 RTS HULPLYN Geagte klient indien u enige probleme ondervind, skakel gerus die volgende telefoon nommer: 086100 2525 Tussen 08H00 en 17H00 weeksdae Ons sal u met graagte te hulp wees U radio is soos volg geprogrammeer Kanaal 1-8 op CTCSS 94.8 Hz...
  • Page 24 Inleiding…………………………………………1 Nagaan van verpakking………………………2 Bybehorelys……………………………………2 Hoofkenmerke…………………………………3 Tegniese informasie…………………………4 Identifikasie……………………………………6 Hoe om te gebruik………………………………7 Rekenaar sagteware ……………..…………11 Versorging…………….………………………15 Probleem Oplossing…………………………17 Bylaag: CTCSS QT en DCS DQT Tabel ……19...

  • Page 25: Inleiding

    Inleiding Dankie vir die aankopp van RTS Krimvark aankoop lisensievrye produk. Lees asseblief hierdie boekie sorgvuldig deur en bestudeer die funksies en hoe om die radio te gebruik voordat u dit gebruik. Hierdie klein kompakte tweerigtingradio is stabiel, maklik om te gebruik, en is ontwikkel vir verskeie gebruikers areas, bv.

  • Page 26: Nagaan Van Verpakking

    1 NAGAAN VAN VERPAKKING Verwyder radiotoerusting versigting uit die verpakking. Maak seker dat hierdie toerusting en bybehore in die verpakking is. Behou u verpakking vir waarborg doeleindes. In daar enige van Indien onderstaande item(s) weg is, beskadig is as gevolg van vervoer, kontak u handelaar sonder versuim.

  • Page 27: Hoofkenmerke

    Hoofkenmerke 1、Wye band 400--470MHz 2、Engels kanaal aankondiging 3、Hoog en lae krag uitset verstelling 4、Wye of nou bandwydte 5、CTCSS/50 en DCS/83 squelch sisteem om mede kanaal gebruikers te voorkom of onnodige steurnisse. 6、Handvrye stem beheerde uitsending. 7、Besige kanaal transmissie uitsluiting. 8、Skandeer funsie, skandeer alle kanale 9、Ingeboude FM radio, luister na u gunsteling nuusstasie.

  • Page 28: Tegniese Informasie

    Tegniese Informasie Algemeen Frekwensie band 400MHz-470MHz Aantal kanele Kanaalwydte 12.5kHz / 25kHz Modulasie metode Gebruik temperatuur --- ＋55 －10 Spanning 3.7V---4.2V Bystand kragverbruik omtrent 10mA Grote 95(H) × 53(W) × 30(D)mm Gewig omtrent 135g TRANSMITTER Frekwensie stabiliteit ≤5ppm Uitsetkrag ≤2 W Transmit kragverbruik ≤1.3A Maksimum deviasie...
  • Page 29 ONTVANGER Ontvangersensitiwiteit <-122dBm (12dB SINAD) Sensitiwiteit oopmaak <-126dBm Audio klank ≥500mW Ontvanger kragverbruik ≤300mA Audio verwronging <10% Sykanaal selektiwiteit ≥60dB Intermodulasie verwerping ≥60dB - 5 -...

  • Page 30: Identifikasie

    Identifikasie - 6 -...
  • Page 31 1. Hanger gaaitjie 2.Beltknip 3. Indikasie liggie 4. Antenna 5 .Volumeknop 6. Kanaalknop 7. Beltknip 8. PTT 9. Oorfoon punt 10. FM Radio/Monitor/Ontvangs+ 11. Luidspreker 12. Roep/Ontvangs- 13. Mikrofoon 14. Laai kontak Punt 15. USB Laaiprop 16. Antenna Terminaal - 7 -...

  • Page 32: Hoe Om Te Gebruik

    HOE OM TE GEBRUIK Installeer Lithium batterypak Installeer die battery agter in die radio, volg die sketse noukerig Skets1 Skets2 Installeer battery klappie Installeer die batteryklappie deeglik soos hierbo aangewys. Installeer beltknip Skuif beltknip in plek soos hieronder aangedui. - 8 -...
  • Page 33 Om beltknip te verwyder Druk beltknip pennetjie soos in skets 1. Druk nou die beltknip in die rigting van die pyltjie soos in skets 2, verwyder nou beltknip soos in skets 3. Skets 1 Skets 2 Skets 3 - 9 -...
  • Page 34 Installeer die Antenna Skroef die antenna kloksgewys soos in skets 1 in die antenna terminal, wees versigtig om antenna nie oordraad te draai nie, voltooi antenna installasie soos in skets 22 Skets 1 Skets 2 - 10 -...

  • Page 35: Rekenaar Sagteware

    Laai van Lithium Batterypak Die batterypak is by vervaardiging nie volledig gelaai nie, laai batterypak nou. Laai kontakpunte Indikasie liggie Skets 2 Skets 1 - 11 -...
  • Page 36 Programmering van Sagteware Om rekenaar programmering sagteware te bekom besoek gerus http://www.repeater.co.za，en laai die Krimvark sagteware af. Gebruikaanwysings Transmit 1．Druk die uitsaaiknoppie 【PTT】 nadat die rooi indikasie liggie begin brand, praat dan, sodra u klaar gepraa,t het los die uitsaaiknoppie. Monitor 1．...
  • Page 37 1750KHz uitsaai terwyl u die 【Radio/Monitor/Ontvangs+】inhou. FM-radio aaanskakeling 1．Druk 【Radio/Monitor/Ontvangs+】knoppie in vir 2sekondes totdat u ”di” klank hoor, nou is die FM-radio aangeskakel 2. Druk【Radio/Monitor/Ontvangs+】of 【Roep/Ontvangs- 】 om outomaties te soek vir ‘n FM radiostasie, indien u na ‘n ander radiostasie wil soek druk 【Radio/Monitor/Ontvangs+】of 【Roep/Ontvangs-】...
  • Page 38 luidspreker hoor. Druk die【PTT】om alarm te kanselleer. Die radio sal op kanaal 01 bly totdat u die kanaal selekteerde knoppie draai. Die Groen indikasie ligie sal flikker tot en met u die kanaal verander. Lae Battery Indikasie 1． Die radio funksioneer normaalweg wanneer die battery spanning bokant 3.6V is;...

  • Page 39: Versorging

    Versorging Krimpvark tweerigting radio wat u aangekoop ‘n elektroniese apparaat. Volg onderstaande versorging om sodoende die lewe van u toerusting te verleng. 1. Moet asseblief nie prober om die radio produk oop te maak nie, aangesien daar binne-in geen versienbare onderdele is nie.
  • Page 40 5、 Hou die tweerigtingradio droog, want reen en water kan die elektroniese stroombane beskadig. 6、 Skakel die tweerigtingradio onmiddellik af indien daar rook of reuke uit die radio kom. - 16 -...

  • Page 41: Probleem Oplossing

    Probleem oplossing Probleem Oplossing Geen reaksie Die batterypak is pap. Vervang wanneer of herlaai batterypak. radio Die batteypak is moontlik nie aangeskakel behoorlik ge-installeer nie. word nie. Herinstalleer die batterypak. Maak seker dat u radio met die ander radio se kanaal verstellings Kan nie met dieselfde is.
  • Page 42 Maak seker dat die mikrofoon onvang u radio gaaitjie oop is. sag of gebroke Haal die battery dadelik uit. Maak droog onder ‘n waaier. Stuur radio so Radio vol water gou as moontlik na RTS toe vir herstelwerk. - 18 -...

  • Page 43: Bylaag: Ctcss Qt En Dcs Dqt Tabel

    Aanhangsel：CTCSS en DCS Lys 50 CTCSS 67.0 85.4 107.2 136.5 165.5 186.2 210.7 254.1 69.3 88.5 110.9 141.3 167.9 189.9 218.1 71.9 91.5 114.8 146.2 171.3 192.8 225.7 74.4 94.8 118.8 151.4 173.8 196.6 229.1 77.0 97.4 123.0 156.7 177.3 199.5 233.6 79.7 100.0 127.3 159.8 179.9 203.5 241.8 82.5 103.5 131.8 162.2 183.5 206.5 250.3 83 DCS...
