PRESENTER CONTROL COMPACT
ORDERCODE 100802

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Presenter Control Compact and is the answer not in the manual?

Questions and answers

Summary of Contents for DMT Presenter Control Compact

  • Page 1 PRESENTER CONTROL COMPACT ORDERCODE 100802...
  • Page 2 For more information: iwant@dutchmediatools.info You can get some of the best quality, best priced products on the market from DMT. So next time, turn to DMT for more great lighting equipment. Always get the best -- with DMT ! Thank you!
  • Page 3: Table Of Contents

    DMT Presenter Control Compact Product Guide ™ Warning..…...................…………………………………………....Safety-instructions…………………………………………………………………………………………....Operating Determinations……………………………………………………………………………...... Description..…................……….…………………………………....Features…….……………………………………………………………………………………….……...…....Overview………………………………………………………………………………………………………....Backside………………………………………………………………………………………………………....Installation................…...…………………………………….…....System set up..............................Software installation............................Running the set up program..........................Serial port control............................... Requirements for the RS232 code........................Example 1..............................Example 2..............................Infrared remote control.............................
  • Page 4: Warning

    If your DMT device fails to work properly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your DMT dealer for service.
  • Page 5: Operating Determinations

    Repairs, servicing and electric connection must be carried out by a qualified technician. WARRANTY: Till one year after date of purchase. CAUTION ! EYEDAMAGES !. Avoid looking directly into the light source. (meant especially for epileptics) ! OPERATING DETERMINATIONS If this device is operated in any other way, than the one described in this manual, the product may suffer damages and the warranty becomes void.
  • Page 6: Description

    Description of the device Features The Presenter Control Compact has a small size, compact appearance, many functions and it is easy to operate. It is therefore ideally suited to be used in conference rooms, multimedia rooms, college or classrooms. One button click.
  • Page 7: Overview

    Overview Fig. 2 1) PC2 VGA Input. Connect with VGA out terminal of PC 2. 2) PC2 Audio Input. Connect with audio out terminal of (external)PC 2 device. 3) Video 2 Audio Input. Connect with audio out terminal of (external)Video 2 device. 4) Video 2 Video Input.
  • Page 8: Backside

    Backside Fig. 3 S-video Input. Connect with S-video Out terminal of the S-video device. 16) S-video/YCbCr Audio Input. Connect with the Audio Out terminal of S-Video/YCbCr device. Video 1 Video Input. Connect with Video Out terminal of the Video 1 device. 18) Video 1 audio Input.
  • Page 9: Installation

    Installation Remove all packing materials from the Presenter Control Compact. Check that all foam and plastic padding is removed. Connect all cables. Host Terminals and Connection Diagram. Fig. 4...
  • Page 10: System Setup

    The computer will start searching for the Presenter Control Compact and the window shown in Figure 5 will appear. Fig. 5 If the computer fails to find the Presenter Control Compact, the window shown in Figure 6 will appear. Fig. 6...
  • Page 11 If the connection is set up properly, the setup program will start the main interface (Figure 7). Fig. 7 First check if your projector is listed in the Existing projector list, if so please select the desired projector and click the icon “programming”. Now the setup program will transmit the right RS232 code to the Host. If your projector is not in the list, you have to program the control protocol yourself, using the projectors information.
  • Page 12: Serial Port Control

    Serial port Control If your projector is controlled by a serial port, please select “the Serial Port” button. Next you have to define Baudrate, Data Bit, Verification Mode, Power-on command, Power-down command, Projection VGA command, Projection Video Command etc. First select “USER-DEFINED PROJECTOR”. Now the window shown in Figure 8 on the next page will appear. Fig.
  • Page 13: Requirements For The Rs232 Code

    Requirements for the RS232 code. Use hexadecimal digits only. Please transform other codes to the Hexadecimal format. The symbol “\” is necessary for separating the Hex-digits. Special characters have to be transferred into Hexadecimal digits also. Use a ascII table (also see appendix 3) for special characters.
  • Page 14: Example 2

    Example 2 Power-on command of the projector is POWR___1 (Enter) (_ signifies space)Then in the command field should contain: \50\4f\57\52\20\20\20\31\0d (upper/lower case is insensitive). Infrared remote control If it is impossible to obtain the Control Code of a projector, but the projector can be controlled by infrared Control, please select the “Infrared Remote Control”...
  • Page 15 Fig. 11 The system shall pickup the infrared code of the projector via infrared receiving window on the control panel of the host. The computer shall process the infrared code and send out the infrared signal to the infrared receiving window of the projector through infrared wire. You can observe the action of the projector to verify the correctness of the infrared code.
  • Page 16 Fig. 13 After successful sampling of the infrared code, a pop up window shall appear and ask you to confirm. If the infrared cable is properly connected please check the projectors action. If ok, then confirm. If not ok, press “No” and start all over again. Possible causes for problems during infrared learning mode: Check the connections of the learning cable.
  • Page 17 Saving the setup. Please save the data for future maintenance or transform the data to those Hosts which have parallel configuration. See Figure 14. Fig.14 Sending the program to the Host. Connect the programming cable, check if connected properly and click the “programming” button. Now the data will be send to the host.
  • Page 18: Maintenance

    Maintenance Showtec Scanmaster 3 requires almost no maintenance. However, you should keep the unit clean. Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in liquid. Do not use alcohol or solvents. Keep connections clean.
  • Page 19: Product Specifications

    Product specification Inputs/ Outputs: PC2 VGA input PC2 Audio input Video 2 video input Video 2 audio input MIC input PC1 VGA input PC1 audio input VIDEO 1 video input VIDEO 1 audio input S-VIDEO video input S-video audio input (YCbCr input optional) VGA output Video output...
  • Page 20: Appendix 1: Pcc Block Diagram

    Appendix 1: PCC Block Diagram.
  • Page 21: Appendix 2: Pin Definition Of Programming Cable And Infrared Learning Cable

    Appendix 2: Pin definition of programming cable and Infrared learning cable. Pin definition of programming cable. Infrared learning cable.
  • Page 22: Appendix 3: Ascii Table

    Appendix 3: ASCII-table...
