Summary of Contents for Davis Instruments Envoy8X

  • Page 1 GETTING STARTED GUIDE Envoy8X ™ 'DYLV ,QVWUXPHQWV  'LDEOR $YHQXH +D\ZDUG &$  86$ ‡  ‡ ZZZGDYLVQHWFRP...
  • Page 2 • Consult the dealer or an experienced radio/TV technician for help. Changes or modification not expressly approved in writing by Davis Instruments may void the warranty and void the user's authority to operate this equipment. FCC ID: IR2DWW6312...

  • Page 3: Package Contents

    Before installing the software on your PC, make sure your package includes the following items: • Envoy8X • Two #6 x 1” screws for wall mounting • Weather Data Transfer Utility for Envoy8X software CD • AC Adapter System Requirements Envoy8X requires the following: ®...

  • Page 4: Data Logger Requirements

    “Inside” data. If you do not want the “inside” temperature to be from this sensor, such as when the Envoy8X is housed in an outside shelter, you may add either the Stainless Steel Temperature Probe with RJ Connector (6475), or the Temperature Probe with RJ Connector (plastic housing, 6477).
  • Page 5 Temperature) when you configure the Envoy8X. If any transmitting station is going through a repeater or repeaters, you will also need the Repeater ID (A-H) of the last repeater before the Envoy8X. List your transmitters and repeaters to refer to during setup of your Envoy8X.
  • Page 6 Install the Data Logger Installing the data logger (supplied with WeatherLink) is the first step in preparing the Envoy8X to transmit data to the software. CAUTION: Plugging or unplugging the data logger while power is applied to the Envoy8X can lock up or damage the logger. The WeatherLink data logger must be installed before you install the batteries or plug in the AC power adapter.
  • Page 7 Data Logger Cable Channel Cable Channel Inserting the Serial or USB data logger into the Envoy8X 3. Rejoin the case halves, making sure the data logger cable passes through the cable channel. 4. Fasten using the three screws you removed in step 1.

  • Page 8: To Replace The Batteries

    Note: Before installing batteries and/or AC adapter, make sure the data logger is already installed. If replacing batteries, see below. 1. Remove the battery cover on the back of the Envoy8X case by pressing on the arrow embossed on the cover and sliding the cover away from the case.

  • Page 9: Connecting Ac Power

    Connecting AC Power The operating battery power for Envoy8X is up to 5 months, depend- ing on the number of transmitters being received. Envoy8X is sup- plied with an optional AC power adapter that can be used as an addtional power source.
  • Page 10 Mount Your Envoy8X You can place your Envoy8X on your desktop, install it on a wall near your computer, or install it with the optional Multi-Purpose Shelter (7728). Here are some guidelines for placing your Envoy8X. Envoy8X Location Place the Envoy8X in a location where it is easily accessible and can be easily connected to a computer.
  • Page 11 Envoy8X. 2. Use the template as a guideline for the hole markings on the wall where you want to mount the Envoy8X, and use a pencil to mark the location for the two mounting screws. The screws should be 3.25 (82.5...

  • Page 12: Local Computer Installation

    Locate a free USB port on your computer and connect the USB connector of the 8’ cable to the port, and connect the Mini-B connector to the data logger. The connection between the Envoy8X and the computer can be extended up to 16' (5 m) by replacing the cable with a Mini-B-to-USB connector cable.

  • Page 13: Serial Port Connection

    Note: The data logger does not require a constant connection with a computer to continue logging and storing data. Although the data logger should remain connected to the Envoy8X at all times, the data logger only needs to be con- nected to the computer when data is being downloaded or when the com- puter is actively using data from the data logger.

  • Page 14: Software Installation And Setup

    Here are some basic considerations for selecting your database: • MS Access is included with Envoy8X software and requires no additional purchase or setup to use. Access is the easiest to use and is recommended for single-user installations.
  • Page 15 Note: Selecting the Everyone button is usually the best choice for ease of use. 6. Installation is completed. Click Finish to exit the Setup. You should see the Weather Data Transfer Utility for Envoy8X icon on your desktop and also in the Start - All Programs menu.

  • Page 16: Using Your Software

    Using Your Software The first time you use the software, you will set up the database and add your Envoy8X, and configure the transmitting stations. You should refer to the copious Help files for instructions on each of these steps.
  • Page 17 Envoy 8x. It should be only used to import data from the DTU software and to plot and graph this imported data. Do not attempt to use WeatherLink to communicate with the Envoy8X. The Weather Data Transfer Utility for Envoy8X software must be used to communicate with the Envoy 8X. WeatherLink®...
