AC UNISON SOLAR POWER SYSTEM

INSTALLATION GUIDE

Please carefully read these installation instructions.
This document is available on our web site
http://solar.auo.com/?sn=784&lang=en-US&c=238
Thank you for choosing AUO.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AC UNISON and is the answer not in the manual?

Questions and answers

Summary of Contents for AUO AC UNISON

  • Page 1: Installation Guide

    AC UNISON SOLAR POWER SYSTEM INSTALLATION GUIDE Please carefully read these installation instructions. This document is available on our web site http://solar.auo.com/?sn=784&lang=en-US&c=238 Thank you for choosing AUO.

  • Page 2: Table Of Contents

    2. AC Module Planning and Preparation……………………………………….…………….4 2.1 ACPV System Design and Layout…………………………….………………...5 2.2 Accessory Plan and Part Number……………………………………………….12 2.3 Accessory Plan and Part Number…………………………………….………...14 3. AC Unison Module System Installation……………………………………………………15 3.1 AC Cable Termination…………………………………..……………………..15 3.2 AC Cable Management………………...…………………………………………15 3.3 Accessory Plan and Part Number……………………...……………….……..16 AUO AC Unison Module Map……………………….………………….……..17...

  • Page 3: Overview-Ac Module Installation Components

    AUO AC Unison 1. Overview -AC Module Installation Components AUO AC Unison Solar Power System -the following diagram illustrates the major component layout for a typical residential Photovoltaic(PV) system installation. AUO AC Unison PV modules –our AC modules AUO Data Logger(DL) –our data acquisition system(DAS) PV Distribution Panel –dedicated...
  • Page 4 More flexible installation • Higher availability (no single point of failure) • Reduced design costs -no string design consideration nor limitations • Scalable – can add modules over time [AUO AC Unison Installation Guide] [Page 3 of 44] [February 2012 Rev. 1.0]...

  • Page 5: Ac Module Planning And Preparation

    AUO AC Unison 2.0 AC Module Planning and Preparation The critical components of an AC Unison Module: AUO AC Module 2 MCR Bracket 1-1 DC-to-AC micro-inverter (field installed) 1-2 Module Junction Box 3 M3 Screw 1-3 Mid-Cable Receptacle 4 M5 Screw...

  • Page 6: Acpv System Design And Layout

    AUO AC Unison 2.1 ACPV System Design and Layout Please see below several of our common module layout examples and ‘best practice’. [AUO AC Unison Installation Guide] [Page 5 of 44] [February 2012 Rev. 1.0]...
  • Page 7 AUO AC Unison [AUO AC Unison Installation Guide] [Page 6 of 44] [February 2012 Rev. 1.0]...
  • Page 8 A single branch circuit (maximum of 17 AC Unison modules per branch circuit) will terminate with a transition cable or an extension cable that could be routed toward an electrical work box on the roof or another set of AC Unison modules on another part of the roof.
  • Page 9 Installer must ensure that the cable does not touch the roof. Examples are shown below: [AUO AC Unison Installation Guide] [Page 8 of 44]...
  • Page 10 AUO AC Unison [AUO AC Unison Installation Guide] [Page 9 of 44] [February 2012 Rev. 1.0]...
  • Page 11 AUO AC Unison [AUO AC Unison Installation Guide] [Page 10 of 44] [February 2012 Rev. 1.0]...
  • Page 12 AUO AC Unison [AUO AC Unison Installation Guide] [Page 11 of 44] [February 2012 Rev. 1.0]...

  • Page 13: Accessory Plan And Part Number

    Available in 5' and 10' lengths. Interconnecting cable plugs on both ends. Extension Cable 20A, exterior-rated 4-wire (L1, L2, N, and Ground) cable. (Male-Male) Available in 5' and 10' lengths. [AUO AC Unison Installation Guide] [Page 12 of 44] [February 2012 Rev. 1.0]...
  • Page 14 20A, exterior-rated 4-wire (L1, L2, N, and Ground) cable. (Female-Female) Available in 5' and 10' lengths. Center disconnect pin is inserted into interconnecting plugs, Disconnect Tool receptacles, and mid-cable receptacles to safely disconnect components. [AUO AC Unison Installation Guide] [Page 13 of 44] [February 2012 Rev. 1.0]...

  • Page 15: Accessory Plan And Part Number

    SS MCR bracket with two M3 screws (provided). Torque to 20 inch-pound. It is best to complete steps 1 and Step 2 on the ground prior to installing the AC Unison modules. Step 2 First and last module considerations...

  • Page 16: Ac Unison Module System Installation

    Firmly press male AC cable into rigid female MCR AC receptacle 3.2 AC Cable Management The following diagram shows a system of three AC Unison modules. The AC cables are secured to the module frames with stainless steel Cable Clips at the recommended locations below.

  • Page 17: Accessory Plan And Part Number

    Please remove serial number(SN) sticker located on the Mid-Cable Receptacle of each AC Unison Module and place it on the AUO AC Unison Map. Your Module Map will provide necessary module layout information during the final step of creating your...

  • Page 18: Auo Ac Unison Module Map

    AUO AC Unison AUO AC Unison Module Map Installer Name ________________________ AUO Module(Wp) ________________ Project Name _________________________ No. of Modules _________________ Project Location State____ Zip Code __________ PV System Size _________________ Date of Installation _________________________ Data Logger SN _________________ Cir_A...

  • Page 19: Data Logger Installation And Setup

    AC Unison modules. The Data Logger retrieves module level production data at 5 minute intervals and then forwards the aggregated data to the AUO Solar Web portal at 15 minute intervals. Our data logger is NEMA 3R rate and suitable for outdoor applications.
  • Page 20 *For best results please hardwire the Data Logger to the PV Distribution Panel. Please do not ground or bond the Data Logger [AUO AC Unison Installation Guide] [Page 19 of 44] [February 2012 Rev. 1.0]...
  • Page 21 Once the initialization process has completed, the LCD displays the shown “HOME SCREEN”. Step 7 AC Unison Module Discovery Navigate the Data Logger’s menu by pressing the next menu and to enter/select. Please enter the “Setup”...
  • Page 22 ‘Communication’ menu returning to the ‘Home Screen’. ‘COMM’ should now be displayed on the Home Screen, indicating a reliable network connection. [Module Count] [Today’s Power Generation] [Internet Handshake] [AUO AC Unison Installation Guide] [Page 21 of 44] [February 2012 Rev. 1.0]...

  • Page 23: Auo Solar Web Portal Account Creation

    4.1 Creating your Installer or Company Account If this is your first time using AUO Solar Web Portal, your first step is to register a New Installer account. Your authorized AUO Distributor or Dealer will provide your installer or company account registration code.

  • Page 24: Creating Your New Customer Account

    4.3 Creating your New Customer Account Step 1 Create Profile -Select the Create Profile tab, enter the details of the AC Unison PV system installation. Be certain to Save each step in the process before you proceed to next step in this 3 step process...
  • Page 25 All Systems tab. This system will remain Locked until the system owner logs in to the AUO Solar Web Portal and activates their new account. [AUO AC Unison Installation Guide] [Page 24 of 44] [February 2012 Rev.

  • Page 26: Notice And Safety Instructions

    This section contains important information and instructions to safely install an array of alternating current photovoltaic solar modules (AC Unison module) and the Data Logger. Failure to follow these instructions can result in equipment damage or failure, or personal injury, and may void the system warranty, and/or property damage.
  • Page 27 Some authorities having jurisdiction (AHJ) may require a separate disconnect next to the AC Unison module system as well as a readily accessible disconnect. The AC cables and connectors are listed for outdoor use with AC Unison module applications and are rated for 20A, and with insulation rated to a maximum temperature of 90°C.
  • Page 28 Do not expose the AC Unison module to excessive loads on the surface of the AC Unison module or twist the frame. The glass may break. Do not stand or step on the AC Unison module. The glass may be slippery, and there is a risk of injury or electric shock if glass is broken.
  • Page 29 Always wear protective head gear, insulating gloves and safety shoes (with rubber soles). Due to the risk of electrical shock, do not perform any work if the terminals of the AC Unison module are wet. Do not wear metallic jewelry which may conduct electricity and enable electric shock during installation.
  • Page 30 NOTE: Proper grounding of the AC Unison module system will ensure full warranty coverage. Although highly recommended, the installation of auxiliary lightning protection systems / components is not specifically tied to the AC Unison module’s warranty. The conductor used for lightning protection from the structure to the grounding electrode system must not be run inside the same conduit that contains the EGC and AC circuit conductors.
  • Page 31 IEC 60417-5172 symbol for double insulated equipment (CLASS II) which does not require a protective earthing (equipment grounding conductor) as a means of providing protection against electric shock. [AUO AC Unison Installation Guide] [Page 30 of 44] [February 2012 Rev. 1.0]...

  • Page 32: Additional Information On Ac Module Planning & Preparation

    6.0 Additional Information on AC Module Planning & Preparation For the purpose of this document, a circuit is defined as one to seventeen AC Unison modules connected in parallel to a dedicated 20A branch circuit. An array refers to the entire installation of one or more strings connected to the structure’s AC service equipment.

  • Page 33: Pv System Attachment Mounting Considerations

    PV modules should be tilted so that the energy production from the PV modules will be maximized on an annual basis. The tilt angle of the PV module is measured between the surface of the PV module and a horizontal ground surface. AUO PV modules produce the most power when the sun’s rays strike the module perpendicular to the module surface.
  • Page 34 D5(mm) PM250M00.0_XXX 1651 PM250M00.0_XXX 1651 1300 Note: XXX = 240 . 245 . 250 . 255 . 260 . The mechanical loading claimed value is 50 lb/ft2. [AUO AC Unison Installation Guide] [Page 33 of 44] [February 2012 Rev. 1.0]...

  • Page 35: Micro-Inverter Specifications

    (NEC) and the current rating of the micro-inverter. If more micro-inverters than this number need to be installed, additional 20-A branches shall be used, keeping the number of micro-inverters on each branch less or equal to this number. [AUO AC Unison Installation Guide] [Page 34 of 44]...

  • Page 36: Data Logger

    The AUO Data Logger is a gateway device that uses Power Line Communications (PLC) to collect status and performance data from AC Unison modules. Using broadband Internet, the Data Logger then forwards the collected data to the Solar Monitoring System at five minute intervals. When necessary, the Data Logger automatically downloads and installs enhancements, which can include defect fixes, to the software on the Data Logger or, on rare occasions, to the firmware on the micro-inverter.

  • Page 37: Data Logger Preparation

    Solar Monitoring System, the Data Logger must be connected to a 10/100Base-T network router using an Ethernet cable. When connected to the Internet, the Data Logger periodically uploads site- and module-level data to the AUO Solar Monitoring System. If a network or DHCP is not available, the Data Logger uses its default IP address, 192.168.100.1.

  • Page 38: Lcd Display Menu Tree

    ) on the EXIT screen returns you to the first menu item in the current topic menu. Pressing the checkmark button ( ) on the EXIT screen returns to the topic menu. [AUO AC Unison Installation Guide] [Page 37 of 44] [February 2012 Rev. 1.0]...
  • Page 39 AUO AC Unison [AUO AC Unison Installation Guide] [Page 38 of 44] [February 2012 Rev. 1.0]...
  • Page 40 Number of discovered modules. Total amount of power generated by all modules at the time of the last data reading. COMM = Connected to AUO Solar Monitoring System, NOCOMM = Not connected to AUO Solar Monitoring System. Information about the Data Logger.
  • Page 41 Press to view information about this module. The remainder of this table shows the information available for each module. [AUO AC Unison Installation Guide] [Page 40 of 44] [February 2012 Rev. 1.0]...
  • Page 42 Displays the frequency of the electric grid at the time of the last data reading. Displays the voltage of the electric grid at the time of the last data reading. [AUO AC Unison Installation Guide] [Page 41 of 44] [February 2012 Rev. 1.0]...
  • Page 43 Displays the date and time that data from the modules was last transmitted to the monitoring system. Scrolls through the menus. Exits the communication information screens and returns to Communications. [AUO AC Unison Installation Guide] [Page 42 of 44] [February 2012 Rev. 1.0]...
  • Page 44 AUO AC Unison Setup Menu The submenu in this menu enables you to discover newly installed AC Unison modules. Menu Description Press to begin discovering modules. An interim screen displays the discovery progress and returns the next screen. Press to move to the EXIT screen.
