Summary of Contents for Security Ranger III
- Page 1 SECURITY SECURITY Ranger III & Ranger III MS High Per formance, Long-Range Thermal Security Cameras...
- Page 2 The Ranger III has three optical configurations to choose from: the LR 50x250mm, the XR 100x500mm, and the XR+ 150x750mm. Security operators can field the Ranger III as a portable stand-alone camera, or integrate it into a suite of plug-and-play sensors.
- Page 3 The combination of these sensors allows operators to precisely geo-locate objects of interest, and display their position as an overlay on a digital map. It is even possible to integrate Ranger III MS with radar systems to automatically direct the camera, and provide visual target assessment of the radar signature.
- Page 4 Maximum Range The FLIR Ranger III comes with a choice of three long-range telescopes: 50x250mm, 100x500 and 150x750mm. In addition to their 5:1 optical zoom ratio, both models have 2:1 & 4:1 digital zoom, giving you the ability to reach out to targets far beyond the capability of any other thermal security camera in its class.
- Page 5 FLIR Systems is uniquely capable of these complex tasks, as we design and manufacture all of the critical components in the imaging system: detector – cooler – video processing - lenses. FLIR designed the Ranger III from the ground up so that all of its critical components work together towards one goal: making Ranger III the best long-range thermal security camera around.
- Page 6 FoR THERMaL IMagIng Thermal security cameras compliment and complete your existing security network – you won’t believe what you haven’t been seeing border security Thermal security cameras cover more territory with greater detail than any other sensor suite available. Networkable video and control make the Ranger III the perfect border security imaging solution. Perimeter security Airports, hydropower generation, refineries, chemical plants, and other large facilities have perimeters that can encompass miles of real estate.
- Page 7 The image on the right has DDE on. 5:1 optical Zoom Each model of Ranger III offers 5:1 zoom, plus 2:1 and 4:1 e-zoom for a combination of situational awareness and outstanding range – night and day, in good weather and bad.
- Page 8 JUnCTIon PRoToC0L ConvERTER FoR RangER III MS ConnECTIvITY Taking networkability to a whole new level analog and digital connections The Ranger III MS thermal security camera comes ready for video and control over IP, as well as traditional remote control with RS-232, -485 and the Nexus software suite. Power 28VDC input.
-
Page 9: About Flir Systems
US. This ensures fast maintenance and support. volume production FLIR thermal security cameras are mass-produced and can be found in a variety of applications including automotive vision enhancement, fire fighting and aviation. Our volume production allows us to extend lower prices to our customers. -
Page 10: System Overview
Pixel Pitch 15μm Spectral Range 3.4 - 5.0μm Field of View Range: Ranger III LR 11.0° x 8.2° to 2.2° x 1.6° Field of View Range: Ranger III XR 5.5° x 4.1° to 1.1° x 0.8° Field of View Range: Ranger III XR 3.6°... -
Page 11: Optional Accessories
Interfaces Command and control RS-232/-422, PelcoD STandaRd EQUIPMEnT Ranger III thermal security camera, power supply, controller, breakout box, cables, Ranger III LR, XR, & XR+ Operator’s Manual, shipping case. Thermal imaging camera, daylight camera, Pan/Tilt, Joystick, power supply with Multi-Sensor Package cables, Operator’s Manual, shipping cases. - Page 12 FLIR Systems, Inc. CVS World Headquarters FLIR SYSTEMS, INC. 70 Castilian Dr. Goleta, CA 93117 PH: + 1 877 773 3547 PH: + 1 805 964 9797 FX: + 1 805 685 2711 sales@flir.com EURoPE CVS Eurasian Headquarters FLIR SYSTEMS CVS BV Charles Petitweg 21 4847 NW Teteringen - Breda Netherlands PH: +31 (0) 765 79 41 94...
