Operating Instructions
Tumble dryer
ISE CD60W
Dear ISE customer,
Thank you for choosing this quality product from Scandinavia,
which was made in Sweden.
We want you to feel assured that the inside of your new ma-
chine is just as good as the outside and that the ethics and
standards that went into the production of this machine are
just as high as the quality and performance that you will re-
ceive from it. We hope that this product will give you many
years of pleasure.
To ensure that you get the most out of your new machine, we
recommend that you read the operating instructions before
using the machine. The operating instructions also contain
information on how to avoid damaging the environment.
Advertisement
Table of Contents
Related Manuals for ISE CD60W
Summary of Contents for ISE CD60W
-
Page 1: Operating Instructions
Operating Instructions Tumble dryer ISE CD60W Dear ISE customer, Thank you for choosing this quality product from Scandinavia, which was made in Sweden. We want you to feel assured that the inside of your new ma- chine is just as good as the outside and that the ethics and... -
Page 2: Table Of Contents
Contents Before using your machine for Troubleshooting the first time The machine will not start Do not tumble-dry Overheating cut-out Safety instructions Drying takes too long General The washing does not dry, or is Installation too dry Safety Error messages Interrupting a programme Technical information Transport/Winter storage... -
Page 3: Before Using Your Machine For The First Time
Before using your machine for the first time Do not tumble-dry Certain materials are not suitable for tumble- drying. Always check and follow the instruc- tions on each item's laundry label. You can find more information in the chapter "Advice and tips before you tumble-dry". -
Page 4: Safety Instructions
Safety instructions General Installation • Read the operating instructions and keep See the “Installation” chapter. them in a safe place! • Electrical installation, if required, should Safety be carried out by a qualified electrician. • The machine must not be used for drying •... -
Page 5: Recycling
Safety instructions Recycling This machine is manufactured and labelled for recycling. In order to prevent injuries, the machine must be made unusable once the decision has been taken to dispose of it. Contact your local authority for information about where and how your machine can be recycled correctly. -
Page 6: Child Safety
Child safety General Do not allow children to play with the tumble dryer. The tumble dryer does not start automatically when the door closes (e.g. if a child closes the door from inside). The tumble dryer has a magnetic catch, which allows the door to be opened from the inside. -
Page 7: Description Of The Tumble Dryer
Description of the tumble dryer Panel Outer door Condensed water container Fan (behind hatch) Type plate Condenser (behind the front plate) Lint filter holder Lint filter... -
Page 8: Front Panel
Front panel Main power switch Options buttons Programme selector Display Start/Stop Options button Button for selecting Low Temperature Button for selecting Anti crease Button for selecting Delayed Start 1-24h... -
Page 9: Advice And Tips Before You Tumble-Dry
Advice and tips before you tumble-dry Here are some tips that may help you before Materials that must not be you begin tumble-drying. tumble-dried Have the clothes been spun? This symbol means that the material is not Items to be tumble-dried should be spun at suitable for tumble-drying. -
Page 10: Tumble Drying
Tumble drying Below are step-by-step instructions to help Dry and Normal dry you achieve the best possible tumble-drying These programmes shut off the heat once the results. load is dry but before it is "bone-dry". The Dry programme shuts off the heat slightly later Sort your fabrics than Normal dry. - Page 11 Tumble drying Menu overview Programme chart For the consumption values given below, the requirements are as follows: Temperature of intake air: 20°C Moisture content of intake air: 65 % Drying temperature: Normal or low Heater output: 2500W Before tumble-drying, cotton fabrics should be spun at 800 and 1600 rpm (long spin). Before tumble-drying, other fabrics (crease-resistant and acrylic) should be spun at 800 rpm (short spin).
-
Page 12: Selecting Options
Tumble drying Delayed Start Selecting Options When you select Delayed Start, the machine By selecting options, you can tailor dry- will start 1-24 hours after you press the ing programmes to suit your own laun- Start/Stop button. dry requirements. The machine remembers •... -
Page 13: Press The Start Button
Tumble drying Press the Start button Drying programme finished The text "END" appears on the display Remaining drying time when the programme is finished. If the An estimate of the remaining drying time Anti-crease option has been selected, the will be shown on the display within 2 minutes drum will rotate every minute for 2 hours after of the drying programme starting. -
Page 14: Once Drying Has Finished
Tumble drying Emptying the condensed water container The condensed water container must be drained after each load. Remove the con- densed water container, empty out the water and replace the container. If the condensed water container becomes too full, the pro- gramme is interrupted and F1 appears on the display. -
Page 15: Care And Cleaning
Care and cleaning Cleaning the lint filter Emptying the condensed water container The lint filter must be cleaned after each load. If you have very hard water, this can cause limescale deposits in the lint filter. Check for any limescale deposits when cleaning the lint filter and, if necessary, wash the filter by hand. -
Page 16: Cleaning The Condenser
Care and cleaning 5. Replace the condenser. When refitting the Cleaning the condenser condenser, check that it is replaced cor- The condenser should be cleaned at least rectly. The top of the condenser is labelled three times a year. If you have pets, the con- "upp", "up"... -
Page 17: Troubleshooting
Troubleshooting The machine will not start Drying takes too long • Empty the condensed water container and Check check that neither the lint filter nor the • that the door is properly closed. condenser are clogged. See the chapter • that the main power switch is on. "Care and cleaning". -
Page 18: Technical Information
Technical information Technical data Height: 850mm Width: 595mm Depth: 585mm Weight: 47kg Cylinder volume: 111 l Max. drying capacity: Speed: 52 rpm Rated power: See type plate. Drum material: Stainless steel Outer casing material: Powder-coated and hot-galvanized sheet steel or stainless steel. Setup Stacking or freestanding Drain:... -
Page 19: Service
Service Before contacting the service division Before contacting the service division, you Model designation should find out whether you can resolve the fault yourself. See the "Troubleshooting" and Type plate "Care and cleaning" chapters. If you still need to contact the service division, make sure that you know the model designa- tion, type designation and serial number. -
Page 20: Installation
Installation How to assemble the stack: Positioning the tumble dryer 1. Undo the anti-tilt device. The tumble dryer can be free-standing or in a stack. Remember that the tumble dryer produces heat and should therefore not be located in a room that is too small. If the room is very small, drying will take longer due to the limited quantity of air. -
Page 21: Adjusting The Feet
Installation 5. Fit the plastic cups so that the “tags” marked with arrows are against the front Adjusting the feet edge or side edge of the cover and press them firmly onto the cover. Then break off Screw the feet in or out so that the tumble the remaining tags. -
Page 22: Electrical Installation
Installation Electrical installation The machine must only be connected to an earthed wall socket. Connection on delivery The machine is supplied as 1-fas, 230V, with a heat output of 2500W and a 16A fuse. Any earth fault fuses must be type A. Switch-over It is possible to switch over from 16A (heat output 2500W) to 10A (heat output 1950W). -
Page 23: Door Hanging
Door hanging 5. Next you must move the plastic plugs on Door hanging the upper and lower edges of the door. Use The tumble dryer comes with the door hung a flat screwdriver. on the left. However, it is possible to change the door so that it is hung on the right. - Page 24 Door hanging 8. Insert the door magnet in place of the cover washer. 14.Replace the screw which you removed in point 11. 9. Insert the cover washer in place of the door 15.Replace the lower front plate. magnet. 10.Insert the screws so that the door magnet and cover washer are held in place.
- Page 25 Your notes...
- Page 26 Your notes...
- Page 27 Your notes...
-
Page 28: Quick Guide
Quick guide Fabrics Drying programme finished • Dry fabrics of the same type together • The text "END" appears on the display to ensure that they dry as evenly as when the programme has finished. If possible. you have selected the Anti crease op- tion, the drum will rotate every minute Turn on the main power switch for 2 hours after cooling.
