Sierra 11P Patio Heater
(Propane only)
Sierra 13N Patio Heater
(Natural Gas Only)
AGA Approval No. 4800
Installation and servicing instructions
(After installation, hand these instructions to the consumer.)
Important all installations must conform with relevant statutory regulations and the Australian Gas
Association installation Code AG601. To be installed and serviced by an authorized person.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 11P and is the answer not in the manual?

Questions and answers

Summary of Contents for Sierra Products 11P

  • Page 1 Kangaroo Flat, 3555 Free Call: 1800 630116 Email: sierra@bendigo.net.au Website: www.sierraproducts.com.au Sierra 11P Patio Heater (Propane only) Sierra 13N Patio Heater (Natural Gas Only) AGA Approval No. 4800 Installation and servicing instructions (After installation, hand these instructions to the consumer.) Important all installations must conform with relevant statutory regulations and the Australian Gas Association installation Code AG601.

  • Page 2: Table Of Contents

    Contents: 1.0 Introduction 2.0 Technical Specification 2.1 General 2.2 Ignition and Control 2.3 Gas Inlet Connection 3.0 Gas Supply 4.0 Installation Instruction 4.1 Packing 4.2 Assembly of Patio Heaters (Fig. 1) 5.0 Installation and Commissioning 6.0 Installation Lighting Procedure 7.0 Fault Finding 7.1 Control Valve and Pilot Burner 7.2 Piezo Connection 8.0 Short Parts List...

  • Page 4: Introduction

    Nominal Input Burner Pressure Injector Size MJ/HR Natural Gas Model 13N 46.8 0.75 3.30 Propane Gas Model 11P 41.4 2.75 1.90 Control Sit 500 Simplosit Control Valve Main Burner Type Pressed steel venturi; vertical position with cast iron top. Ignition and Control...

  • Page 5: Installation Instruction

    Gas Supply continued. Gas supply piping should be of an adequate size. Refer section 4 of AG601. Particular attention should be paid to section 4.11 of AG601 concerning the location and depth of cover for consumer piping. The complete installation must be tested for soundness as per section 2.6 of AG601. Installation Instructions Packing The patio heater will arrive packed in two cartons which will contain ready to assemble...

  • Page 8: Installation And Commissioning

    Installation and Commissioning 1. Locate patio heater in final position on patio or leisure area. (Confer with customer, purchaser or user. Warning- ensure minimum clearance from flammable material both 400mm above and sideways of 1.5 meters (4ft 6in) this appliance is for external use only. 2.
  • Page 9 Initial Lighting Procedure. 1. Slide open control cover door. Operating instruction- Natural Gas 1. Turn gas cock on. 2. Push lower button fully in at the same time operate igniter button, until pilot flame lights, continue to hold button in for approximately 15 seconds. (1-2 minutes may be required.) 3.

  • Page 11: Fault Finding

    Fault Finding Control Valve and Pilot Burner. Pilot Flame goes out. 1. Check gas supply has not been turned “off” 2. Check pilot flame adjustment on the side of control valve. Remove cover screw, adjust inner screw anti clockwise to give 30mm long flame (see Fig. 3 and 4) whilst holding control knob depressed in pilot position if necessary).

  • Page 12: Short Parts List

    Short Parts List Appliance name and model Sierra Patio Heater 13N Appliance name and model Sierra Patio Heater 11P Manufacturer: Sierra Space Heating Ltd Australian Agent: Sierra Products Pty Ltd P.O.Box 1168 Kangaroo Flat Vic 3555 A.C.N No. 078600450 Key No.
  • Page 13 8.0A Conversion Detail. Sierra Traditional and Standard Model Patio Heaters may be converted between natural gas and propane operation. Conversion involves changing to the correct injector and pilot injector. (Refer to part numbers) Part numbers traditional and standard patio heaters. Conversion to For Use on Propane (G31)

  • Page 14: Servicing

    Servicing Important Note: To be serviced only by an authorized person. General Servicing Procedure 1. Turn off main gas at service cock. 2. Remove reflector assembly (a) by unscrewing 3 x M8 thumbscrews. 3. Unscrew the M8 hex set screw (located in the center of the cone shaped emitter) and remove emitter for examination and cleaning.

  • Page 15: Replacement/ Exchange Of Component

    Replacement/ Exchange of components 1. Main injector Carry out general servicing 1-4 Unscrew injector from adaptor/ burner 2. Pilot Injector Carry out general servicing 1-4. Unscrew nut securing thermocouple to pilot bracket/ assembly. Pull off ignition lead to electrode. Disconnect pilot supply pipe from pilot injector. Remove two screws securing pilot assembly to support bracket.
  • Page 16 Warranty Guarantees all products supplied against any manufacturing defect for a twelve month period from date of sale. The Warranty does not cover the following: 1. Faults/ Failure caused by misuse, neglect or faulty adjustments by the user. 2. Failures resulting from not using the product in accordance with the operating instruction manual.
  • Page 17 Warning This Emitter is coated with a protective oil. Upon lighting this will burn off and there will be some initial smoke. Ensure adequate ventilation.
