Summary of Contents for SDI FS100-RM
- Page 1 PECTRA YNAMICS, OISE REQUENCY ULTIPLIER FS100-RM PERATING ANUAL PECTRA YNAMICS, NC • 1849 Cherry St. Unit 2. • Louisville, CO 80027 Phone: (303) 665-1852 • Fax: (303) 604-6088 www.spectradynamics.com...
- Page 3 The FS100-RM is an ultra-low noise multiplying frequency synthesizer. The standard FS100-RM unit multiplies a frequency input of 5 MHz or 10 MHz +13 dBm to provide 100 MHz output. The input frequency must be specified when placing the order.
-
Page 4: Safety And Preparation For Use
Line Voltage This instrument may be setup to operate on 100-120 or 220-240 VAC and a line frequency of 50 to 60 Hz. The setup voltage for this FS100-RM is specified on page 4. Fuse A 0.50 Ampere 250V slow-blow fuse is used for 100-120 VAC operation. -
Page 5: The Front Panel
LED should be on when DC power is applied and the unit is operating properly. If the FS100-RM is not equipped with the battery backup option, the DC POWER LED will not be connected but will still be on the front panel. -
Page 6: The Back Panel
The Back Panel The Back Panel AC POWER ENTRY MODULE The FS100-RM is configured to operate on: 100-120 VAC 220-240 VAC DC POWER ENTRY MODULE Optional Battery Backup Connector for +24 VDC Backup power source. Copyright © SpectraDynamics, Inc. 2010... -
Page 7: Battery Backup Module
Battery Backup Module Description If you acquired the optional battery backup module for your FS100-RM you will be able to power your instrument with an external +24 VDC power source. In case of loss of the main AC power this module will automatically power the unit. The switch from AC to DC supply operation is affected by a Schottky diode network and charge storage capacitors to ensure glitch free operation. - Page 8 DC Connector DC Connector WARNING! DO NOT APPLY AC VOLTAGE TO THIS UNIT THROUGH THE 6 PIN CONNECTOR ON THE REAR OF THE UNIT! Failure to follow these directions will cause injury or death to personnel, cause irreparable damage to the instrument and void all warranties. WARNING! DO NOT REVERSE THE POLARITY OF THE SUPPLY VOLTAGE! Reversing the polarity of the power supply will cause damage to the unit and void...
-
Page 9: Operation
This unit is designed to operate only with the specified voltage on page 4. For conversion to a different voltage of operation contact SDI. To operate the unit, locate the power entry module on the rear of the enclosure and connect the power cord. -
Page 10: Specifications
Specifications PARAMETER CONDITIONS UNITS Output Power +13 dBm input Impedance input Ohms output Return Loss input(S11) output(S22) Spurious Harmonics of input frequency Harmonic Distortion +13 dBm output Phase Noise 1 Hz -145 -140 dBc/Hz referred to the input 1 kHz -170 -167 10 kHz... -
Page 11: Warranty
SDI’s option, any product not meeting the said specifications. This warranty shall be in effect for one (1) year from the date a FS100-RM is sold by SDI. SDI makes no other warranty, express or implied, and makes no warranty of the fitness for any particular purpose. - Page 12 FS100-RM:1I-6O/R02...
