- Page 1 Nova Power From The Heavens Nova FF6.5 Front Firing Powered Subwoofers Operation Manual & Technical Guide www.earthquakesound.com Sound That Will Move You.
-
Page 2: Table Of Contents
This owners manual is designed to better acquaint you with the Nova FF6.5 subwoofer system and guide you through the phases of system design and application. It is imperative that you read this manual in its entirety. Simply call 1- 800-576-7944 for EARTHQUAKE technicians and staff to answer any questions you might have in regards to the FF6.5... -
Page 3: Warranty Guideline
Product/part damaged due to poor packaging or abusive shipping conditions. Subsequent damage to other products. warranty claim will not be valid if the warranty registration card is not properly filled & returned to Earthquake with a copy of the sales receipt. -
Page 4: Specifications & Performance
Specifications & Performance Specifications Power: 150 watts Frequency Response: 28-180Hz Dimensions Height: 9-15/16" (252.4mm) - including 3/8” (10.4mm) legs Width: 7-11/16” (194mm) Depth: 14-1/4" (361mm) - including amplifier controls Weight: 16.5 lbs / 7.5 kgs Power Line Voltage: 115-230~AC / 50/60Hz Output Levels: Greater than 100dB peak SPL (includes room gain) from 40Hz to 135Hz. -
Page 5: Product Overview
Product Overview Class "A/B" Amp 150 Watts Class "A/B" high efficiency power amplifier 12 dB/Octave variable filter from 40 Hz to 180 Hz Automatic signal detection circuitry. When "ON", it automatically turns on the subwoofer when an audio signal is detected. It also shuts the subwoofer off after 30 minutes if no signal is detected Low level (RCA) audio inputs FF6.5 Transmission Line Design... -
Page 6: Control Panel Overview
Positioning Your Subwoofer Subwoofer Placement FF6.5 Subwoofer There is no argument among audio professionals that the loudest bass output from a subwoofer comes from corner placement. The sound flaring outward from a room corner focuses low frequencies giving them no place to go but toward you. -
Page 7: Connecting Your Subwoofer
Connecting Your Subwoofer Low Level (RCA) Input Connection 1. Locate the LINE IN RCA on the FF6.5 amplifier. 2. Connect the FF6.5 to the signal source, i.e. AV receiver. Even though there is no need to have both RCAs to the signal source since the subwoofer is often operated in mono signal, we recommend connecting the receiver to both RCA inputs in order to obtain higher signal level. - Page 8 Sound That Will Move You. 2727 McCone Avenue. Hayward, CA 94545. USA US Toll Free: 1-800-576-7944 | Tel: 1-510-732-1000 | Fax: 1-510-732-1095 www.earthquakesound.com...
