Summary of Contents for Iluv iCM10
- Page 1 English Model : iCM10 / iCM15 / iCM20 Instruction Manual Mini Webcam for Laptop...
-
Page 2: Introduction
INTRODUCTION Thank you for purchasing the iCM10 / iCM15 / iCM20. Unpack the unit and make sure all accessories are put aside so they will not be lost. Clip-Style Webcam · High quality 1.3 megapixel (iCM10/15), 3.0 megapixel (iCM20)sensor resolution webcam for laptop or desktop ·... -
Page 3: Table Of Contents
Audio Source and Settings Using Internet Messenger Downloads Maintenance Tips WEB CHATTING AND SPECIAL EFFECTS GUIDE Installing the Special Effects Software Instant Messenger Setting Using the Special Effects and other Features TROUBLESHOOTING GUIDE USER SAFETY GUIDE SPECIFICATIONS iCM10/15/20 | V10M10_IM_EN_08112010 iLuv | 2... -
Page 4: Getting Started
· Mac OS X 10.4 or later · 1GB RAM · 160MB hard disk space (260MB recommended) · CD-ROM drive · One available USB port (USB 2.0 recommended) · Internet connection for Web chatting iCM10/15/20 | V10M10_IM_EN_08112010 iLuv | 3... -
Page 5: Installation
ManyCam special effects. Insert the installation CD into your CD-ROM/DVD-ROM drive and Install the software according to the screen prompts. If prompted to do so, restart your computer after installation. iCM10/15/20 | V10M10_IM_EN_08112010 iLuv | 4... -
Page 6: Operational Instructions
For Windows XP / Vista / 7 users: 1. Click on the Start menu button. 2. Click on the All Programs menu item. 3. Click on iCM10, iCM15 or iCM20 Amcap. 4. From the menu bar, choose Capture Start Capture. -
Page 7: Camera Settings
Items in the above Video Format window are described as: · Frame Rate – this setting controls the frame rate of the image or video. The higher the frame rate, the larger the file size. iCM10/15/20 | V10M10_IM_EN_08112010 iLuv | 6... - Page 8 The video source dialog box allows you to control the image quality provided by your camera. In Amcap, click on Options Video Capture Filter or Properties for the Instant Messenger application to have a window similar to the one shown below. iCM10/15/20 | V10M10_IM_EN_08112010 iLuv | 7...
- Page 9 · Zoom – this setting allows you to zoom in or zoom out the image capture. Please note that many of the above settings operate the same as those on a normal color TV or computer monitor. * Properties may differ depending on computer setting. iCM10/15/20 | V10M10_IM_EN_08112010 iLuv | 8...
-
Page 10: Light Sources
· Compression Control - Compression control lets you adjust the frame rate. The USB Web Camera is initially set to use the lowest compression setting, but choosing high compression mode may help speed up the rate of transmission. iCM10/15/20 | V10M10_IM_EN_08112010 iLuv | 9... -
Page 11: Audio Source And Settings
Under the ‘Audio’ tab, change the ‘Default device’ of ‘Sound recording’ to ‘USB Audio Device’ or display web-camera model number. 2. Choose ‘Volume’ under ‘Sound Recording’ , adjust the ‘Volume’ until the microphone reaches a comfortable sound level. iCM10/15/20 | V10M10_IM_EN_08112010 iLuv | 10... - Page 12 Important: When running with camera software application (Amcap) as the first time, go to Options Audio Capture Filter. To increase the audio volume, slide the bar in ‘AudioInputMixer Properties’ page as below. In the ‘Pin Line’ box, select ‘Microphone’ . iCM10/15/20 | V10M10_IM_EN_08112010 iLuv | 11...
-
Page 13: Using Internet Messenger Downloads
• Outdoor Use: Your USB Web Camera is not designed for outdoor use and should not be exposed to the elements without suitable protection. In general, you should not expose it to extreme temperatures or humidity. iCM10/15/20 | V10M10_IM_EN_08112010 iLuv | 12... -
Page 14: Web Chatting And Special Effects Guide
Each messenger service is different and may be subject to various updates. Please use the available toolbar options for the messenger service you use in order to effectively use this Web cam for chatting. iCM10/15/20 | V10M10_IM_EN_08112010 iLuv | 13... -
Page 15: Using The Special Effects And Other Features
Open the –”Effects” tab of the ManyCam options window. Click the –”Backgrounds” tab. Select the type of background (static or dynamic) you would like to use. Select an individual background from the list in the bottom part of the window. iCM10/15/20 | V10M10_IM_EN_08112010 iLuv | 14... - Page 16 Type your text in the field below. Adjust options like scrolling, font, transparency and background color. Place your text where you want it to be shown in the video window by Drag and Drop. iCM10/15/20 | V10M10_IM_EN_08112010 iLuv | 15...
- Page 17 (you can use one of the existing categories or create a new one) Fill the –”Name” and –”Created by” fields. Click –”OK”. The new effect will now appear in the category you have selected. iCM10/15/20 | V10M10_IM_EN_08112010 iLuv | 16...
-
Page 18: Troubleshooting Guide
Brightness or Contrast settings in the software you are using. · Make sure that there is no strong light source behind the object or person being viewed by the PC Camera. · Make sure that the lens is clean. iCM10/15/20 | V10M10_IM_EN_08112010 iLuv | 17... -
Page 19: User Safety Guide
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. iCM10/15/20 | V10M10_IM_EN_08112010 iLuv | 18... - Page 20 (grounding) pin. This plug will only fit into a grounding-type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the grounding-type plug. iCM10/15/20 | V10M10_IM_EN_08112010 iLuv | 19...
- Page 21 Please remember to respect the local regulations: Hand in the non-working electrical equipment to an appropriate waste disposal center. FOR USED BATTERIES Disposed of the used batteries properly. Please follow the local regulations for the battery disposal. iCM10/15/20 | V10M10_IM_EN_08112010 iLuv | 20...
- Page 22 Note: Do not make changes or modify the device in any way. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. iCM10/15/20 | V10M10_IM_EN_08112010 iLuv | 21...
- Page 23 This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. iCM10/15/20 | V10M10_IM_EN_08112010 iLuv | 22...
- Page 24 • Mains plug is used as the disconnect device. It shall remain readily operable and should not be obstructed during intended use. To be completely disconnected, the apparatus from supply mains, the mains plug of the apparatus shall be disconnected from the mains socket outlet completely. iLuv | 23 iCM10/15/20 | V10M10_IM_EN_08112010...
-
Page 25: Specifications
SPECIFICATIONS · Image Sensor: CMOS 1.3M pixels (iCM10/15 ) / 3.0 M pixels (iCM20) · Image Sensor Size: 1/5.5” (iCM10/15) / 1/4” (iCM20) · 2560×1920(iCM10/15) by software interpolated · 4000×3000(iCM20) by software interpolated · Video Frame Rate: up to 30 fps ·... - Page 26 © 2010 www.i-Luv.com iLuv is a registered trademark owned by iLuv Creative Technology. MSN and Windows Live are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. Skype is a trademark of Skype Limited. Yahoo! is the trademark and/or registered trademark of Yahoo! Inc.
