Cascade Whisperlite International Instruction Manual

TROUBLESHOOTING

Problem
Leaking Fuel Cause Solution
At Pump and Fuel Bottle Connection Damaged or missing Pump Seal Replace Pump Seal
At Pump and Fuel Line Connection Damaged or missing Fuel Tube Replace Fuel Tube O-ring
O-ring
At Control Valve Stem Damaged or missing Replace Control Valve O-ring
Control Valve O-ring
In Pump Plunger Chamber Obstructed Check Valve Clean Check Valve Cavity
Poor Performance Cause Solution
Pump not pressurizing Fuel Bottle Loose or poorly seated Pump Tighten or rescrew Pump
on Fuel Bottle
Damaged Pump Cup Replace Pump Cup
Plunger hard to pump Dry Pump Cup Lubricate Pump Cup
Erratic yellow flames Improper preheating Repeat Step 4
Diminished flames Low Fuel Bottle pressure Pump the Plunger
Slow boil times Clogged Jet or Fuel Line Clear Jet and clean Fuel Line
Diminished flames at altitude Insufficient airflow Open Windscreen slightly

FUEL INFORMATION

The WhisperLite ™ Internationale stove burns a variety of fuels by using two interchangeable Jets.
1. The IG Jet is used for White Gas and Unleaded Auto Gas. This Jet is preinstalled in your stove.
2. The K Jet is for Kerosene and Diesel. This Jet is included in the parts kit with your stove.
To exchange Jets, see "Cleaning the Jet and Fuel Line."
Use MSR ® SuperFuel ™ (White Gas) for optimal performance. It is the highest quality fuel available for your stove.
Do not use leaded fuels. Fuels other than MSR SuperFuel white gas lead to rapid stove clogging and require
more frequent Jet and Fuel Line cleanings. Also, the use of Unleaded Auto Gas may shorten stove lifespan. Use
the fuels chart below to help you find your fuel when traveling internationally.
Visit www.msrgear.com for more information on international fuel names and safe stove transportation.
USA/UK/ Germany/
Japan France Netherlands
Canada Switzerland
White Gas, Kocherbenzin, Pétrole à brûler,
White Gas Wasbenzine
Naphtha Reinbenzin Essence C
Unleaded Essence sans Gasolina sin
Autobenzin Gasoline Benzine
Auto Gas plomb
Petroleum
Kerosene Petroleum Toh-yu Kérosène
Lampolie
2010_WLI-StoveInst_EN_USJC.indd 1
DANGER
CARBON MONOXIDE, FIRE & EXPLOSION HAZARD
There are serious hazards associated with using this stove and fuel. Accidental
fire, explosion, and misuse can cause death, serious burns, and property dam-
age. You are responsible for your own safety and the safety of those in your
group. Please use good judgment.
This stove is for OUTDOOR USE ONLY. Never use this stove in a tent, vestibule,
car, house, or inside any enclosed area. This stove consumes oxygen and pro-
duces carbon monoxide gas, which is poisonous and has no odor. This stove
can easily ignite nearby combustible materials and flammable liquids or vapors.
If you use this stove in an enclosed area you can be killed or seriously burned.
Keep stove and fuel bottle away from other heat sources. Never use cookware
or an Outback Oven with a diameter larger than 10 inches (25 centimeters).
™
Oversized cookware can overheat the fuel bottle. If you expose the fuel bottle to
high heat, it will explode and you can be killed or seriously burned.
Never let children use this stove. Keep children at least 10 feet (3 m) away from
the stove and cooking area, and supervise them at all times.
Spain
READ, UNDERSTAND, AND FOLLOW ALL instructions and warnings in this
Bencina
manual before using this stove. Failure to follow warnings and instructions can
blanca
result in death, serious burns or other injury, and property damage.
plomo
Parafina
WARNING
Do not attempt to use this stove: (1) before reading and fully understanding this
Instruction Manual; (2) if you are not prepared or comfortable attending to a
burning and/or hot stove at all times; (3) if you observe leaking fuel; or (4) if
you observe any condition with the stove system or in the surrounding environ-
ment that would make operation of an open flamed device dangerous. Failure
to follow these directions can cause an unsafe situation leading to fire, burns,
severe injury or death.
This stove is designed for the outside (i.e., not within enclosed spaces of any
kind; e.g., tents) boiling of water or cooking of food only—never use it for
any other purpose. Use of stove within any enclosed space, or for a purpose
other than boiling water or cooking food can cause fire, burns, severe injury
or death.
Do not disassemble stove beyond what is described in these instructions. Do not
modify stove. Disassembly or modification of stove in any manner not consistent
with these instructions voids warranty and can result in an unsafe situation
where fire, burns, severe injury or death can occur.
Do not use stove if parts are missing or broken, or with replacement parts not
specific to your stove model. Use of stove with missing or broken parts, or with
replacement parts not specific to your stove model, can result in an unsafe situ-
ation where fire, burns, severe injury or death can occur.
Always use stove on a solid, stable, even surface to avoid tipping and spills.
Tipping of stove can result in an unsafe situation where fire, burns or severe
injury or death can occur.
Cascade Designs, Inc. warrants the use of appropriately sized MSR ® brand
cookware only—use of cookware other than MSR ® brand cookware will be at
user's own risk and discretion.
FOR OUTDOOR USE ONLY
Fo r p r o du c t s er vi c e a nd i nf o r m at i o n c o nt ac t
C a s c a d e D e s i g n s , I n c .
4 0 0 0 F i r s t A v e n u e S o u t h , S e a t t l e , WA 9 8 1 3 4 U S A
P h o n e : 8 0 0 . 5 3 1 . 9 5 3 1 o r 2 0 6 . 5 0 5 . 9 5 0 0
w w w. m s r g e a r. c o m
ART# 33-303 | EN
I N S T R U C T I O N
M A N U A L
M O U N TA I N S A F E T Y R E S E A R C H
W H IS P ER L I T E IN TE RN ATIO N A L E
™
