- Page 1 ® Gyro Stabilized Marine Satellite TV System Model 9815-RJ Model 9818-RJ Installation and Operating Instructions ® Satellite Solutions for Mobile Markets 11200 Hampshire Avenue South, Bloomington, MN 55438-2453 Phone: (800) 982-9920 Fax: (952) 922-8424 www.kingcontrols.com MEMBER 1315 REV C...
-
Page 3: Table Of Contents
IMPORTANT! The satellite TV market is expanding and changing. The information in this manual was accurate at the time of printing. If your Sea-King does not operate as outlined in this manual please call King Controls at (800) 982-9920 or visit our website at www.kingcontrols.com. Please read this entire manual before beginning the installation. -
Page 4: Introduction
INTRODUCTION SECTION 1 The Sea-King Fully Stabilized Marine Satellite System includes 4 main components (Fig. 1). Dome (Antenna) Unit Mounted on the vessel. The dish is covered by a protective dome that keeps operational components free from the elements. Controller Located in the vessel. -
Page 5: Definition Of Terms
DEFINITION OF TERMS SECTION 2 AZIMUTH: Angle in degrees measured clockwise from Magnetic North (0°) (Fig. 2). Fig. 2 ELEVATION: Angle in degrees measured from a level plane (Fig. 3). Fig. 3 SIGNAL STRENGTH: Intensity of electronic signal received from the satellite transmission. Page 3... -
Page 6: Installation
INSTALLATION SECTION 3 TOOLS AND MATERIALS REQUIRED 1. Read thru the instructions and make sure you have all the tools and materials required to complete the installation, including: • drill and drill bit set • tape measure • 7/16” open end wrench (coax connections) •... - Page 7 The shortest distance between the dome unit and the main satellite receiver is most desirable. b) The dome unit requires a 16.5” (model 9815-RJ) or 20” (model 9818-RJ) diameter mounting area on the vessel surface. You may also use an industry standard mount.
- Page 8 2. Place the components in the selected areas. REMOVE SHIPPING RESTRAINTS Note: Reference appropriate figure on next page for your model number: Model 9815-RJ: see Fig. 6A Model 9818-RJ: see Fig. 6B 1. Remove and save the dome cover screws. (Figs. 6A and 6B).
-
Page 9: Installation
Fig. 6A 9815-RJ IMPORTANT! The shipping bolt must be removed prior to installation. IMPORTANT! CAREFULLY remove the dome cover, tilting it side to side as necessary to prevent damaging internal components. Fig. 6B 9818-RJ IMPORTANT! The shipping bolt must be removed prior to installation. - Page 10 EXTREMELY IMPORTANT! NEVER lift the unit by the LNB assembly, Wave Guide assembly, or the dish. Lift the unit by the base ONLY. PRE-INSTALLATION CHECK To verify proper operation of the components, perform a Pre-Installation Check as follows: 1. Place the dome unit in your chosen location and on its mounting pedestal. Temporarily secure the unit from falling.
- Page 11 2. TEMPORARILY connect the system as outlined on page 13. If using both 50’ coax, label the ends of one coax to avoid confusion when making the connections. MAKE SURE TO CONNECT POWER LAST. 3. Verify system operates properly as described in Section 4 OPERATION, Page 18. DISH NETWORK - EXPRESSVU: If configuring the receiver for multiple satellite switching, do this now while the antenna unit is on a motionless platform (see page 24).
- Page 12 IMPORTANT! Make sure power supply is disconnected from 110 volt source before continuing with permanent installation. The installer is responsible for weatherproofing all holes in the vessel. Note: The installer is responsible for determining the most appropriate fastener to secure the dome unit to the pedestal or vessel surface.
- Page 13 3. Fill end of coax cable that will connect to the MAIN port on the dome unit with supplied dielectric grease. Connect this end of the coax cable to the MAIN port and tighten connection (Fig. 9). If using a second (auxiliary) receiver, fill end of second coax cable and connect it to the unlabeled port.
- Page 14 ELECTRICAL HAZARD WARNING! The coax cable that connects the dome unit to the tuner carries a 24 volt electrical current. Exercise extreme caution when handling this cable. Do not cut, break, or splice this line. Do not insert or connect any devices such as splitters or any other device for any reason.
- Page 15 Sea-King Fig. 10 Model 9815-RJ & Model 9818-RJ Wiring Schematic Note: In order to view programming from the master and secondary receivers simultaneously, both receivers must be tuned to a channel broadcast from the same satellite. Use the controller to manually switch satellites for the secondary receiver.
- Page 16 MULTIPLE SATELLITE RECEIVER CONFIGURATIONS With the use of an active multi-switch (sold separately by King Controls), more than two TV’s and receivers can be hooked up (see Fig. 11 for typical 4 receiver hookup). Diagram shows King Controls Multi-Switch #1810. Other options: 3-4 satellite receivers: use one 2x4 or 3x4 active multi-switch 8 satellite receivers: use one 2x8 or 3x8 active multi-switch...
- Page 17 Sea-King Fig. 11 Model 9815-RJ & Model 9818-RJ Typical 4 Receiver Hookup IMPORTANT! HDTV Converter must be connected to 18V input on multi-switch. IMPORTANT! AVOID SHARP BENDS WHEN ROUTING COAX. Page 15...
- Page 18 OPTIONAL WALL MOUNT FACEPLATE (INCLUDED) Note: If not using the faceplate, see faceplate removal instructions below. IMPORTANT! Depending on the thickness of the vessel wall, a relief notch may need to be cut for the cable. THE CABLE MUST NOT BE PINCHED OR BENT WHEN MOUNTING THE DISPLAY. 1.
- Page 19 TUNER MOUNTING OPTIONS You can mount the tuner or leave it freestanding: a) You can mount the tuner to an appropriate surface (Fig. 14). b) You can leave the tuner freestanding. If space requirements dictate, the mounting feet can be snapped off. Fig.
-
Page 20: Operation
OPERATION SECTION 4 IMPORTANT! There must be a clear “line of sight” to the satellite (See Fig. 2, Page 3). Terrain, other boats, buildings, trees, masts, telephone poles, etc. can all block the satellite signal from reaching the dish. Note: This example is for the DTV 101 satellite in Region 2-North Central. The information on your controller will vary depending on the satellite and region you have chosen (see pages 20-21). - Page 21 AUTOMATIC SATELLITE SWITCHING DIRECTV: Before using the automatic switching feature, you must configure the Sea-king and your receiver for your desired option. For switching options see pages 22. Dish Network - ExpressVu: Before using the automatic switching feature, you must configure the Sea-King and your receiver for your desired option.
- Page 22 SET SATELLITE SERVICE IMPORTANT!: If you choose any Dish Network or Bell ExpressVu option in steps 1-3 below, you must then run the check switch on pages 24-25. All of the satellite options listed may not be available with your unit. If you cannot lock onto your chosen satellite(s), call the King Controls Service Department.
- Page 23 SET REGION (OPTIONAL) Note: To reduce satellite acquisition time, you can set your current region. REGION OPTIONS: NORTH WEST NORTH CENTRAL NORTH EAST CENTRAL WEST MIDDLE CENTRAL CENTRAL EAST SOUTH WEST SOUTH CENTRAL SOUTH EAST ALL REGIONS RECALIBRATE Page 21...
-
Page 24: Automatic Satellite Switching (Directv )
AUTOMATIC SATELLITE SWITCHING SECTION 5 DIRECTV DIRECTV 101 SATELLITE ONLY To receive programming from the DIRECTV 101 satellite only, choose the DTV 101 option (see page 20), and make sure your receiver is set for round dish-1 satellite (do this through the receiver’s satellite set-up menu screens). -
Page 25: Automatic Satellite Switching
AUTOMATIC SATELLITE SWITCHING SECTION 6 Dish Network - ExpressVu DISH 500 FOR DISH NETWORK The Sea-King will automatically switch between the 110 and 119 satellites for Dish Network by using the receiver’s remote control, after the receiver has been properly configured. Choose the Dish 110/119 option (see page 20) and then follow the instructions on pages 24-25. -
Page 26: Check Switch Procedure
CHECK SWITCH PROCEDURE SECTION 7 Dish Network - ExpressVu IMPORTANT! The antenna must be on the ground, dock or motionless platform with no movement in order to configure the DISH HD receiver. If you are an end user and the Sea-King is already permanently mounted, you can perform the configuration if the vessel is tied up tightly with no movement. - Page 27 6. When test is complete, a screen similar to ALL SINGLE SATELLITES one of the following should appear: (Screen graphics may vary.) NO SWITCH DETECTED INSTALLED DEVICE UNKNOWN DISH 500 EXPRESSVU HDTV 82/91 MUST SHOW “SW21” NO “X”s DISH 1000 DISH 1000a NO “X”s MUST SHOW...
-
Page 28: Troubleshooting
TROUBLESHOOTING SECTION 8 SYMPTOM POSSIBLE SOLUTION Controller does not power up. Check: tuner is connected to power supply. controller is connected to tuner. power supply is plugged into 110 VAC outlet. Controller remains in one of the Unplug tuner for 10 seconds, then plug back in. following conditions: Check coax cables and connections between tuner and dome unit. - Page 29 SYMPTOM POSSIBLE SOLUTION Only getting signal on 1/2 of Kinked or sharply bent coax cable. transponders. Verify coax cables are properly terminated with SNAP-N-SEAL ® connectors only. Verify receiver is operating properly. Verify LNB type is set correctly. Unit never locks on or locks on Atmospheric moisture.
- Page 30 OPTION 21 RE-INITIALIZE and 0-RECALIBRATE Page 28...
- Page 31 Page 29...
-
Page 32: Maintenance
MAINTENANCE SECTION 9 The Sea-King Satellite System has been designed to be maintenance and trouble free. For optimum signal strength, keep the dome clean from dirt, bugs, and other debris. Periodic washing of the dome with mild soap and water is recommended. If you plan on storing your vessel for long periods of time, it is recommended that the system be put through a search procedure on a quarterly basis to keep all moving parts in good working order. -
Page 33: Limited Warranty
LIMITED WARRANTY SECTION 10 Every King Controls Satellite System is thoroughly inspected and tested before leaving the factory. It is covered by a two year parts and one year labor limited warranty from the date of original purchase. This warranty does not cover installation and external wiring or refurbished units. - Page 34 Notes: Page 32...
- Page 36 ® 11200 Hampshire Avenue South, Bloomington, MN 55438-2453 Phone: (800) 982-9920 Fax: (952) 922-8424 www.kingcontrols.com ®...
