Advanced Keys AK-PSB05 Installation Manual

Push-start ignition system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ADVANCED KEYS
Push-Start Ignition System
*
INSTALLATION GUIDE
Product Features:
•
Push-Start Ignition Operation
•
OEM Toyota Push-Start Button
•
One-Touch Engine Tach Ignition
•
Backup Ignition Relays
•
Diesel Wait-to-Start Input
•
Immobilizer Bypass Enable Trigger
•
Remote Start Function with AK-103
•
Compatible with Aftermarket Alarms
•
Compatible with OEM Vehicle Setup
www.advancedkeys.com
support@advancedkeys.com
© Copyright Advanced Keys Inc. 2011. All Rights Reserved.
AK-PSB05
REV: A05-11-1118

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AK-PSB05 and is the answer not in the manual?

Questions and answers

Summary of Contents for Advanced Keys AK-PSB05

  • Page 1 Backup Ignition Relays • Diesel Wait-to-Start Input • Immobilizer Bypass Enable Trigger • Remote Start Function with AK-103 • Compatible with Aftermarket Alarms • Compatible with OEM Vehicle Setup www.advancedkeys.com support@advancedkeys.com © Copyright Advanced Keys Inc. 2011. All Rights Reserved.

  • Page 2: Table Of Contents

    FCC And Canadian Compliance PRODUCT CONTENTS The following list of components are included in this system: Push-Start Module Button Ring Mount Accessory Harness Ignition Key Cover Backup Ignition Relay User Manual/Installation Guide Push-Start Button © Copyright Advanced Keys Inc. 2011. All Rights Reserved.

  • Page 3: Warning And Safety Information

    DO NOT power up the module before it is properly grounded. Should the unit be powered before being grounded, serious damage to internal components could occur. CAUTION © Copyright Advanced Keys Inc. 2011. All Rights Reserved.

  • Page 4: Connections

    Status LED ON 1 ON 2 START All Off Ready Amber Green Green (Flashing) Step On Brake Amber (Flashing) No Change to Any Output START (Crank) All Off RUN (ON) Backlight Only © Copyright Advanced Keys Inc. 2011. All Rights Reserved.

  • Page 5: Access Harness Wire Descriptions

    (JP1) selects Non -Tach Ignition mode. In Non-Tach Ignition mode, engine START or crank time is depended on how long the push-button is held it down. © Copyright Advanced Keys Inc. 2011. All Rights Reserved.

  • Page 6: Controller Wiring Diagram

    Default Settings Optional Settings Tach Ignition Tachless Ignition Smart Key Enable Ground Enable Remote Start Enable* Remote Start Disable* *Remote start function only available with Advanced Keys’ Smart Key module. Legend: Input Positive Type Frequency Type Output Negative Type In-Line Fuse...

  • Page 7: Installation

    ON 2 (Main) and ON 2 (Backup). • connect the ON 1 of vehicle, and join the ON 2 (Main) and ON 1 (Backup) together and connect the other ON 1 of the vehicle. © Copyright Advanced Keys Inc. 2011. All Rights Reserved.

  • Page 8: Tach Ignition Programming

    TACH IGNITION PROGRAMMING Follow steps below to program Tach signal for Tach Ignition Mode. This function allows automatic START (crank) the engine by single tap the push-start button. Prior to programming, check to ensure Tach input and ignition outputs (ACC, ON and START) with applicable immobilizer bypass device are connected/programmed.

  • Page 9: Ignition Test And Troubleshooting

    A) Transponder signal missing and vehicle fail to disable immobilizer. Verify Immobilizer bypass is working. Reprogram Tach B) System may under-crank the engine. Program Tach at higher RPM than idle. See Reprogram Tach Ignition above. © Copyright Advanced Keys Inc. 2011. All Rights Reserved.

  • Page 10: Remote Start Function

    REMOTE START FUNCTION (OPTIONAL) A built-in Remote Start function is available when system is connected with an Advanced Keys Smart Key System. To enable remote start function the following conditions are required: • Internal Jumpers JP1, JP2 and JP3 are set at their default position.

  • Page 11: Steering Column Lock Bypass

    ACC and remove the shaved-key from the key cylinder and insert OEM key to operate the vehicle normally. Note: There are multiple ways to bypass steering column. Advanced Keys does not recommend permanent disabling the mechanism and is not responsible for any damage, theft and accidents which could result from steering lock bypass modification in any ways or forms.

  • Page 12: Keysense Function Bypass (Optional)

    Insert the push-button along with the wire and connector through the Button Ring Mount and the cut- out. Push the button down until fully seated around the Button Ring Mount over the cut-out. Apply adhesive to the Button Ring Mount backing if desired. © Copyright Advanced Keys Inc. 2011. All Rights Reserved.

  • Page 13: Frequently Asked Questions

    Tach Ignition programming. If engine is running DO NOT attempt to START again. (Press the Push-Start button while brake is applied) This will cause the engine to over crank. WARNING © Copyright Advanced Keys Inc. 2011. All Rights Reserved.
  • Page 14 See "Remote Start Ignition Takeover" section under the REMOTE START FUNCTION on page 11. What if I am having other issue that is not list here? Please contact support@advnacedkeys.com for additional help . © Copyright Advanced Keys Inc. 2011. All Rights Reserved.

  • Page 15: Closing Up

    Tach Tachless System Enabled by: If YES is Neutral Safety Switch tested and working? Smart Key Third Part Device Reviewed Product Operation with End-User: Tested and Working Not Tested Additional Comments: © Copyright Advanced Keys Inc. 2011. All Rights Reserved.
