Summary of Contents for MOVIEtube MOVIEtube ST
- Page 2 The up- and downgrade procedure can be completed within 10 minutes by using Allan Keys. The MOVIEtube ST is a top of the line version for small video docking cameras and is equipped with following accessories: An integrated Sony/ Panasonic tripod plate compatible shoulder set for living camera moves •...
- Page 3 Features A: Professional viewfinder mounts for use with Sony/ Panasonic compatible finders. B: WALTERgrip top and side. For carrying the MOVIEtube or handheld shots like low shots/ low moves. C: Plate for Sony V-Mount or Anton Bauer compatible batteries. D: Integrated Sony/Panasonic tripod plate compatible shoulder set.
- Page 4 G: Extendible battery plate with quick release to compensate for heavy lenses. H: 12V Arri-compatible (AUX PWR) out Fischer 11-pin Video out (VID OUT) 1 BNC, 2 Fischer 4-pin with 12Vpower for monitoring etc. I: WALTERgrip handles for handheld and on shoulder moves.
- Page 5 The MOVIEtube ST is placed in front of you, lens left hand, battery right hand side. Grab the top handle of the MOVIEtube with your right hand from below and behind and lift it onto your right shoulder. Support it from the side with your left hand on the front camera handle.
- Page 6 Some camcorders have an external microphone with cradle suspension. For example: Sony HDR-Z1, PD150 / PD170 Panasonic AG-DVX100, AG-HVX200 To fit this type of camcorder to the MOVIEtube ST please remove the cradle suspension with a screw driver. The images below are showing the cradle removing on a Panasonic AG-DVX100.
-
Page 7: Specifications
12 Golden rules carefully! * The primary goal while developing the film screen was not only to produce a video frame with less depth of field, but to create a truly film-like image on video. The MOVIEtube image reproduces... -
Page 8: Electronic Connectors
Electronic connectors • Illuminated on/off switch (POWER) • 12V Arri-compatible (AUX PWR) Fischer 11-pin • Video out (VID OUT), 1 BNC, 2 Fischer 4-pin with 12Vpower for Arri Mini Monitor • 12V power in (BATTERY) Fischer 2-pin • Video in (VID IN) Composite-Cinch •... -
Page 9: Lens Mount
To carry the camera system please use only the handle grip of the Sony: HDR-FX1/ HVR-Z1, PD100, PDX10, PD150/ 170, MOVIEtube ST. Never use the handle bar of the docking camera. VX1000/ 2000/ 2100, TRV890/ 900/ 950, Never open the red sealed screws or remove the protective glass... - Page 10 To shoot with the highest possible sensitivity, open the Iris completely. Consider shooting MOVIEtube. Use a lens brush and/ or an air duster, in clean environment so not to scratch with shutter speed 1/25 for cinematographic look and increasing the sensitivity by 1 Stop.
- Page 11 Fax: +44 (020) 7820 1718 Office hours: Office hours: Monday to Friday 8.00am to 4.00pm GMT Monday to Friday 9.00am to 6.30pm GMT hbr@befort-optic.com Email: carey.duffy@camerafilters.co.uk Email: For more information and movies visit our WebPages www.movietube.com or send us an email to info@movietube.com.
