Audiovox XPress RCi Quick Start Manual

Pick a Spot for Your Radio

1 Pick a Spot for Your Radio

Install the Dash or Vent Mount

Installing the Vent Mount:
You can use either the Dash Mount or the Vent Mount for your Xpress RCi , depending upon your vehicle and the 1. Locate a suitable vent in your vehicle which is strong enough to
hold the Xpress
location where you want to place your radio.
4 or 5.)
CAUTION! Make sure your radio isn't in a place where it could interfere with driver visibility or safe deployment
2. If the vent louvers are recessed, you'll have to use the
of the airbags.
extended vent hooks. The Vent Mount is assembled with the
short vent clamps, so you will have to remove the short clamps
IMPORTANT! When you install the chosen mount, do not yet attach the PowerConnect Vehicle Dock to the
mount. The cables must be attached prior to connecting the dock to the mount. and install the extended clamps as shown below.
Installing the Dash Mount: Remove End Cap
CAUTION: The adhesive used on the mount may be difficult to remove. Do
not install this mount on leather surfaces, and make sure the air temperature Dash
is at least 15ºC (60ºF) during installation.
Mount
1. Locate a flat surface for the Dash Mount. (Options 1, 2, or 3.) Make
sure there is ample room for the dock and radio when installed.
Option 1
2. Set the orientation of the mount before adhering it. Loosen the
knob and adjust Slide Extended Vent Clamps In
the adhesive foot I II
for the location
you selected:
• Option 1 &
3 should be
oriented as I.
• Option 2 should be oriented as II.
3. Push the Vent Mount onto the vehicle vent as shown (1) until
3. The dock mounting plate can be tilted in different directions.
hooked on the rear of the vent louver (2).
Adjust as necessary for your particular vehicle. When the Option 2
orientation is correct, tighten the knob. 4. Rest the foot against the bottom of the vent (2). If necessary,
adjust the tilt of the Vent Mount by repositioning the foot to a
Knob Adhesive Foot
Dock Mounting Plate
different tilt adjustment hole (3).
PUSH
4. Clean the surface with the alcohol preparation
pad, and let it dry thoroughly.
Foot
5. Peel off the adhesive liner. Position, press, and
Option 3
hold the Dash Mount in place for 30 seconds.
IMPORTANT! Let the Dash Mount adhesive cure (dry) for 24 hours before
attaching the PowerConnect Vehicle Dock and radio to the mount.
2

Install the Magnetic Mount Antenna

(continued)
Mount the Magnetic Mount Antenna
Extended Vent Clamps
Choose the best location for the antenna considering your vehicle type. Refer to the antenna
RCi and the PowerConnect Vehicle Dock. (Options placement tips and cautions in the User Guide beginning on page 22.
• Sedan or Coupe: We recommend mounting the antenna just above either the front windshield
or the back window.
Short Vent
Clamps • Pickup Truck: We recommend mounting the antenna just above the front windshield.
• Convertible: We recommend mounting the antenna at the leading edge of
the trunk.
Slide Short Vent Clamps Out
• SUV: We recommend mounting the antenna at the rear of the roof.
Vent Mount
CAUTION! STOP and read the more specific instructions in the User Guide for all
types of vehicles — or get someone who knows vehicles to help — if you don't
understand what to do. You might accidentally do damage to your ride.
Feed the antenna wire under the rubber molding around the front or rear
windshield, and into the seal around the trunk or door. For a convertible, the cable
can be routed directly into the trunk.
Replace End Cap
TIP! Use a tool like a blunt plastic putty knife, a credit card, a plastic knife, or a
similar blunt tool to help hide wires along the windshield trim.
Hide the Magnetic Mount Antenna Cable Inside the Vehicle
The best place to hide your antenna cable depends on your type of vehicle.
When the antenna is mounted at the rear of the vehicle, it's usually easiest to run
the cable from the rear to the front toward the radio by routing the cable along
the interior trim where it meets the carpet, gently pushing it behind the edges of
the trim. Bring the cable out from the trim and route it under the carpet toward
the dashboard.
When the antenna is mounted at the front of the vehicle, bring the cable into the
rubber weather stripping around the door to the bottom of the door opening.
Bring the cable out of the weather stripping and route it under the carpet toward
1 2 3
the dashboard.
Dash
Dash Dash
Coil any excess cable in a hidden location, such as under the carpet, keeping it
HOOKED away from any vehicle pedals or controls. Secure the excess cable with wire ties.
Vent Vent
Plug the antenna into the silver ANT connection on the rear of the dock.
Vent
Louver
TIP! A dry vehicle is nice. Avoid damaging or compromising the window, door, and
trunk seals.
TIP! For more help, refer to the detailed antenna cable routing instructions for
your type of vehicle, in the User Guide beginning on page 27.
3 Connect the Audio to Your Vehicle's Stereo
Decide How to Connect
To listen to Xpress RCi through your vehicle's stereo system or FM radio, it must be receiving the XM signal. Be sure your
vehicle is outside and the antenna has a clear view of the sky. Connect your Xpress
vehicle's stereo system or FM radio using one of the following options:
• Best: Use the Aux In Cable if your vehicle's stereo system has an
auxiliary input connection. Plug one end of the Aux In Cable into
the green AUDIO connector on the PowerConnect Vehicle Dock,
and the other end into the auxiliary input jack on the vehicle's
stereo system. Refer to your vehicle's owners manual to find the
location of the auxiliary input jack, or consult the vehicle dealer.
AUDIO ANT
• Better: Use a Cassette Adapter if your vehicle has a built-
in cassette player. Cassette Adapters are sold separately
and can be purchased from an electronics retailer, or go to
xmradio.ca/accessories. Plug the Cassette Adapter into the
green AUDIO connector on the PowerConnect Vehicle Dock.
Insert the Cassette Adapter into the vehicle's cassette deck.
• Good: Use the PowerConnect feature in the Xpress RCi . PowerConnect plays the audio through your vehicle's
FM radio. When you have finished step 4 (below), you'll first need to find an available FM channel in your area,
and then you need to ensure that the Xpress RCi and your vehicle's FM radio are tuned to the same available FM
channel. (Step 5)
• Best: Use an FM Direct Adapter. If none of the above three audio connection options works in your vehicle,
you need to use the FM Direct Adapter (FMDA). The FMDA needs to be installed by a professional installer
and directly connects the Xpress RCi to your vehicle's FM radio. To learn more, check with the retailer where you
bought your radio or go to xmradio.ca/accessories.
4

Finish the Installation and Power On

Connect the PowerConnect Power Adapter
Insert the PowerConnect Power Adapter into your vehicle's cigarette lighter or power
adapter socket. Then plug it into the red PWR connector on the rear of the dock.
AUDIO ANT PWR FM OUT Attach the Dock to the Mount
Wire Guide
and the Radio to the Dock
Attach the PowerConnect Vehicle Dock
to the mount that you selected. Utilize
the wire guide at the rear of the dock to
help organize the wire and cables, and
make your installation neater.
Place the Xpress RCi into the dock. Press
the Power button to turn it On.
5

PowerConnect

If you have connected the audio in step 3 using the Aux In Cable or Cassette Adapter, continue with step 6.
Tune the Xpress RCi and Vehicle FM Radio to the Same FM Channel
RCi to play it's audio through your
1. Find an Available FM Channel in Your Area
Audio Quality GOOD BETTER BEST
An available FM channel is one that's not being used by an FM radio station in your area. When you
PowerConnect tune your FM radio to an available channel, you should only hear static or silence – not talk or music.
To find an available FM channel:
Cassette Adapter
• Manually tune through your local FM channels on your vehicle's FM radio. Locate and create a list of
Aux In Cable
channels that aren't being used by any FM radio station. Write down the list. Once you have created your
FM Direct Adapter (FMDA)
list of available FM channels, you will need to find the one that provides the best match for Xpress
TIP! You'll need to use the 'Manual' tune function on your vehicle's FM radio to tune through every FM channel
one-by-one. Turn on your vehicle's FM radio. Start at 88.1 and use the 'Manual' tune function on your vehicle's FM
PWR FM OUT
radio to tune through each FM channel one-by-one (88.1 followed by 88.3 etc.) to locate channels that aren't being
used by a local FM radio station. Write down each FM channel that has only static or silence on it, until you reach 107.9.
AUDIO ANT PWR FM OUT 2. Turn the Xpress 's FM Transmitter On.
RC i
a. Turn On the Xpress RC i by pressing the Power button.
b. Press menu.
c. Press the Select button to select Vehicle Mode.
d. Press the Select button to select FM Transmitter
which will turn yellow.
e. Turn the Control knob clockwise to display On and press
the Select button.
3 Tune the Xpress RC i and the Vehicle FM Radio to the Same
FM Channel.
a. Press menu.
b. Press the Select button to select Vehicle Mode.
c. Scroll to highlight FM Channels and press the Select button.
d. Scroll to highlight the storage location (FM-1 to FM-5) you
want to set and press the Select button. You can choose
among the following options:
i. If the chosen storage location is empty (denoted by "---"),
AUDIO ANT PWR FM OUT
or if the storage location contains the FM preset currently being used (denoted by "Current"),
then a list of FM channels is displayed.
ii. If the chosen storage location has an FM preset that is not currently being used, and you want to
edit it, scroll to highlight Edit Channel and press the Select button to see the list of FM channels.
iii. If the chosen storage location has an FM preset that is not currently being used, and you want
to start using it, press the Select button to select Start Using. Skip to step 7.
e. Scroll to highlight the desired FM channel from the list and press the Select button.
97.9
MATCH FM CHANNELS
PowerConnect
(continued)
f. If you are editing the storage location that has the "Current"
FM channel, skip to step 7. Otherwise press the Select button to
select Start Using.
TIP! You can also preset a new FM preset in a storage location without
having to start using it right away. Just press menu and exit the screen.
g. The chosen FM channel will be confirmed on the display screen
and the Xpress RC i will tune to that FM channel. Press the Select
button to continue.
h. Set your vehicle's FM radio to same FM channel.
RCi
.
4.
IMPORTANT! You'll first need to find an unused FM channel that is
available in your area.
6

Activate

Activate Your Service
Before you can enjoy Commercial-Free Music, plus Sports, News, Talk & Entertainment, you need to activate
your Xpress RCi .
1. Make sure your Xpress RCi is properly installed and receiving the XM signal so that you can hear the
audio on channel 1.
2. Make a note of your XM Radio ID. You can find it on channel 0, on a label on the bottom of the gift
box, and on the label on the back of your Xpress RCi .
TIP! If the signal reception is
NOTE! The XM Radio ID does not use the letters I, O, S, or F.
low, check to see if the
antenna's view of the sky is
3. Activate your service: blocked by a tree, a building, a
bridge, or by anything on the
• Online: Go to www.xmradio.ca and click on "ACTIVATE vehicle roof such as a roof rack
or luggage container, etc. Adjust
RADIO" in the top right corner
until you are receiving a good
OR signal. Press menu, turn the
• By phone: Call 1-877-GET-XMSR (1-877-438-9677) Control knob to scroll to and
highlight Signal Indicator. Press
the Select button to display the
TIP! You can follow the built in activation Signal Indicator screen.
wizard in your Xpress RCi . If your radio has not Welcome
Signal Indicator
been activated, press menu and the first item The next few screens will help
you activate your satellite radio.
in the list will be Activate Radio. Press the
Please press Select to continue SATELLITE
Select button. A series of screens will guide with the activation of your radio,
you through the activation process. Follow the or press menu to cancel
activation at this time.
instructions on each screen. Press the Select TERRESTRIAL
Press Select to continue
button to advance to the next screen, or
menu to cancel the activation process.
4. When your service is activated, your Xpress will receive all channels to which you have
RCi
subscribed. At this time, if you turn the control knob, you can scroll and tune into other channels.
Activation usually takes 10 to 15 minutes, but may take up to an hour. We recommend that your
radio remain on until activated.
