DC-310 series SCSI Adapter
Introduction
The DC-310 series has two adapters: DC-310U, an Ultra-SCSI adapter based on the
Symbios Logic SYM53C860 SCSI Chip, and DC-310, a Fast SCSI-2 adapter based on
SYM53C810 SCSI Chip. Designed to provide a low cost, easy to implement SCSI solution,
this adapter utilises the built-in Symbios Logic SCSI BIOS (SDMS BIOS version 4.x) on
supported mainboards, such as Tekram P5 VX/TX and P6/Pentium_II series.
Fully Plug & Play and PCI 2.1 compliant, enhanced SCSI features include
Disconnect/Reconnect, Scatter/Gather, and Tag Queuing to greatly improve overall system
performance, particularly under multitasking environments.
Jumper-less hardware design, Active SCSI Bus Termination, and 32-bit PCI DMA Bus
Mastering are a few more of the advanced features built-in to the DC-310 series adapters,
providing the best performance and ease of use possible
Checklist
This manual
l
Symbios SDMS 4.1 driver diskettes (3)
l
Disk #
Disk1:
1.
DOS
2.
OS2
Disk2:
1.
Win95
2.
NT 3.5x/4.x
Disk3:
1.
NetWare
2.
DOS Utilities
Drivers for SCO Unix 5.0 and UnixWare 2.x are available via our website at
l
http://www.tekram.com
Specification
SCSI Performance
SCSI Chip: • Symbios SYM53C860 (DC-310U) or SYM53C810 (DC-310)
SCSI devices: • Max: 7
SCSI bus transfers: • DC-310U => Async: 7MB/sec & Sync: 20MB/sec
Bus master data
transfers:
• DC-310 => Async: 5MB/sec & Sync: 10MB/sec
• 132MB/sec (at 33MHz)
• 80-byte DMA FIFO for 2/4/8/16 dwords burst across PCI bus
Quick Reference Guide (rev 2.2)
.
50-pin internal SCSI cable
l
Installation
1.
\DOS\DOS.TXT (for both DOS & Win 3.1)
2.
\OS2\OS2.TXT
1.
\WIN95\WIN95.TXT
2.
\WINNT\8XXNT.TXT
1.
\NETWARE\DDFS\NET_DDFS.TXT
2.
ASPIFMT.EXE
CONFIG.EXE
Tekram Technology Co., Ltd
1
Advertisement
Table of Contents
Related Manuals for Tekram Technology DC-310 series
Summary of Contents for Tekram Technology DC-310 series
- Page 1 Jumper-less hardware design, Active SCSI Bus Termination, and 32-bit PCI DMA Bus Mastering are a few more of the advanced features built-in to the DC-310 series adapters, providing the best performance and ease of use possible...
- Page 2 DC-310 series SCSI Adapter Quick Reference Guide (rev 2.2) PCI Integration • Full 32-bit PCI DMA bus master • Jumper-less design • Active SCSI bus termination (* DC-310: optional) ∗ Termination is required for both ends of a SCSI bus.
- Page 3 DC-310 series SCSI Adapter Quick Reference Guide (rev 2.2) Adapter Utilities Menu When you select a host adapter from the main menu, the following screen is displayed: • Adapter Setup: views and changes the selected adapter settings. SCAM Support - SCAM (SCSI Configured AutoMatically) is the SCSI Plug and Play protocol supported by this Symbios BIOS version 4.X.
- Page 4 DC-310 series SCSI Adapter Quick Reference Guide (rev 2.2) Read Write I/O Timeout (secs) - This option sets the time the host adapter waits for a read, write, verify, or seek command to complete before trying the I/O transfer again. Since this provides a safeguard allowing the system to recover if an I/O operation fails, it is recommended that you always set the time-out to a value greater than zero (no time-out).
