Tecnet TJ-3100V User Manual

Tj-3000 series vhf/uhf professional radio
Hide thumbs Also See for TJ-3100V:
Table of Contents

Advertisement

Quick Links

11535 W. 83rd Terrace, Lenexa, KS 66214
Toll-Free: 800-456-2071 (US Only), 913-859-9515 (Outside US)
Website: www.tecnetusa.com
Printed in Korea
Rev.120605C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TJ-3100V and is the answer not in the manual?

Questions and answers

Related Manuals for Tecnet TJ-3100V

Summary of Contents for Tecnet TJ-3100V

  • Page 1 11535 W. 83rd Terrace, Lenexa, KS 66214 Toll-Free: 800-456-2071 (US Only), 913-859-9515 (Outside US) Website: www.tecnetusa.com Printed in Korea Rev.120605C...
  • Page 2 VHF/UHF Professional Radio TJ-3000 Series TJ-3000 Series User Manual User Manual TJ-3100V (VHF) TJ-3400U (UHF) 11535 W. 83 Terrace, Lenexa, KS 66214...

  • Page 3: Fcc Regulations

    Federal law prohibits you from making any internal adjustments to the transmitter, and / or from changing transmit frequencies unless you are specifically designated by the licensee. If your radio equipment fails to operate properly, contact your authorized dealer or TECNET INTERNATIONAL.

  • Page 4: Table Of Contents

    www.tecnetusa.com www.tecnetusa.com Table of Contents 1. Controls & LCD Display 2. Operation of the TJ-3000 Series Radio 3. Battery Installation 4. Recharging Battery 5. Function & Operation 6. Frequency Charts 7. CTCSS and DCS Code Tables 8. For Safe Operation 9.

  • Page 5: Controls & Lcd Display

    1. Controls & LCD Display Antenna Power ON/OFF, Volume Switch LED Status PTT Button Belt Clip Speaker Jack Mic Jack Menu (P) LCD Display Monitor (M) Channel Down ( ) Call / Enter ( Channel Up ( ) Power ON/OFF Volume Switch Battery Locker Antenna Connector...

  • Page 6: Operation Of The Tj-3000 Series Radio

    www.tecnetusa.com 2. Operation of the TJ-3000 Series Radio 1. Power on/off, Volume control switch Turns the radio on and off, and adjusts audio volume level. 2. PTT (Push-To-Talk) Radio transmission button 3. Menu Button (P, Program-Menu Button) Pressing for more than 1 second, the radio will be entered into Menu programming mode. Repeated presses of the (P) button will advance the menu as follows: Tone SCAN...

  • Page 7: Battery Installation

    3. Battery Installation Please read the user manual carefully before using TJ-3000 Series radio. This user manual contains important and useful information about the radio. Battery installation and Removal To install battery, slide up the battery pack towards top of the radio until battery latch is locked. To remove the battery, slide the battery latch located on the bottom of the radio to the open position as shown in the figure 3-1.

  • Page 8: Recharging Battery

    (1) The battery pack of TJ-3000 Series radios has high performance and reliability. This battery pack has been designed for included and optional chargers offered. (2) Do not charge the battery with non TecNet chargers. Using non Tecnet charger will cause damage to the battery pack and the radio.

  • Page 9: Function & Operation

    5. Function & Operation Function Button & LED status LCD Display Power on/off Power on/off, Volume switch PTT button Transmit (TX) Red LED Receive (RX) Green LED Up ( ) / Down ( ) button Channel Selection To start Scan, Menu (P) + Enter ( Scan To end Scan, Just press Menu (P) button Short time monitor : Press monitor...
  • Page 10 www.tecnetusa.com 5.1 CTCSS/DCS/DCS Invertor sub-tone channel selection: Press Menu (P) button for more than 1 second and the radio will go into function setting mode. Press UP ( ) or DOWN ( ) button to select Type of Sub-Channel. CTCSS Sub-Channel : ( ) DCS Sub-Channel : ( ) DCS Inverter Sub-Channel : ( ) No setting Sub-Channel : ( )
  • Page 11 Home Channel. Simply press PTT while the radio is scanning and the radio will transmit on channel 10). To disable scan, press Menu (P) button. Additional scanning features are available through programming software. Please contact TecNet or an Authorized TecNet Dealer for additional information. 5.4 Beep Tone On/Off selection: Press Menu (P) button for more than 1 second and the radio will enter into function setting mode.
  • Page 12 www.tecnetusa.com 5.7 Roger Beep On/Off selection: Press Menu (P) button for more than 1 second and the radio will enter into function setting mode. Press Menu (P) button 6 times. Radio will go into Roger beep on/off setting mode. By pressing UP ( ) or DOWN ( ) button will select on or off. To confirm your selection, press Enter ( ) button.

  • Page 13: Frequency Charts

    6. Frequency Charts VHF Frequency Charts TecNet TJ Series Model TJ-3100V VHF Radio Transmit (TX) Receive (RX) Output Bandwidth Frequency Frequency Power Channel 151.6250 151.6250 151.9550 151.9550 152.8850 152.8850 152.9150 152.9150 151.7000 151.7000 151.7600 151.7600 152.9450 152.9450 151.8350 151.8350 151.8050 151.8050...
  • Page 14 UHF Frequency Charts TecNet TJ Series Model TJ-3400U UHF Radio Transmit (TX) Receive (RX) Output Bandwidth Frequency Frequency Power Channel 464.5000 464.5000 464.5500 464.5500 467.7625 467.7625 467.8125 467.8125 467.8500 467.8500 467.8750 467.8750 467.9000 467.9000 467.9250 467.9250 461.0375 461.0375 461.0625 461.0625...
  • Page 15 UHF Frequency Charts TecNet TJ Series Model TJ-3400U UHF Radio Transmit (TX) Receive (RX) Output Bandwidth Frequency Frequency Power Channel 466.1875 466.1875 466.2125 466.2125 466.2375 466.2375 466.2625 466.2625 466.2875 466.2875 466.3125 466.3125 466.3375 466.3375 466.3625 466.3625 467.7875 467.7875 467.8375 467.8375 467.8625...
  • Page 16 Weather 5 162.4500 button Weather 6 162.5000 Weather 7 162.5250 Note: Channels indicated for models other than TecNet TJ-3000 Series are for reference only. Devices FCC type accepted after January 1, 2011 are narrow band only of which TJ-3000 Series applies.

  • Page 17: Ctcss And Dcs Code Tables

    7. CTCSS and DCS Code Tables Sub -Tone Table CTCSS Frequency Table No. Frequency No. Frequency No. Frequency No. Frequency No. Frequency 67.0 107.2 167.9 159.8 64.7 71.9 110.9 173.8 183.5 74.4 114.8 179.9 189.9 77.0 118.8 186.2 196.6 79.7 123.0 192.8 199.5...

  • Page 18: For Safe Operation

    www.tecnetusa.com 8. For Safe Operation Don’t transmit with antenna detached from the radio or don't damage or change antenna type. Strong electronic waves are emitted from the radio and damages or changes to the antenna may effect the performance of the radio, and it may cause the radio to be defective and not covered under warranty.

  • Page 19: Warranty Statement

    Authorized Repair Depot. The user is responsible for the removal of the product from a vehicle or any equipment attached to it, or other site of its use; transportation of the product to the Authorized TecNet Dealer; for the return of the repaired or replacement product to the site of its use and for the reinstallation of the product.
  • Page 20 www.tecnetusa.com Replacement Parts TJA-1800LI Battery - 1800 mAh Lithium lon TJA-341 Antenna - VHF TJA-342 Antenna - UHF TJA-300L Charger - Rapid Rate TJA-30BC Belt Clip Optional Accessories ACC-600TJ3 Vehicular Charger - Single Unit ACC-6110TJ3 Charger - 6 Unit Gang Charger TA-836X Speaker Microphone - Standard TA-850X...
