Blazee technology BM3030 User Manual

High definition hdd multimedia player
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

USER MANUAL

High Definition
HDD Multimedia Player
BM 3030
Feature
Installation Guide
Management Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BM3030 and is the answer not in the manual?

Questions and answers

Summary of Contents for Blazee technology BM3030

  • Page 1: User Manual

    USER MANUAL High Definition HDD Multimedia Player BM 3030 Feature Installation Guide Management Guide...

  • Page 2: Table Of Contents

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l CONTENTS 1. Before You Get Started...……………………………………………………………………………..……………. 3 1.1 S ……………………….……………………………………………….………………...3 AFTY NSTRUCTION...
  • Page 3 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l 3.6.6 C ………………………………………………………………….….51 HANGING ETWORK ETTINGS 3.7 Browser Menu………………………………………………………………………………………………... 53 3.7.1 B …………………………………………………………………………………..55 ...

  • Page 4: Before You Get Started

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l 1. Before You Get Started 1.1 Safety Instruction 1.

  • Page 5: Take A Look To The Media Player

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l 1.2 Take a look to the Media Player BM3030 Front Panel Rear Panel...

  • Page 6: Specification

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l 1.3. BM3030 Specification: ■ Hardware Spec Feature Description Main Board Main Chipset...
  • Page 7 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Software Spec Feature Description Video MPEG1 (dat, mpg), MPEG2 (vob, mpg, ts), MPEG4 (avi, divx, xvid),mkv, iso, High Definition Video Playback ifo up to 1080i output FF/FR: 1.5, 2, 4, 8, 16, 32x...

  • Page 8: Video Recording Mode

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Feature Description One Touch Record Record to FAT32 HDD Recording Quality Adjustable HQ/SP/LP/EP/SLP Recording...

  • Page 9: Package Contents

    M u l t i m e d i a P l a y e r U s e r M a n u a l 1.4 BM3030 Package Contents: Multimedia-Player Unit x 1 DC Power Adapter x 1 AV Cable x 2 -(RCA x3 , 3 IN 1)

  • Page 10: Easy Installation Guide

    M u l t i m e d i a P l a y e r U s e r M a n u a l 2. BM3030 Easy Installation Guide 2.1 Front / Back Panel Power LED Recording LED...
  • Page 11 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Co-axial Output Fiber Optical Output HDMI Power ON/OFF Mini USB b AV_IN Cooling Fan...

  • Page 12: Hardware Installation

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l 2.2 Hardware Installation Install a Hard Disk Drive for the Device 1.
  • Page 13 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l 2. Place the Hard Disk drive evenly on the hard disk drive base. Slide the Hard Drive to connect to the connector (cable) on the device.
  • Page 14 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l 3. Secure your hard disk with the included screws in the package.
  • Page 15 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l 4. Push tray into Aluminum housing and screw the two pieces together.

  • Page 16: Using Media Player

    P l a y e r U s e r M a n u a l 3. Using BM3030 Media Player 3.1 Remote Control All procedures in this manual can be carried out using the remote control buttons. Certain functions can also be carried out using the front panel at the front of the Multi media Player.
  • Page 17 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Button Function POWER button: Press to POWER on or off the AV HDD recorder. DISPLAY button: Press to display current status.
  • Page 18 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l BROWSER button: Press to browse the music, photo, movie and all files on USB or HDD. STOP button: Press to stop playback.
  • Page 19 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l REPEAT buttons: Press REPEAT 1 / ALL to set repeat option - Chapter, Title or Off. ZOOM button: Press to zoom in/out when playing back photos or Video programs.
  • Page 20 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l TIMER button: Press to enter the Timer Menu directly to add, edit and delete recording schedules. See “Creating a New Schedule”...
  • Page 21 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l PAUSE / STEP button: Press to pause the current playback. Press again to step to the next frame.
  • Page 22 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l TV SYSTEM button: Press to switch between NTSC Interlaced, NTSC Progressive, PAL Interlaced, and PAL Progressive.

  • Page 23: Getting Started

    U s e r M a n u a l 3.2 Getting Start Power on the BM3030 Multimedia player system, you will see the start-up page. After few seconds, the menu will be displayed on your TV. To enter the menu, press...
  • Page 24 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Selecting Video In To select an input source, select Video In button on the guide menu page. Selecting file Copy A video clip recorded in HDD or USB disk is called a Title.

  • Page 25: Selecting Browser

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Selecting Browser Select Browser button on the guide menu page to browse movie, photo, and music files stored either in a HDD, USB, card reader, NET or a USB device.

  • Page 26: Selecting Time Rec

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Selecting Time REC on the remote control or select Timer REC button on the guide To enter the Time REC setup page, select menu page.

  • Page 27: Format Hard Disc

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l 3.3 Format Hard Disc When you install a hard disk in the system at the first time, the system will remind you to enter the hard disk  format interface. You can also press    into Setup menu and select HDD Format to Format HDD.  First, a “Warning”...
  • Page 28 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Step 1: Please adjust the hard disk capacity according to the information on your TV screen. to adjust the Fat32 and NTFS partition.
  • Page 29 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Step 2: Hard disk format Press on the remote control to select “Back” or “Format”. When the Format button highlighted, press to start.
  • Page 30 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Step 3: Congratulation page When complete the format, the system will display the congratulation page. Select OK button and press to exit.

  • Page 31: The Rec List

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l 3.4 The REC List The REC List menu allows you to play all saved titles. REC List Menu When you press to begin to record, system will make a “My Recordings”...

  • Page 32: Timer Record Menu

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l 3.5 Timer Record Menu The Timer Record menu allows you to create, edit and delete recording schedules and view all schedule  status and history. To enter the menu, select Timer Record from the Guide menu. 3.5.1 Creating a New Schedule on the remote control to select the Edit tab from the menu bar.
  • Page 33 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Start Time Enter the date and time of the recording. Length Enter the length of the recording Repeat...

  • Page 34: Editing Schedules

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l 3.5.2 Editing Schedules Press on the remote control to select the Edit tab from the menu bar. Select the schedule you want to edit from the list and press The schedule setting screen appears.

  • Page 35: Deleting Schedules

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l 3.5.3 Deleting Schedules on the remote control to select the Delete tab from the menu bar. Press Select the schedule you want to delete and press .

  • Page 36: Viewing Schedule Status Viewing Schedule Status

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l 3.5.4 Viewing Schedule Status Viewing Schedule Status on the remote control to select the Schedule tab from the menu bar. Press The schedule list is displayed.

  • Page 37: Viewing Recording History

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l 3.5.5 Viewing Recording History Press the left and right navigation arrows on the remote control to select the History tab from the menu bar. Here you can view a complete history of all recordings that were set.

  • Page 38: Setup Menu

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Setup Menu The Setup Menu allows you to configure video, record and system settings. To enter the menu, select Setup from the Guide menu.

  • Page 39: Menu Language

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Select to choose the OSD (On Screen Display) language. Menu Language Press to select the language.
  • Page 40 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Select to set the system time. Time Press and enter Manual setup.

  • Page 41: Hdd Format

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Select to HDD Format. HDD Format button on the remote control to select Cancel or Press CONFIRM from the menu.

  • Page 42: Changing Video Settings

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l 3.6.2 Changing Video Settings on the remote control to select the Video tab from the menu bar. Press Select to set aspect ratio.
  • Page 43 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Select to set brightness levels. Brightness Press to adjust brightness. The new setting is previewed onscreen. Press to confirm.
  • Page 44 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Select to adjust TV system. TV System When insert HDMI TV, TV System only choose Auto EDID, 480P, 576P, 720P 50HZ, 720P 60HZ and 1080i 60HZ.

  • Page 45: Night Mode

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l 3.6.3 Changing Audio Settings on the remote control to select the Audio tab from the menu bar. Press Select to toggle Night Mode on and off.
  • Page 46 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Select to set Digital output type. Press to select from HDMI and SPDIF RAW or LPCM. S/PDIF (Sony/Phillips Digital Interface Format) carries digital audio signals between the DVD recorder and other component devices, such as a home theater setup with surround sound.

  • Page 47: Changing Record Settings

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l 3.6.4 Changing Record Settings on the remote control to select the Record tab from the menu bar. Press Quality Select to set the default recording quality setting.
  • Page 48 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Select to set the Permanent time shift on or off. Permanent time shift Press to select.

  • Page 49: Changing Photos Settings

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l 3.6.5 Changing Photos Settings on the remote control to select the Photos tab from the menu. Press Select to set slide show time.

  • Page 50: Transition Effect

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Select to set the transition effect of photos. Transition Effect Press to select the transform of photo you require:...

  • Page 51: Background Music

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Select to play the music file under the same folder. Background Music Press to select the position of the background music.

  • Page 52: Changing Network Settings

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l 3.6.6 Changing Network Settings on the remote control to select the Network tab from the menu. Press Select to set the Network Setting.
  • Page 53 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l DHCP DNS(AUTO) Set the DNS server IP address by auto. Press to confirm.

  • Page 54: Browser Menu

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l 3.7 Browser Menu The Browser menu allows you browse and play music, photo and movie files stored on a HDD or an external USB device and Card reader, Network.
  • Page 55 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l My Short Cut When you are browsing NET, you can choose the PC name from the menu or you can set “Specific File Server IP” and access it from “My Short Cut”...

  • Page 56: Browsing Music

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l 3.7.1 Browsing Music Use the left and right navigation arrows to select the Music tab. Press to select the folder containing your audio files.

  • Page 57: Browsing Photos

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l 3.7.2 Browsing Photos Use the left and right navigation arrows to select the Photos tab. Note: 1.

  • Page 58: Browsing Movies

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l 3.7.3 Browsing Movies Use the left and right navigation arrows to select the Movies tab. Note: When play the HD Video, you can adjust HD Video output to as same as movie resolution.

  • Page 59: Browsing All

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l 3.7.4 Browsing All Use the left and right navigation arrows to select the “All” tab. Press to select the folder(s) containing your all files (Beside Music, Photo and Movie).

  • Page 60: File Edit Menu

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Press to select the file or folder, press to display the Edit tab.
  • Page 61 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Return Select to return to the main screen. Rename To rename a file, do the following steps: 1.
  • Page 62 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Delete To delete a title, complete the following steps: on the remote control to select the Delete tab from the menu bar.

  • Page 63: File Copy Menu

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l File Copy Menu The Setup Menu allows you to copy files among NET, USB and HDD. To enter the menu, select File Copy from the Guide menu or select on the remote control.

  • Page 64: Step 1. Select Source Device

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Step 2. Select Destination Device When enter into Destination sector, press to select the device of the Destination.

  • Page 65: Step 3. Select Copy Files Or Folders

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Step 3. Select copy files or folders At “Source” sector, press to select and press “Enter”...

  • Page 66: Step 4. Select The Folders Of Destination

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Step 4. Select the folders of Destination At “Destination” sector, press to select a folder of the "Destination".
  • Page 67 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Step 5. Copy Status At “Pop” menu, select OK to copy, select No to cancel. When copy succeeds, the system will display “File Copy Completed!”;...

  • Page 68: Utilities

    B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l 4. Utilities Transcode Server Transcoding on PC (RM, RMVB, WMV, H.264...) and real-time streaming playback via network. Please follow the instructions to install the software.
  • Page 69 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Step 2: “Next” Step 3: “Browser folder”...
  • Page 70 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Step 4: “Install” Step 5: “Copying new files”...
  • Page 71 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Step 6: “Finish”-You can start use the software.
  • Page 72 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Run the software Step 1: Double click to run the program. You can enter the software page. Step 2: Transcode Status: Transcoding information.
  • Page 73 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Net Share Dialog: Step 3: Add your files on PC (RM, RMVB, WMV, H.264...) and real-time streaming playback via network...
  • Page 74 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l Setting: EventLog: Auto Run System Starup “Yes” or “No”. Event log is helpful for troubleshooting...
  • Page 75 B M 3 0 3 0 M u l t i m e d i a P l a y e r U s e r M a n u a l About: Transcode server Version information. M0-90-475G...
