Summary of Contents for Intellux D-422
-
Page 1: Quick Guide
Stand Alone Type DVR SYSTEM QUICK GUIDE (HDD, CDRW, USB) Revision Date : 2006. 06. 01. - Page 2 1 Hard Disk & CD-RW Install Guide (PART1) 1. Jumper Setup 2. Bracket Install 3. Install Complete ->1 ea : MASTER (IDE1) ->2 ea : MASTER,SLAVE (IDE1) ->3 ea : MASTERx2, SLAVEx1 (IDE1, IDE2) 1. Jumper Setup 2. Bracket Install 3.
- Page 3 1 Hard Disk & CD-RW Install Guide (PART2) Selection Cable & Jumper Setup ① HDDx1 : HDD (Jumper MASTER) + IDE1 Cable + MASTER ② HDDx2 : HDD (Jumper MASTER) + IDE1 Cable + MASTER HDD'(Jumper SLAVE) + IDE1 Cable + SLAVE ③...
- Page 4 Hard Disk & CD-RW Install Guide (PART3) 1. Power On 2. New Detected Hard Disk Format 3. System Start (Initial View) (Select By Play, Reverse Play Key) ※ If do not format newly detected hard disk, it’s the same situation as no hard disk. If install new hard disk, please do format.
-
Page 5: Basic Connection
2 Basic Connection ALARM RELAY CAMERA WITH CONNECTION CONNECTION MICROPHONE (AUDIO INPUT) VGA CONNECTION PORT CAMERA (COMPUTER MONITOR) ① POWER (DC 12V) AUDIO OUTPUT (AV MONITOR) ETHERNET CONNECTION RS-485 CONNECTION (LAN) (PTZ CAMERA CONTROL) CONNECTOR (AV MONITOR) - Page 6 Warning! Please use Hard Disk Possible to Supply Higher than UDMA66 Recommended CD-RW is LG (Model : GCE-8526B,GCE-8527B). SAMSUNG (Model : SW-252F, TS-H292A, SH-522C). ASUS (Model : CRW-5232AS), GIGABYTE (Model : GO-R5232B). HDD & CD-RW installation - 3 X HDD with standard DC Adaptor - 4 X HDD with optional SMPS -2 X HDD + 1 X CD-RW Recommended USB Memory stick ,USB HDD is...
