Summary of Contents for Fillmaster Systems, LLC Fillmaster Filtration
- Page 1 INSTALLATION INSTRUCTIONS AND SERVICE GUIDE ® FILLMASTER FILTRATION GIVE THIS TO PHARMACY MANAGER ® FILLMASTER SYSTEMS, LLC www.fillmastersystems.com 619-596-9900 FAX 619-596-8700 TOLL FREE 1-888-284-7873 PO BOX 711537 SANTEE, CA 92072-1537...
-
Page 2: Important Information
® Fillmaster Pharmacy Water Purification and Dispensing System Installation Instructions and Service Guide ® Model Fillmaster Filtration Assembly with Model FMD 3400, 3600 , and 2600 dispenser IMPORTANT INFORMATION ® Welcome to the Fillmaster Family! This illustrated guide contains step-by-step instructions and service information to facilitate installation and continued life of your new system. - Page 3 CONDITIONS FOR USE This Reverse Osmosis (RO) Pharmacy Water Purification and Dispensing System has been designed for serviceability and ease of installation and constructed with the finest materials available. Using these guidelines and paying close attention to the parameters outlined within the “conditions for use” will ensure a successful installation. To insure the system continues to operate at the optimum level, it is necessary to have a routine maintenance and replacement schedule.
-
Page 4: Parts List
PARTS LIST Use the following list of components to ensure that all parts are included with your system while familiarizing yourself with the items before installation. Part Number Description FAUC1360 Air Gap Faucet FITT2206 Faucet Adapter 3/8” x 7/16” TANK1400 Water Storage Tank (reservoir) ®... - Page 5 PARTS LIST (continued) Part Number Description TIPP2310 Dispensing Tip Package ANCH2301 Hallow Blue Wall Anchors ® SCRE1300 Fillmaster filltration Mounting Screws SCRE2303 Dispenser Mounting Screws SCRE2304 Dispenser Assembly Screws CABL2302 Dispenser Tubing Staples Installation Hardware Bag Contents ® OTHER FILLMASTER PRODUCTS ®...
- Page 6 PRELIMINARY INSTALLATION STEPS 1. Examine the cold water feed line, usually located underneath the pharmacy sink. You will be installing an In-Line Adapter and Ball Valve on the cold water line. ® ® 2. Determine the location for the Fillmaster Filtration System.
-
Page 7: Installation Instructions
INSTALLATION INSTRUCTIONS Installing the In-Line Adapter and Ball Valve 1. Turn off the cold water under your sink by rotating the cold water supply valve in a clockwise direction. If you are not sure which is the cold water, run both taps, then feel the tubing. The hot water feed will be noticeably warmer. - Page 8 Installing the Drain Line Adapter 1. Open and verify the DLA-12 Drain Line Adapter parts. Description Slip-Joint Nuts Beveled Washers 3-Way Repair Tee Adapter 2. Check the drainpipe directly below the sink drain. Make sure that you have at least 4” of vertical pipe between sink drain and the trap.
- Page 9 ® Installing the Air Gap Faucet and Fillmaster Filtration Unit 1. IMPORTANT: Installation of the air gap faucet is not optional. It must be installed. The air gap faucet is the systems' means of drain water backflow prevention. If you have a knockout hole in your sink the Air Gap Faucet will fit there.
- Page 10 ® Installing the Fillmaster FMD 2600 Dispenser ® 1. Assemble the Fillmaster Dispenser by joining the lower and upper part of the dispenser together with the two #10 x ½” FH metal screws. 2. Ask the pharmacist where he or she would like the dispenser mounted.
- Page 11 Final Tubing Connections (continued) 5. Connect the 1/4” tubing from the dispenser to the "T" connector between the 3/8” blue tubing. NOTE: Systems with the FMD 3400 and 3600 dispenser : Connect the ¼” tubing form the dispenser to the regulator that is connected to the “T”...
- Page 12 ACTIVATING THE SYSTEM CAUTION: Make sure all water supply lines, drain lines, and fittings are secure and free from leakage. 1. Open source water supply valve. Close product water faucet. Check for leakage. 2. Turn tank valve one-quarter turn counter-clockwise to open valve (handle should be in line with tubing as it enters connection).
- Page 13 RECOMMENDED ROUTINE MAINTENANCE To insure the system operates at its maximum efficiency level, the following routine maintenance must be performed: Test your system frequently using the AquaScan button. The AquaScan monitor does not indicate when the filters should be changed, it does measure the integrity of the product water and the membrane. To accurately test using the AquaScan button, the system must be in the "make-water"...
- Page 14 Cleaning and Sanitizing the System During a Filter Change 1. Mix a mild cleaning solution of dish soap and water. 2. Turn off the cold water supply and open the Air Gap Faucet. Lock the faucet in the open position by lifting the lever to the full-up position. This will empty the storage tank and relieve pressure in the system.
- Page 15 TROUBLE SHOOTING GUIDE Symptom Probable Cause Solution Excessive slack in drain tubing (new Cut off excess tubing (*Tubing #1) so that Leak from Air Gap Faucet system) tube runs "downhill" to drain 3/8" blue tube (*Tubing #2) to plastic Tubing connections to air gap faucet fitting on very bottom of faucet, 1/4"...
- Page 16 TROUBLE SHOOTING GUIDE (CONTINUED) Symptom Probable Cause Solution Low usage or non-usage Drain one quart of water from auxiliary Yellow Service Light on Aquascan NOTE: The AquaScan monitor does not faucet. Wait 10-15 minutes and Monitor check filter condition (see Routine retest.
- Page 17 WARRANTY ® Subject to the conditions and limitations described below, FILLMASTER SYSTEMS, LLC warrants its ® ® Fillmaster System, Model FMF (Fillmaster filtration) Reverse Osmosis Water Purification Unit and ® Model FMD-2600, 3400 and 3600 Fillmaster Dispenser to be free from defects in materials and workmanship under normal use within the operating specifications listed below.
- Page 18 MAINTENANCE SCHEDULE Date system installed: Filters Replaced Membrane Replaced Other Services Performed ___________________ Date Date Date Serviced Performed Notes:...
- Page 19 PRODUCT REGISTRATION This form must be returned within 10 days of installation or warranty will not be valid Company Store Number Pharmacy Owner / Manager Address City State Pharmacy Phone Installation Date Filtration Serial Number (label on the back of the filtration system hood) 3400 or 3600 Serial Number Script Scanner Bar Code Reader? Yes I certify that I have received the installation manual, including the warranty information and service...
- Page 20 FILLMASTER® SYSTEMS, LLC 619-596-9900 FAX 619-596-8700 TOLL FREE 1-888-284-7873 www.fillmastersystems.com PO BOX 711537 SANTEE, CA 92072-1537 Fillmaster® Installation Manual 950 Rev. JUNE 2006...
