Unit Description: Argus Switched Mode Battery Reverting Charger
Manual P/N: 010-519-C0
# Date Page#
1 03-06-11 All
2 2
The Argus Battery Reverting Charger must be used with a load that has its own internal power supply. The charger is
not intended to power the load directly.
A complete system consists of the Argus Battery Reverting Charger, batteries, load with power supply, and an AC
source. The system provides a separate charging source and automatic-revert to a battery bank in the event of
an AC power interruption. The Argus Battery Reverting Charger system interfaces with the load's normal supply
source (or the standard power supply).
The internal supply will supply the load under normal conditions. In the event that the AC source has failed, the
charger initiates a transfer process whereby the battery is connected to supply the load (see Features and
Operation sections).
3 2
Figure 1–Front view of Battery Reverting Charger (010-519-20 typical)
Figure 2–Front panel of 12V 20A Battery Reverting Charger (010-519-20)
Authorized by:
MANUAL ADDENDUM
Applies to Manual Revision: A
Line# Correction to be implemented
Any Change "Battery Charger" to "Battery Reverting Charger"
9 Insert the following (under General/Introduction):
9 Insert Figures (below):
