Litemax Electronics LD1544 User Manual

Sunlight readable 15 " lcd display
Hide thumbs
Table of Contents

Advertisement

Quick Links

LITEMAX LD1544/1548
Sunlight Readable 15" LCD Display
(1st Edition 7/28/2004 )
All information is subject to change without notice.3
LITEMAX
Electronics Inc.
4F, No.131-3, Lane235, Bau-chiau Rd.,
Shin-dian City, Taipei County, Taiwan R.O.C.
Tel : 886-2-8919-1858
Fax: 886-2-8919-1300
Homepage:
http://www.litemax.com.tw
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LD1544 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Litemax Electronics LD1544

Summary of Contents for Litemax Electronics LD1544

  • Page 1 LITEMAX LD1544/1548 Sunlight Readable 15" LCD Display (1st Edition 7/28/2004 ) All information is subject to change without notice.3 LITEMAX Electronics Inc. 4F, No.131-3, Lane235, Bau-chiau Rd., Shin-dian City, Taipei County, Taiwan R.O.C. Tel : 886-2-8919-1858 Fax: 886-2-8919-1300 Homepage: http://www.litemax.com.tw...

  • Page 2: Table Of Contents

    Content Introduction ...................... 3 Hardware Installation..................3 The Display Timing................... 5 The Display Outline Dimensions............... 6 The Display Controls..................7 The Screen Adjustment ..................8 Troubleshooting Tips ..................10 Specification....................11 Product Safety Precautions................12 Page 2...

  • Page 3: Introduction

    Introduction Welcome to enjoy the fantastic sightseeing world. This new technology will bring you the whole new feeling about the “monitor”. We show here some of the major advantages of the LCD monitor. You will really find some other advantages when you use it. Hardware Installation This chapter will guide you the correct installation procedures of your LCD monitor.
  • Page 4 The following picture provides the connection outline A: POWER B:VGA INPUT C: DVI INPUT D: S-VIDEO INF E: AV INPUT F: TOUCH INPUT Video Input Pin Assignment This section describes the pin assignment of the LCD’ s video connector. It is called 15pin Mini D-sub connector.

  • Page 5: The Display Timing

    The Display Timing Applicable video timing The following table lists the better display quality modes that the LCD monitor provides. If the other video modes are input, the monitor will stop working or display unsatisfactory picture quality. VESA Modes Mode Resolution Total Nominal...

  • Page 6: The Display Outline Dimensions

    The Display Outline Dimensions Unit: mm Page 6...

  • Page 7: The Display Controls

    The Display Controls Membrane Control Button POWER SWITCH: Pushing the power switch will turn the monitor on. Pushing it again to turn the monitor off. Power LED: Power ON-Green / Power off-No. Up Key >: Increase item number or value of the selected item. Menu Key: Enter to the OSD adjustment menu.

  • Page 8: The Screen Adjustment

    The Screen Adjustment Main Menu You can adjust the brightness, contrast, display colors, the horizontal and vertical position of the display and OSD menu, etc. through the main menu display. The Down Key < and Up Key >are used to scroll through items within the menu. The selected item is highlighted as the scrolling move along.
  • Page 9 Menu key function: Color Setup the contrast, brightness and color of the panel. / The Contrast menu item is used to adjust image contrast. Picture Setup the image position within the panel. Function Select auto adjust & auto color function can make the monitor have the best efficiency.

  • Page 10: Troubleshooting Tips

    Troubleshooting Tips In the event that you experience trouble with your Display, check the following items before contacting the dealer from whom the Display was purchased. The most common problems usually involve an incorrectly an incorrect connection from the Video Card to the Display. We recommend that you also consult your Video Card User’...

  • Page 11: Specification

    Specification Model No. LD1544 / LD1548 Display Area 304.128 x 228.096mm LCD Display 15" TFT active matrix Display Colors 262,144 Colors Luminance 800 cd/m2 / 1600 cd/m2 Contrast Ratio 400 :1 (typ.) Resolution 1024 x 768 (XGA) Pixel Arrangement RGB (Red, Green, Blue) vertical stripe Pixel Pitch 0.297(H) x 0.297(V)

  • Page 12: Product Safety Precautions

    Product Safety Precautions Follow all warnings and instructions marked on the product. Do not use this product near water. This display should be installed on a solid horizontal base. When cleaning, use only a neutral detergent cleaner with a soft damp cloth. Do not spray with liquid or aerosol cleaners.

This manual is also suitable for:

Ld1548
