Summary of Contents for Argox PT
- Page 3 PT Series Accessories When you first unpack your PT-Series PDT, please check the contents of the package and compare it to that model’s content list below. The PT-10 and PT-12 models come with different accessories. PT-10 Package Contents �� PT-10 with gray color keypad ��...
- Page 4 A high-performance long range CCD scanner lets you read barcodes from distances up to 13 inches (33cm). The PT Series offer powerful hand-held data capture tools based on bar code scanning technology. These PDTs allow you to collect bar code data from remote locations and store the data until you upload it to a computer system for analysis.
- Page 5 PT Series Accessories When you first unpack your PT-Series PDT, please check the contents of the package and compare it to that model’s content list below. The PT-10 and PT-12 models come with different accessories. PT-10 Package Contents �� PT-10 with gray color keypad ��...
- Page 6 PT-12 Package Contents �� PT-12 with black color keypad �� Charging and communication cradle �� 9-pins to 9-pins RS-232 communication cable �� CD ROM �� Quick Reference Guide (User’s manual) �� 2 x Rechargeable battery pack �� Battery box �� Clip ��...
- Page 7 PT-10 and PT-12 Description RS-232 port Clip Battery slot Battery unlock...
- Page 8 Cradle Description (CRD-10) Front Power (communication) Terminal slot Charging Back Serial and charging port Charging slot USB port RS-232 port Power port...
-
Page 9: Charging Batteries
Only a rechargeable battery pack can be charged using the PDT or using the spare slot. Before using your PT-12 for the first time, charge the NI-MH battery pack for 3 hours using the PDT or using the CRD-10 cradle. -
Page 10: Keypad Description
Keypad Description Scan Key Enter Key Cancel Key Escape Key The PT Series keypad consists of 22 rubber keys including one trigger key. Function Cursor Left Cursor Right Cursor Up Cursor down Confirm entering data Scan Scan Key Alpha Alpha to toggle between alpha and... -
Page 11: Starting The Pdt
Cradle Charging LED Status LED Status (charging->full) Insert terminal No LED display (status only display on PT-12 LCD screen) Insert battery pack Red Flash (Charging) -> Green (Complete charging) Starting the PDT Press the Power button for 2 seconds to power on the PDT. -
Page 12: Data Communication
Data Communication The PT Series portable data terminals let you link to a host computer through an RS-232 cable or through the CRD-10 cradle for data communication. Via RS-232 Cable The PT Series connects directly to a host computer’s serial port via the bundled RS-232 cable (9-pins to 10-pins). -
Page 13: Specifications
Back up power 3V rechargeable Lithium battery Packing RS-232 Cable 9-Pins to 10-Pins 9-pins to 9-pins Battery 2 x AA Alkaline battery Ni-HM battery pack Clip holder Hand strap Cradle Adapter Package Single PT-10 package Complete package w/cradle Developing tools Software ArgoBuilder...
