Summary of Contents for AvediaPlayer r92 series
- Page 1 Getting Started Guide AvediaPlayer r92xx series IPTV Receivers...
- Page 2 Before installing and operating these products, please refer to the safety information the associated installation and operating documentation. The Exterity building IPTV logo, AvediaStream, AvediaServer, AvediaCentre, and AvediaPlayer, are trademarks or registered trademarks of Exterity Limited. All other trademarks are the property of their respective owners. All rights ®...
-
Page 3: Table Of Contents
Models ...................... 6 Basic Configuration ................16 AvediaPlayer r9200 Receiver ............6 Determining the IP address of the AvediaPlayer Receiver ....16 AvediaPlayer r9210 Receiver ............6 Using the Connected TV and Remote Handset ......16 AvediaPlayer r9220 Receiver ............6 Using the AvediaServer Director ........... -
Page 4: Introduction
The AvediaPlayer r92xx series receivers are network devices which display an IP network delivered MPEG transport stream on a television or display. AvediaPlayer Documentation This manual – the AvediaPlayer r92xx Receivers Getting Started Guide – shows you how to perform the first steps of configuring and connecting Exterity AvediaPlayer r92xx series receivers to your TV/display and IP network. -
Page 5: Documentation Conventions
MODE PLAY highlighting is used to indicate an AvediaPlayer receiver on-screen menu display accessed using the Remote Control handset, such as Settings. Bold and grey highlighting - is used for web interface features such as the Apply button. Emphasis is used when referring to another document, for example AvediaPlayer Administrator’s Guide. -
Page 6: About The Avediaplayer R92Xx Series Receivers
Audio: HDMI (8 channel PCM or Bitstream), TOS (2 channel PCM or Bitstream) AvediaPlayer r9200 Receiver The AvediaPlayer r9200 features a single Ethernet port and an HDMI output in a compact form factor and the lowest power consumption of the r92xx series receivers. -
Page 7: Before You Begin
3 Before You Begin This section describes the key considerations required before connecting the AvediaPlayer receiver to a TV and your IP network. Network Considerations The Exterity r92xx receiver is a network device designed to accept IP multicast streams from Exterity TVgateways, Encoders and AvediaServers. -
Page 8: Physical Location
Physical Location AvediaPlayer receivers are typically located close to, or attached to the connected TV or display device. Mounting kits enable you to securely mount any AvediaPlayer r92xx series receiver to a television and display, or to a wall or under a surface such as a desk or shelf. -
Page 9: User Control
IR window is obscured. The IR extender is not supplied with the receiver and must be ordered separately. Note: Operation of the AvediaPlayer receiver when using the User Interface allows typical user functions such as channel selection, volume control, and where configured, browser operation and interaction with middleware . -
Page 10: Connection And Power On
4 Connection and Power On This section shows you how to connect the AvediaPlayer r92xx receiver to your TV, power it on, and ensure it is correctly configured for its connection to your IP network. Connect the AV Outputs Select the connection required for your TV/display and/or audio device: HDMI HDMI –... -
Page 11: Avediaplayer R9210 Only - Component/Composite/S-Video/Analogue Audio
AvediaPlayer r9210 Only - Component/Composite/S-Video/Analogue Audio Component Video – (HD and SD) Use standard phono cables (RCA). Composite Video – (SD only) Use a standard phono cable (RCA). S-Video – (SD only) Use a standard S-Video cable. Analogue Audio – Analogue audio 1 volt peak-to-peak maximum. -
Page 12: Connect A Wired Handset Or Ir Extender
Connect to the IP Network In their default setting AvediaPlayer r92xx receivers are configured to obtain an IP address from the DHCP server on your network. You can subsequently configure a static IP address if required, or pre-configure a static address prior to connection to your network. Refer to Address Configuration on page 19 for more information. -
Page 13: Connect To Power Source
Always off, blinking on briefly on reception of remote handset commands. Note: The LED behaviour is a configurable option. Refer to the AvediaPlayer r92xx Administrator’s Guide for more details. 13 | www.exterity.com Exterity Limited, Ridge Way, Hillend Industrial Park, Dalgety Bay, KY11 9JD... -
Page 14: Additional Connections And Functions
Press and hold RESET until both ADM and TV LEDs flash to return the device to factory default settings. (The serial port is set to admin control mode.) Note: You can also set the Admin/Serial port function using the RESET button. Refer to the AvediaPlayer r92xx Administrator’s Guide for more details. Serial TV /ADM Serial TV /ADM –... -
Page 15: Usb
For details on using this interface, refer to the AvediaPlayer r92xx Administrator’s Guide. AvediaPlayer r9220 Connections In addition to the connections available on all AvediaPlayer r92xx series receivers, the AvediaPlayer r9220 provides additional LAN connections and a network switch. Ethernet Ports Ethernet Ports –... -
Page 16: Basic Configuration
Determining the IP address of the AvediaPlayer Receiver If you have connected the AvediaPlayer receiver to an IP network with a DHCP server, you can determine the IP address of the AvediaPlayer receiver: ... -
Page 17: Using The Avediaserver Director
Web Admin Interface. Enter your AvediaServer IP address – lists all Exterity devices Director in your network. Match the AvediaPlayer receiver MAC address and its IP address Start the AvediaServer Director Application and select the Receivers tab. -
Page 18: Using The Serial Admin Interface
Using the Serial Admin Interface USB/Serial Terminal Program - Terminal program such as PuTTY. Baud rate: 115200 Data bits: 8 Serial Port (RJ-45) Parity: none Stop bits: 1 Flow control: none Start terminal program Exterity access-usb Exterity access-srl RJ-45 to USB adaptor RJ-45 to DB9 adaptor... -
Page 19: Ip Address Configuration
This section shows how to use the Serial Admin interface to configure the correct IP addressing details. Additional switch settings are required to configure the AvediaPlayer r9220 four-port Ethernet switch. Connect to the AvediaPlayer receiver as shown described in Using the Serial Admin Interface. -
Page 20: Logging Into The Web Interface
Logging into the Web Interface Admin – log in using: username: admin password: labrador to access the Web Admin Interface. Enter admin/labrador username/password Enter your AvediaPlayer receiver IP address 20 | www.exterity.com Exterity Limited, Ridge Way, Hillend Industrial Park, Dalgety Bay, KY11 9JD... -
Page 21: Setting Network Configuration Using The Web Admin Interface
Setting Network Configuration using the Web Admin Interface This section shows how to use the web admin interface to configure the AvediaPlayer receiver to ensure it connects to your IP network and interacts correctly with all other network devices. You can configure the receiver to... -
Page 22: Name And Location
Name and Location You can specify a name and location for each AvediaPlayer receiver. The name specified is also used to identify the device on a management application such as the AvediaServer Director. You can use the web management interface or the AvediaServer Director to specify a name and location. -
Page 23: General Page Reference
22. AvediaPlayer r92xx receivers listen for SAP announcements on your network to automatically build their channel list. If there are no SAP announcements, an XML channel list can be imported. This, and more detailed configuration information, are described in the AvediaPlayer r92xx Administrator’s Guide. -
Page 24: Regulatory And Safety Information
6 Regulatory and Safety Information There are no instructions specifically for service personnel in this document. There are no user serviceable parts inside any Exterity product. To prevent electric shock or fire hazard, do not remove cover. Refer service to qualified service personnel. This chapter contains important safety information. -
Page 25: Eu And Others
13. Unplug this apparatus during lightning storms or when unused for long periods of time. 14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
