Barrett 960 HF Operation Manual

Telephone interconnect
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Barrett 960 HF Telephone Interconnect
Head office:
Barrett Communications Pty Ltd
10 Port Kembla Drive, Bibra Lake WA 6163
P O Box 1214, Bibra Lake WA 6965
AUSTRALIA
Toll Free Tel: 1800 999 580
Tel: (61-8) 9 434 1700
Fax: (61-8) 9 418 6757
Operation Manual
© BARRETT COMMUNICATIONS
BCM96001/2
1
European office:
Barrett Europe Limited
19 Lenten Street
Alton, Hampshire
GU34 1HG
UNITED KINGDOM
Tel:
(44) 1420 542254
Fax:
(44) 1420 543373

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 960 HF and is the answer not in the manual?

Questions and answers

Summary of Contents for Barrett 960 HF

  • Page 1 Barrett 960 HF Telephone Interconnect Operation Manual © BARRETT COMMUNICATIONS BCM96001/2 Head office: European office: Barrett Communications Pty Ltd Barrett Europe Limited 10 Port Kembla Drive, Bibra Lake WA 6163 19 Lenten Street P O Box 1214, Bibra Lake WA 6965...

  • Page 2: Table Of Contents

    Introduction ............... 7 System Overview .
  • Page 3 Selecting DTMF or pulse (Decadic) dialling ....... . 24 Enabling dial tone checking ..........24 Setting DTMF tone duration .
  • Page 4 ALE Configuration ............46 Enabling/Disabling the ALE .
  • Page 5 Remote supervisory software ........... . 47 Program Overview .
  • Page 6 PABX Prefix ............56 Line Reversal Detection .

  • Page 7: Introduction

    Introduction The 960 HF Telephone interconnect is designed to provide users on a HF network full interconnection with the international telephone network. It is designed to be operated as a completely automatic facility with no requirement for human operator supervision. A high level of security is incorporated to eliminate system abuse.

  • Page 8: Facilities Available To The Telephone User

    Facilities available to the telephone user A telephone subscriber using a DTMF telephone can access the following facilities provided by the 960 telephone interconnect. These facilities are available after the 960 has answered the call and played its recorded instruction messages.

  • Page 9: Sending A Telcall

    Using the Voice Operated Switch (VOX) The transceiver being operated by the Barrett 960 telephone interconnect is usually switched between transmit and receive using the telephone subscribers voice to derive the switching signal. This is achieved using a specialised VOX (voice operated switch).

  • Page 10: Completing A Call - "Hanging Up

    Note: ID's 9900 and above are reserved for ALE calls. Facilities available to the HF station For more detailed information on how to call the interconnect using Barrett 530,550,930 and 950 transceivers refer to the relevant transceiver operation manuals. Sending a beacon Request To receive a beacon revertive from the 960 interconnect, send a Selcall to the ID xx99, where xx is the self ID of the interconnect.

  • Page 11: Sending An Ale Call

    Sending an ALE call ALE calls may be sent to Interconnects fitted with the ALE option. The transceiver must also be fitted with an ALE board. Preset numbers are allocated by the Interconnect operator. Preset numbers are allocated according to which destination address is used.

  • Page 12: Completing The Call - "Hanging Up

    The 960 operator can select 'Place Off Line' from the manual operator's control menu. Once a telephone call is complete, the Barrett 960 will revert to scan if scanning is selected as the system default. Sending a Selcall to a HF station Enter manual mode by pressing '0'.

  • Page 13: Sending A Telcall To A Hf Station

    Sending a Telcall to a HF station Enter manual mode by pressing '0'. Enter the Manual Operator’s Control Menu by pressing the ‘LEFT’ key while in ‘Manual’ mode. When making a Telcall, use the UP/DOWN keys to select 'Send Telcall'. Press the RIGHT key. Enter the telephone number required by using the numeric keypad.

  • Page 14: Making A Telephone Call

    Making a telephone call Enter the Manual Operator’s Control Menu, as before. When making a telephone call, use the UP/DOWN keys to select 'Make Phonecall'. Press the RIGHT key. When the telephone number displayed is correct press ‘END’ to dial the number. When the telephone is answered, use the front panel microphone to talk and the speaker to listen.

  • Page 15: Sending A Beacon Request To A Hf Station

    Sending a Beacon request to a HF station Enter manual mode by pressing '0'. Enter the Manual Operator’s Control Menu by pressing the ‘LEFT’ key while in ‘Manual’ mode. Use the UP/DOWN keys to select 'Send Beacon Rqst'. Press the RIGHT key. When sending a Beacon, the most recent destination ID becomes the default.

  • Page 16: Sending An Ale Request/End

    Sending an ALE Request/End To send an ALE call or end call requires the optional ALE board. Enter the Manual Operator’s Control Menu by pressing the ‘LEFT’ key while in ‘Manual’ mode. Use the UP/DOWN keys to select ‘Send ALE Rqst’ or ‘Send ALE End’.

  • Page 17: System Setup

    Transceiver port for connection to a 950 transceiver. (25 pin 'D' female connector). Auxiliary port 2 for connection to remote site systems etc. i.e. Barrett 974 system(25 pin “D” female connector) Auxiliary serial port for configuring (filling) the optional ALE board (9 pin ‘D’ connector). Can also be used for logging / monitoring and direct programming.

  • Page 18: System Interconnection

    On the 960 interconnect ensure the ON/OFF Volume control is fully counter-clockwise. On the 922 Power supply remove the IEC mains connector lead. Connect the 25 way interface cable (cable Barrett connector P/N BCA90021) from the 950M transceiver 25 pin auxiliary connector to the 960 25 pin 950 transceiver connector.

  • Page 19: Option Levels

    There are 3 different option levels of 960 Telephone interconnect available. These are only available factory fitted. These options can be upgraded, however this can only be done by returning the 960 to the Barrett factory. It is NOT possible for dealers to perform this upgrade.

  • Page 20: Primary Screen Functions

    Primary screen functions The primary screen is the normal operational screen of the 960 interconnect. From the primary screen, the user can do several operations by using the front panel key pad. These are shown individually below, but are not intended to be a sequence of key presses..

  • Page 21: Setting Parameters

    Setting parameters Navigating the menus The configuration of the interconnect is broken down into menus and sub-menus..to enter the main menu ... to enter the manual menu, while the interconnect is in manual mode. To enter manual mode, press '0'. Use the following sequences to display or change parameters of items in the menu selection.

  • Page 22: Deleting A Channel

    Using the number pad enter in the receive (Rx) frequency. If the first digit entered is greater than three (‘3’) then a leading zero (‘0’) will be inserted. For example 06850kHz. This is because RX and TX frequencies are between 1600kHz and 30MHz.

  • Page 23: 960 Interface Parameters

    Use the ‘LEFT’ and ‘RIGHT’ arrow keys to select “950” or “Aux”. Press ‘END’ to confirm selection. Selecting 960 interface Factory Default: 950 Selects which 960 interface is in use. The interconnect can communicate with a 950 transceiver or an ancillary device connected to the ancillary port such as a Barrett 974 integration system.

  • Page 24: Selecting Duplex Mode

    Select the “Txcvr Type” option from the “Txcvr Menu”. Use ‘LEFT’ and ‘RIGHT’ arrow keys to select “950” or “Aux”. Press ‘END’ to confirm selection. Selecting Duplex Mode Factory Default: Off Selects duplex mode. This allows the transceiver user to talk and listen at the same time. Duplex mode requires two 950 transceivers, one for receive and one for transmit.

  • Page 25: Phone Dialling Configuration

    Phone dialling configuration Preset phone numbers Factory Default: No preset phone numbers. The interconnect has the ability to store 98 preset phone numbers internally. These are dialled when a Selcall is received by the interconnect. For example, the interconnect has a self ID of 45, and a Selcall is sent from a mobile transceiver ID 1234 to the ID 4550.

  • Page 26: Selecting Dtmf Or Pulse (Decadic) Dialling

    If the phone number exists it will be displayed upon the bottom line. Use the ‘CANCEL’ button to delete each digit in the phone number. Once all the digits have been deleted press the ‘END’ key to save the empty phone number. Selecting DTMF or pulse (Decadic) dialling Factory Default: DTMF This will set how all phone numbers are dialled to the phone exchange.

  • Page 27: Setting Dtmf Tone Duration

    Setting DTMF tone duration Factory Default: 70ms. Select “DTMF Tone Length” option from the “Dialling Menu”. Use the ‘UP’ and ‘DOWN’ arrow keys to select the time in milli -seconds (ms) a DTMF tone will be on for. Press ‘END’ to save. Setting time to wait for someone to answer the phone Factory Default: 50 seconds.

  • Page 28: Enabling Line Reversal Off Hook / On Hook Detection

    Enabling line reversal off hook / on hook detection Line reversal detection is a means of detecting when the phone is answered when an outgoing phone call from the 960 is made. To use "line reversal detection" the phone line the 960 is connected to must have this facility fitted. You should request this facility from your local Telecom company.

  • Page 29: Setting The Maximum Call Length

    Use the ‘UP’ and ‘DOWN’ arrow keys to select the number of rings before the interconnect will hang-up the phone. The minimum is two rings, the maximum is fifteen rings. Press ‘END’ to save. Setting the maximum call length Factory Default: 30 minutes The interconnect can restrict the length of phone calls so as to allow other people the use of the interconnect.

  • Page 30: Learning Non-Standard Ring / Busy / Disconnect Cadences

    Press 'RIGHT' arrow key to select the option. Press 'CANCEL' to delete the current PABX prefix. Enter a new prefix using the number keys. Press 'END' to save the setting, or continually press 'CANCEL' to abort without saving. Learning non-standard ring / busy / disconnect cadences This feature allows the 960 interconnect to adapt to the different cadences available on different telephone networks.
  • Page 31 Alternatively, the user may enter the cadence manually. This procedure sets the various tone ON and OFF time. These must be known by the user to be entered into the 960. Enter the “Manual Set Tones” submenu in the “Learn Cadences” submenu. Select “Ring Tone”, “Busy Tone”...

  • Page 32: Access Levels

    Access levels Each transceiver that calls into the interconnect has its own unique Selcall ID. Each Selcall ID is assigned an access privilege internally to the interconnect that determines the type of phone call that can be made through the interconnect, and the type of call it can receive (eg.

  • Page 33: Setting Access From Phone To Transceiver

    Setting Access from Phone to Transceiver Access levels that exist from the phone to the transceiver are; Selcalls Only If set, this Selcall ID can receive Selcalls only from the interconnect. Selcalls and Telcalls If set, this Selcall ID cannot receive all Selcalls and Telcalls. Barred If set, this Selcall ID will not be able to receive any Selcalls or Telcalls from the interconnect.

  • Page 34: Telcall Access Parameters

    The access level from transceiver to phone will be displayed for 2 seconds on the top line of the LCD and the access from phone to transceiver will be displayed on the bottom line. Telcall access parameters Barred Prefix This facilitates the ability to block certain phone number prefixes from being called via a Telcall. Select “Barred Prefixes”...

  • Page 35: Tollfree Prefixes

    TollFree Prefixes This sets prefixes that are recognised as TollFree phone number prefixes during a Telcall. Select “TollFree Prefixs” option from the “Telcall Setup” menu. This is located in the “Access Menu”. Select the TollFree prefix to modify by using the ‘UP’ and ‘DOWN’ arrow keys to scroll between 0 and 4. Press ‘END’...

  • Page 36: Pre-Recorded Messages

    Pre-recorded messages Three pre-recorded messages can stored internally to the interconnect. They are used to provide information to the users of the interconnect and can be up to 15 seconds long. The three messages are respectively; “Welcome”. When someone calls into the interconnect from a phone line this message is played to the phone line.

  • Page 37: Erasing A Message

    An indicator of the time left in the message will be displayed on the LCD. Release the PTT button when the message is completed. The message is not required to use the maximum length possible. Play back the message as explained above. Erasing a Message Select “Erase Message”...

  • Page 38: Operational Parameters

    Operational parameters Selecting Channel Scan on Power-up Factory Default: On The normal operation of the interconnect requires that a number of channel frequencies be scanned for incoming calls. The channels only programmed as “Scan” will be scanned (See ‘Adding / Editing a Channel’). Enabling scan mode here will place the interconnect into scan mode and will also save this option.

  • Page 39: Setting Vox Hang-Up Timeout Period

    Use the ‘LEFT’ and ‘RIGHT’ arrow keys to select “Auto” or “Manual”. Press ‘END’ to confirm selection. Setting VOX Hang-up Timeout Period Factory Default: 4 minutes This option will terminate a phone call if the person on the phone line has not spoken within this period. This is to assist with phone exchanges that do not generate a call progress tone when the phone is placed on-hook.

  • Page 40: Setting Vox Threshold

    Select “VOX Hangtime” from the “Operational Menu”. Use the ‘UP’ and ‘DOWN’ arrow keys to select how long to leave VOX enabled after the person on the phone line has finished speaking. Press ‘RIGHT’ arrow to confirm selection. Setting VOX Threshold Factory Default: Sensitive This option determines the minimum threshold level for automatic VOX, when a person speaks on the phone line.

  • Page 41: Enabling Periodic Beacon

    Enabling Periodic Beacon Factory Default: 10 minutes This option generates a beacon that will be sent on every programmed channel. The interval in minutes determines how often the beacon(s) will be sent. Select “Periodic Beacon” from the “Operational Menu”. Use the ‘UP’ and ‘DOWN’ arrow keys to select the interval in minutes that the beacons will be sent. To disable the periodic beacon select “00 Minute(s)”.

  • Page 42: Setting The Real Time Clock (Rtc)

    (Seconds are set to zero). Setting the Custom Start-up Message A custom user start-up message can be displayed on power-up following the Barrett start-up message. To modify the startup message, select “Startup Message” from the “Operational Menu”. Use the ‘UP’ and ‘DOWN’ arrow keys to scroll through the possible characters. Press ‘END’ to move onto the next character.

  • Page 43: Enabling The Scrambler

    Enabling the Scrambler Factory Default: No, Disabled This option is used to enable/disable all scrambler ID's that are enabled in the "Set Scrambler ID" menu option. (See "Setting Scrambler ID for each User's Self Selcall ID"). Select “Scrambler Enable” from the “Operational Menu”. Use the ‘LEFT’...

  • Page 44: Setting Rx Level When In Ptt

    Setting RX Level when in PTT Factory Default: Low Sets the RX Level when the interconnect detects VOX, in duplex mode. Options are “High” and “Low”. When “Low” is selected, RX Level is reduced by 20dB. When “High” is selected, audio is received at full power. Select “PTT RX Level”...

  • Page 45: Factory Options

    Factory options The “Factory Menu” is located in the ‘Operational Menu”, and it is used to reset various parameters to their factory defaults. Reset all to defaults Select “Factory Rst All” from the “Factory Menu”. Use the ‘LEFT’ and ‘RIGHT’ arrow keys to select “Yes” or “No”. Press 'END’ to confirm selection. Reset operational only to defaults Resets all operational parameters.

  • Page 46: Reset Call Progress Cadences To Default

    Reset Call Progress Cadences to default Resets cadences to defaults (e.g. Busy, Ring and Disconnect), which are Australian. Select “Rst Cadences” from the “Factory Menu”. Use ‘LEFT’ and ‘RIGHT’ arrow keys to select “Yes” or “No”. Press END to confirm selection. Erase all channels Select “Erase Channels”...

  • Page 47: Getting Datalog % Full

    Getting DataLog % Full This will display how full the internal DataLog is. Select “% Data Log Full” from the “Factory Menu”. DataLog size is displayed as a percentage of total memory usage. Enable configuration through PC serial port This will enable using the Option Level 3 PC software through a NULL modem serial cable to configure the interconnect.

  • Page 48: Ale Configuration

    ALE Configuration Enabling/Disabling the ALE To enable the ALE go to the "ALE Menu" and use the 'UP' and 'DOWN' arrow keys to choose the "ALE Enable" menu option. Press 'END' to save the option. ALE Fill Mode ALE fill mode is used to remotely configure the ALE board via the Windows ALE configuration software. To go into ALE fill mode, go to the "ALE Menu"...
  • Page 49 Enter the phone number through the key pad. When finished, press 'END' to save the current phone number and to go onto the next index. Press 'CANCEL' to exit out of the ALE phone number editor, or 'RIGHT' arrow key to edit the next ALE phone number.

  • Page 50: Remote Supervisory Software

    Remote supervisory software Program Overview The purpose of this software is to communicate with a remote interconnect with the ability to examine and/or alter its operational parameters, as well as download its call history log. See Interconnect Parameters. Installation Insert Setup disk 1 into floppy drive A: Go to the Start button on the task bar (Windows 95), and click on the Run..

  • Page 51: Menu Options

    The config button allows configuration of interconnect parameters on or off-line. Any of the interconnect parameters can be printed, uploaded or downloaded from here. Whilst connected the dial button changes to a hangup button. Pressing the hangup button terminates the current connection.

  • Page 52: Setup Window

    Setup Window The setup port window is accessed by going to the “File” menu and choosing the “Setup Port” menu option. Baud Rate This is the rate at which data is sent and received from the communications port. For newer high speed modems, this should be set to 19200.

  • Page 53: Adding Interconnect Sites

    Adding Interconnect Sites Each site has associated with it a name, phone number, pin number, and a number of user selectable automatic events. The automatic events allows one to automatically upload any parameter settings of the interconnect and download the call history without user intervention. To add a site, press the Add button on the main window.

  • Page 54: Upload Operational Parameters

    Upload Operational Parameters The interconnect operational parameters contained within the file will be uploaded as soon as a connection is seen. Upload Channels The interconnect channels contained within the file will be uploaded as soon as a connection is seen. Upload Phone Numbers The interconnect preset phone numbers contained within the file will be uploaded as soon as a connection is seen.

  • Page 55: Dialling

    Dialling Once a site has been selected from the sites list, hit the dial button. This will invoke a form that will initialise the modem and then start dialling the site’s phone number. Any dialling errors like ‘no dial tone’ or ‘modem not responding’...

  • Page 56: Modifying The Interconnect's Parameters

    Modifying the Interconnect’s Parameters The parameters for the interconnect can be modified on or off-line. To modify the interconnect’s parameters, select the interconnect site to modify and press the Config button. The first step is to download the current interconnect parameters. To download the interconnect parameters, select the tab containing the parameters to be downloaded, and press the download button.

  • Page 57: Operational Parameters

    Operational Parameters This panel displays the operational parameters of the remote interconnect. These are general settings that affect the operational state of the interconnect. Operational Settings To access the operational settings, press the Config button on the main window. Go to the operational tab and select operational parameters.

  • Page 58: Scrambler Enabled

    Scrambler Enabled When checked, the scrambler is enabled on the remote interconnect. Scan Mute on Powerup This option enables Scan Mute, which disables the speaker during scan. The speaker is re-enabled during receiving Selcalls, and while the interconnect is online. Periodic Beacon Period The remote interconnect when off-line has the ability to send out a beacon on all available scannable channels to indicate that there is an interconnect out there.

  • Page 59: Dial Settings

    Dial Settings To access the Dial Settings, go to the Operational tab and select Dial Settings. Tone Dialling When checked, tone dialling will be used for outgoing phone calls, otherwise pulse dialling will be used. Dial Tone Wait This is the period to wait for before determining if a dial tone is present. The time is measured in seconds. A zero in this field disables dial tone checking.

  • Page 60: Operational - Date/Time

    Operational - Date/Time To access the Date/Time parameters, go to Date/Time in the Operational tab. Date/Time Allows changing the date and time of the remote interconnect when 'Change Data/Time' check box is checked. Startup Message This displays the LCD (Liquid Crystal Display) user defined startup message when the interconnect is turned on.

  • Page 61: Setting Preset Phone Numbers/Prefixes

    Setting Preset Phone Numbers/Prefixes Preset Numbers To set preset numbers, go to Preset phone numbers in the Phone No’s tab. This panel displays preset phone numbers internal to the remote interconnect that are dialled when a Selcall is received. The maximum phone number length is 16 digits.

  • Page 62: Programming Channels

    Programming Channels This panel is accessed by going to the Channels tab. This panel displays the preset channel frequencies for the remote interconnect. To set a channel, choose a channel from the channel list. Receive frequency and transmit frequency are displayed for the current channel. The frequencies are measured in kilo Hertz (kHz).

  • Page 63: Selcall Access Levels

    Selcall Access Levels Each radio that calls into the interconnect has its own unique Selcall ID. Each selcall ID is assigned an access privilege that determines the type of phone call that can be made through the interconnect, and the type of call it can receive (e.g.

  • Page 64: All Phone Calls (Except Barred Numbers)

    All Phone Calls (Except Barred Numbers) If set, selcalls and telcalls can be received from these ID(s). Every call received will be dialled, except barred numbers. Barred from receiving Selcalls and Telcalls If set, this selcall ID will not be able to make any phone calls through this system. Access from Phone to Radio Selcalls Only If set, this selcall ID can receive selcalls only from the interconnect.

  • Page 65: Scrambler Id's

    Scrambler ID's Each transceiver that calls into the interconnect has its own unique Selcall ID. Each Selcall ID has a corresponding scrambler ID, and an option to enable or disable the scrambler for each Selcall ID. There is also an option to enable or disable the scrambler for all scrambler ID’s.

  • Page 66: Data Log

    Data Log (Option Level 2&3 Interconnects Only) This panel displays the current state of the internal data log of the remote interconnect. Shown at the top of the screen is the percentage of memory used by the datalog in the interconnect. When this becomes full, press the Erase button.

  • Page 67: Call Charging

    Call Charging Introduction The remote supervisory software may be used to produce a bill for customers. Setting Charging Rates Before producing a bill, the charging rates must be set. Calls can be charged according to whether the incoming phone call produced a Selcall, Telcall, or ALE Call to link to the remote transceiver. These can be set by going to “Charging Setup”...

  • Page 68: Invoice Options

    Invoice Options Invoice options are used to determine how the bill will be produced. Optionally, the produced invoice can be viewed by a Windows text editor. The default editor is notepad. To modify, go to “Charging Setup” in the “Charging” menu. Select the “View invoice with” check box. Enter a name for the executable of the program used to open the invoice file.

  • Page 69: Adding/Editing Clients

    Adding/Editing Clients Each invoice has a client name at the top. This client name must be entered prior to generating an invoice. Associated with each client, is a list of selcall ID’s that are reserved for this client. Once a selcall ID is allocated, it can’t be allocated to any other client.

  • Page 70: Building Invoices

    Building Invoices Choosing a Client Open the Client Administrator by going to the "Client Administrator" submenu in the "Charging" menu. Select a client from the clients list. To select multiple clients, hold down the 'CTRL' key and select another client. See Creating New Clients.

  • Page 71: Appendix - A

    APPENDIX - A Primary Screen/ Menu Key Functions Primary Screen Function Menu Function Enter the main menu Saves parameter Auto / Manual mode Enters the digit '0' Scan / No Scan Aborts parameter Changes channels Enters the digit '1' Numeric key '1' Changes channels Enters the digit '2' Numeric key '2'...
