- Page 1 BDP-V500 BLU-RAY DISC PLAYER User Manual BDP - V500 Please read this User Manual carefully to ensure proper use of this product and keep this manual for future reference.
-
Page 2: Table Of Contents
Content Introduction Important Safety Instructions Caution Features Getting Started Front Panel and Rear Panel Illustration Remote Control Connections TV set Connections Digital Audio Connections Advanced Features Function Operation System setup File Disc(MPEG4/WMA/MP3/JPEG) Playback Others Troubleshooting Specifications... -
Page 3: Introduction
Important Safety Instructions Introduction 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not block any ventilation openings, install in accordance with the instructions. 8) Do not install near any heat sources such as radiations, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. -
Page 4: Caution
Caution Introduction Please use the original box and packing materials for safe transportation of this product. It is normal for the cover and rear panel to become warm after the player has been in operation for an extended period of time. Do not move this product during playback. - Page 5 Features Introduction Player Features Supports a Variety of Video Disc Types Supports Blu-ray (BD-ROM), DVD Video and DVD RW/ R (V mode and finalized only) discs. HDMI (High Definition Multimedia Interface) HDMI reduces picture noise by allowing a pure digital video/audio signal path from the player to your TV.
-
Page 6: Getting Started
Getting Started Introduction Region code Both the Blu-ray Disc Player and the discs are coded by region. These regional codes must match in order to play the disc. If the codes do not match, the disc will not play. The Region Number for this Blu-ray Disc Player is described on the rear panel of the Blu-ray Disc Player. Disc Type Blu-ray DVD-VIDEO... -
Page 7: Disc Types
Getting Started Introduction Discs which cannot be played on this player. HD DVD DVD-RAM DVD-ROM CD-I CD-ROM Super Audio CD(except CD layer) CDGs play audio only, not graphics. Discs which can be played on this player (For the following discs, the ability to play back may depend on recording conditions.) BD-ROM... - Page 8 Getting Started Introduction CD-RW/CD-R Use a 700MB(80 minutes) CD-RW/CD-R disc. If possible, do not use a 800MB(90 minutes) or above disc, as the disc may not play back. If the CD-RW/CD-R disc was not recorded as a closed session, you may experience delays when playing back the beginning of the disc or all recorded fles may not play.
-
Page 9: Disc Handling
Getting Started Introduction DISC STORAGE & MANAGEMENT Disc Handling Disc Shape Use discs with regular shapes. If an irregular disc (a disc with a special shape) is used, this Blu-ray Disc Player may be damaged. Holding discs Avoid touching the surface of a disc where recording is performed. Blu-ray Discs If the player is not used for a long period of time, remove the Blu-ray Disc from the player and store it in its case. -
Page 10: Front Panel And Rear Panel Illustration
Front Panel and Rear Panel Illustration Introduction Front panel 9 10 SENSOR PREV BUTTON POWER CABIN DOOR OPEN/CLOSE BUTTON NEXT BUTTON BD LIGHT PLAY/PAUSE BUTTON VFD SCREEN STOP BUTTON Rear panel(2CH Audio output) DIGITAL AUDIO O UT DIGITAL AUDIO O UT HDMI OUT(1080P) HDMI OUT(1080P) SERVICE... -
Page 11: Remote Control
Remote Control Introduction Remote Control OPEN/CLOSE STANDBY STANDBY OPEN/CLOSE AUDIO ANGLE SUBTITLE AUDIO ANGLE POP MENU/TITLE MENU RANDOM SUBTITLE POP MENU/TITLE RANDOM BONUS VIEW SECONDARY SECONDARY SECONDARY AUDIO MENU SUBTITLE AUDIO MOVE( COLOUR (RED, GREEN, YELLOW, BLUE) SETUP ENTER SECONDARY SUBTITLE STEP SETUP DISPLAY... -
Page 12: Connections
TV Set Connections Connections HDMI COMPONENT IN AUDIO IN VIDEO AUDIO IN VIDEO IN YPbPr IN HDMI IN COMPONENT VIDEO OUT AUDIO(red and white) OUT (Audio) Red White Red Blue Green CONNECT BD PLAYER TO TV SET BY AV CABLE Connect the BD player s L and R jack to the audio input jack on the TV. -
Page 13: Digital Audio Connections
Digital Audio Connections Connections Connecting to an AV Amplifier with Digital Audio Input Coaxial Optical Digital Amplifier Notes: 1. Select the Coaxial or Optical digital audio output. 2. Set the digital Amplifier to the AV input connected to the BD player. -
Page 14: Advanced Features
Function Operation Advanced Features Function Buttons OPEN/CLOSE To open the disc tray, press OPEN/CLOSE; To close the disc tray, press OPEN/CLOSE again. AUDIO During BD, DVD playback, press AUDIO can select different audio language. During VCD playback, press AUDIO button to switch between LEFT/RIGHT/STEREO channels. - Page 15 Function Operation Advanced Features SLOW During BD, DVD, VCD or SVCD playback, press SLOW for slow motion playback. Once you press SLOW, the disc will play at different speed. Press PLAY to resume normal playback. No sound is heard during slow mode. Slow motion operates only in the forward direction.
- Page 16 Function Operation Advanced Features Secondary Audio Press Secondary Audio button to choose audio language for the secondary audio (this function is disc dependent). POP MENU/TITLE Press the button to enter the appointed title.(Requires disc support) During BD playback, press the button to display the disc s popup menu. REPEAT Each press of the REPEAT button will change the repeat mode.
-
Page 17: System Setup
System Setup Advanced Features Press SETUP button on remote controller under STOP or NO DISC status to bring up setup menu. In setup menu, using UP/DOWN/LEFT/RIGHT and ENTER button to config settings, press SETUP button to exit setup menu. 1. LANGUAGE Menu Setup---Language Menu Audio Chinese... - Page 18 System Setup Advanced Features 2.1 TV Type: Select TV type. 2.2 TV Aspect: Select display configuration for disc. 16:9 Wide: Content presented in 16:9 geometry for widescreen TVs. 16:9 Pillar box: Content presented in 4:3 geometry or cropped content for widescreen TVs. 4:3 Letter box: Content presented in 4:3 geometry with horizontal black bars on top and bottom for conventional TVs.
- Page 19 System Setup Advanced Features 3.1Digital Output Choose preferred option for digital output based on receiver connected to player PCM: Output PCM audio data for receiver not support Dolby and DTS decoding (mixed primary audio, secondary audio and effect audio if available in disk) Bitstream: Output raw data for receiver support Dolby and DTS decoding (primary audio only).
- Page 20 System Setup Advanced Features Enter right password to enter parental setting menu. Setup ---Parental Setting Country Parental Control Parental Level 8.Adult Password Default ENTER Note: Factory default password is 6666. 4.1 Country: Select the movie intended for your residential area. USA: Parental country set to USA.
- Page 21 System Setup Advanced Features 5. System Setup ---System Factory Default Clear BD Storage Software Version PKG_DVD_1_4_035_RC Loader Version BP04-B00T CFE Version CEF-0-1-35-17 ENTER 5.1 Factory Default: menu for setting configurations to factory default. Setup ---System Reload Default Setting? Cancel Reset the menu settings to their default ENTER 5.2 Clear BD storage: menu for erasing storage Partition base on BD-T requirement.
-
Page 22: File Disc(Mpeg4/Wma/Mp3/Jpeg) Playback
File Disc(MPEG4/WMA/MP3/JPEG) Playback Advanced Features System will pop up a navigation selection menu(see below picture) after read out a disc with MPEG4/WMA/MP3/JPEG files. You should select Video to play MPEG4 files, or Music/Picture to view pictures and listen musics. DISC NAVIGATION Video Music/Picture After selecting video for MPEG4 playback, system will bring a file browser like picture below. - Page 23 File Disc(MPEG4/WMA/MP3/JPEG) Playback Advanced Features After read out the device with WMJ files, player will list all directories and files in root directory as below picture shown. Press MENU key to bring up a pop up menu which guide you for special features, press LEFT button to exit pop up menu, press NAVIGATION buttons on remote controller to select desired item for playback or enter next level directory.
- Page 24 File Disc(MPEG4/WMA/MP3/JPEG) Playback Advanced Features For JPEG files, in pop up menu, user can choose to play current JPEG or slide show JPEG files Play Start Slide Show Properties For single JPEG file playback, user can change to slide show mode with different transition effects, rotate current picture or choose Properties to see detail file information.
-
Page 25: Troubleshooting
Troubleshooting Others Ensure you have entered the correct AV input for your TV. Ensure you have entered the correct AV input for your TV. -
Page 26: Specifications
