- Page 1 Indoor / Outdoor Wi-Fi Range Extender Model Number: IT144052 INSTRUCTION MANUAL After Sales Support Telephone: 1300 663 907 Internet: www.winplus.com.au...
-
Page 2: Warranty
Indoor / Outdoor Wi-Fi Range Extender Warranty Details The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months (dependant on product) from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion. -
Page 3: Table Of Contents
SR600EX USER’S GUIDE CONTENTS Warranty ................... 2 Antenna Settings ..............27 Warranty..................Antenna Settings................ Welcome ................... 4 Advanced Settings..............28 Welcome..................Advanced Settings..............General Safety Instructions ............SMART FEATURES ..............29 General Safety Instructions............Smart Features................Parts List ................... Access Schedule ............... 30 Parts List .................. -
Page 4: Welcome
Welcome Congratulations on choosing to buy a BAUHN® product. By doing so you now have the assurance and peace of mind that comes with purchasing a product made by one of the leading manufacturers. All products brought to you by BAUHN® are manufactured to the highest standards of performance and safety and, as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 1 Year Warranty. -
Page 5: Parts List
Parts List 1 x Wi-Fi Range Extender Power Adaptor 1 x Stand 10m PoE Cable Metal Pole Clamp 1m Ethernet Cable PoE Adaptor Plastic Pole Strap After Sales Support Telephone: 1300 663 907 Internet: www.winplus.com.au... -
Page 6: Led Indicators
SR600EX USER’S GUIDE LED Indicators Power: When lit, the power is on. Wireless Activity: Blinks rapidly when wireless data traffic is passing through the Wi-Fi Range Extender. LAN: Shows the connection status and data activity of your local network (network devices connected to the Access Point. -
Page 7: Inside Panel
SR600EX USER’S GUIDE Inside Panel Optional External Antenna Port: RJ-SMA antenna connector. Compatible with all antennas with RP-SMA connectors. Upgradable to high gain antennas for more range. See the External Antenna configuration section for setup procedures. PoE Port: Power over Ethernet capable RJ-45 port used to connect the Wi-Fi Range Extender to the included PoE Adapter for power and data connectivity. -
Page 8: Power Over Ethernet (Poe) Adapter
SR600EX USER’S GUIDE Power over Ethernet (PoE) Adapter Power Adapter Port: Connect the included power adapter to the PoE adapter port for powering the Wi-Fi Range Extender. Repeater Port: Connect a PoE cable between the PoE Adapter’s Repeater port and the PoE port on the Wi-Fi Range Extender to provide power and data to the Wi-Fi Range Extender. -
Page 9: Find A Setup Location/ Optimal Positioning
SR600EX USER’S GUIDE SR600EX USER’S GUIDE SETUP GUIDE SETUP GUIDE Find a Setup Location The location of where you setup the Wi-Fi Range extender is very important. The optimal setup location should be within 3m of your Find a Setup Location Find a Setup Location router and modem. - Page 10 SR600EX USER’S GUIDE Wi-Fi Range Extender Find the Optimal Position for the Choose the option below that best fits your installation scenario. For best results, the signal strength between the Wi-Fi Range Extender and the Home Network / Hot Spot should be greater than 70%. FRONT BACK NOTE: Antenna strength is directional.
-
Page 11: Mounting Instructions
SR600EX USER’S GUIDE Mounting Instructions MOUNTING INSTRUCTIONS Desktop Mounting Place the stand in an optimum location. Secure the Wi-Fi Range Extender onto the desktop mount. After Sales Support Telephone: 1300 663 907 Internet: www.winplus.com.au... -
Page 12: Setup Guide
Mounting Instructions SR600EX USER’S GUIDE Wall Mounting Place the Wi-Fi Range Extender against the wall, use a pencil and mark two locations through the mounting hole on the wall. Remove the Wi-Fi Range Extender and securely drill two screws where you’ve marked on the wall. -
Page 13: Find A Setup Location/ Optimal Positioning
Mounting Instructions SR600EX USER’S GUIDE Pole Mounting Place the Wi-Fi Range Extender against the pole. Use the included hose clamp and secure it through the smaller hole located on the bottom of the mounting bracket. Use a screw driver to tighten the clamp until the adapter is securely mounted to the pole. -
Page 14: Access Setup Wizard
Accessing The Smart Setup Wizard FIG. A FIG. B Wireless Network Wireless Network REPE ATER a. Connect cables as shown (fig. A) b. Disconnect your computer from any wireless networks (fig. B) c. Open your web browser d. Type http://192.168.1.240 into the web address bar Enter the setup web address into your browser: http://192.168.1.240... -
Page 15: Welcome To The Smart Setup Wizard
Next to continue to the next page. Bauhn Wi-Fi Range Extender Bauhn Wireless Wi-Fi Range Extender The diagram on this page displays the terms used to describe: 1) The network you are trying to repeat (Home Network / Wireless Hot Spot) -
Page 16: Scan For A Wireless Network
SR600EX USER’S GUIDE Scan for a Wireless Network Click to begin searching for available wireless networks SCAN to repeat. Wireless Wi-Fi Range Extender Highlight your network and click Next to continue. If you fail to find any wireless networks, the Wi-Fi Range Extender may be placed too far from the wireless network that you are trying to repeat. -
Page 17: Connecting To A Secure Network
SR600EX USER’S GUIDE Connecting to a Secure Network If the wireless network you are trying to repeat has wireless security enabled, you will be prompted to enter a security key. If you did not select a secure network, continue to the next step. Enter the security key in the space provided. -
Page 18: Repeater Settings (Ssid)
SR600EX USER’S GUIDE Extender Settings (SSID) The default SSID of the Wi-Fi Range Extender Extender Settings Bauhn_Wireless This SSID for the Extended Network may be changed by adjusting the name in the field for the Extended Wireless Network ID. This ID will be used by wireless users connecting to Bauhn_Wireless the Wi-Fi Range Extender to identify the Wi-Fi Range Wi-Fi Range Extender... -
Page 19: Repeater Settings (Security)
SR600EX USER’S GUIDE Extender Settings (Security) By default, the Extended Network has security Wi-Fi Range Extender. enabled. The WPA security key is “wireless.” Users trying to connect to the Wi-Fi Range Extender wirelessly will be prompted to enter this key. Wi-Fi Range Extender Wi-Fi Range Extender It is recommended that you use the default settings... -
Page 20: Setup Summary
At this time you may disconnect from the Wi-Fi Range At this time, you may disconnect from the Wi-Fi Range Extender and start a wireless connection. Bauhn Wireless Extender start a wireless connection. Bauhn Wireless Extender start a wireless connection. - Page 21 SR600EX USER’S GUIDE SR600EX USER’S GUIDE If the Home Network / Hot Spot connection fails, then try the following… If the Home Network / Hot Spot connection fails, then try the following… Check that the signal strength between the Wi-Fi Range Extender and your Home Network/Wireless Check that the signal strength between the Wi-Fi Range Extender and your Home Network/Wireless Hot Spot is above 70%.
-
Page 22: Wireless Settings
SR600EX USER’S GUIDE WIRELESS SETTINGS To modify the settings of your Wi-Fi extender at any time, navigate your web browser to SR600EX SR600EX USER’S GUIDE USER’S GUIDE http://192.168.1.240 Home Network Settings The Home Network Settings page allows you to adjust WIRELESS SETTINGS WIRELESS SETTINGS On the left side of the page, select “More Settings”... -
Page 23: Extended Network Settings
SR600EX USER’S GUIDE allows for faster speeds. Select the channel width you wish to use for your network. This setting must match that of your Home Network for a successful connection. Extended Network Settings The Extended Network Settings page allows you to adjust settings for your Extended Network. - Page 24 Multiple AP/SSID : You may add an additional name (SSID) to you Extended Network with different characteristics. The additional AP or SSID can have its own security, band and data rate settings. You may restrict users for the specific SSID or provide access only to some users with lower bandwidth by changing the band. (i.e. only allow Click the “Multiple AP”...
- Page 25 SR600EX USER’S GUIDE Security Wireless security allows you to change the type of Bauhn Wireless wireless security settings for your Extended Network or your Home Network. Note: If you adjust the security in your Home Network and it is incorrect, you will no longer have a successful connection to your Home Network.
-
Page 26: Wi-Fi Protected Setup (Wps)
SR600EX USER’S GUIDE Wi-Fi Protected Setup (WPS) WPS is a Wi-Fi feature created to make Wi-Fi setup simpler and easier. Some wireless routers and adapters support this feature with varying names (i.e. one touch setup or WPS). You may enable WPS setup here by selecting the Wi-Fi Range Extender type of WPS setup you wish to use. -
Page 27: Antenna Settings
SR600EX USER’S GUIDE Antenna Settings The Wi-Fi Range Extender includes an internal High Wi-Fi Range Extender Power Antenna, however, if you wish to use an external antenna instead of the internal antenna, you may activate the External Antenna port here. Wi-Fi Range Extender Wi-Fi Range Extender The External Antenna Port is a RJ-SMA port and... -
Page 28: Advanced Settings
SR600EX USER’S GUIDE Advanced Settings It is recommended that only experts in Wi-Fi configuration adjust the advanced wireless settings for the Wi-Fi Range Extender. These settings allow you to control the details of your wireless network configuration. After Sales Support Telephone: 1300 663 907 Internet:... -
Page 29: Smart Features
SR600EX USER’S GUIDE SMART FEATURES The Wi-Fi Range Extender provides your Extended Network with Smart Features that help to provide convenience and protection for your Extended Network. The Smart Features allow you to control access to your Extended Network through on/off schedules, specific user authorizations as well as through the size of your wireless coverage for your Extended Network. -
Page 30: Access Schedule
SR600EX USER’S GUIDE Access Schedule You can set a schedule for when your Wi-Fi is enabled or disabled (both Home Network and the Extended Network) through the Access Schedule feature. Enable Access Schedule Wi-Fi Range Extender. b. Select which days you wish for your Wi- Fi to be available Select the time frame during that day that you wish for Wi-Fi to be available... -
Page 31: User Access Control
SR600EX USER’S GUIDE User Access Control User Access allows you to deny access or allow access to specific users connecting wirelessly to the Extended Network. Each networking device has a unique address called a MAC address (a 12 digit hex number). -
Page 32: Wireless Coverage Controls
SR600EX USER’S GUIDE Wireless Coverage Controls Adjust the output power of the Wi-Fi Range Extender to control the coverage distance of your Extended Wireless Network. For a smaller coverage area you can select a lower output power. For the maximum wireless coverage select the 100% selection. -
Page 33: Ip Settings
SR600EX USER’S GUIDE SR600EX USER’S GUIDE IP SETTINGS IP SETTINGS IP Address: The IP address of the Wi-Fi Range Extender IP Address: The IP address of the Wi-Fi Range IP Address: The IP address of the Wi-Fi Range Extender Extender Subnet Mask: the subnet of the Wi-Fi Range Extender Subnet Mask: the subnet of the Wi-Fi Range Extender Subnet Mask: the subnet of the Wi-Fi Range Extender... - Page 34 SR600EX USER’S GUIDE DHCP Client Range: The range of IP addresses the Wi-Fi Range Extender’s DHCP server will assign to users and devices connecting to the Wi-Fi Range Extender . Static DHCP: You may set a static IP address within your DHCP network. The Wi-Fi Range Extender will track the device via its MAC address and assign it a pre-defined IP address each time the device logs into the network.
-
Page 35: Management Features
SR600EX USER’S GUIDE MANAGEMENT FEATURES The Management features on the Wi-Fi Range Extender allow you to view the status of your Home Network and Extended Network. The Extender Status page provides full information regarding each connection (Home and Extended), including the IP address, current connection SSID and current state. -
Page 36: Repeater Status
SR600EX USER’S GUIDE Extender Status Wi-Fi Range Extender Status The Wi-Fi Range Extender Status page provides detailed information regarding the system, wireless network and configurations as well as the current IP settings of the The Wi-Fi Range Extender. This page is often used to check the health of your wireless network and the link to your home router/hot spot network. -
Page 37: Network Statistics
SR600EX USER’S GUIDE Network Statistics The Network Statistics page provides detailed traffic data for each connection type. To sync your system clock with the Wi-Fi Extender, by pressing “Sync”, then press “Apply”. After Sales Support Telephone: 1300 663 907 Internet: www.winplus.com.au... -
Page 38: System Clock
SR600EX USER’S GUIDE SR600EX USER’S GUIDE System Clock System Clock Maintain the internal clock for the Wi-Fi Range Extender by syncing with your computer’s time. Your system clock settings need to be accurate in order for logs and wireless access schedules to work correctly. To sync your system clock with the Wi-Fi Extender, Press ‘Sync’... -
Page 39: System Logs
SR600EX SR600EX USER’S GUIDE USER’S GUIDE System Logs System Logs The system log will display the activity history of the Wireless Extender. It is recommended that Maintain the internal clock for the Wi-Fi Range Extender by syncing with your computer’s time. Your system Maintain the internal clock for the Wi-Fi Range Extender by syncing with your computer’s time. -
Page 40: Upgrade Firmware
SR600EX USER’S GUIDE SR600EX USER’S GUIDE Upgrade Firmware Upgrade Firmware The Wi-Fi Range Extender uses internet software (firmware) to operate. In the event that a new firmware file is The Wi-Fi Range Extender uses internet software (firmware) to operate. In the event that a new firmware file is available you may update it here. - Page 41 SR600EX USER’S GUIDE To manually upgrade your firmware: Download the file from the www.winplus.com.au/support website and remember the location where you saved it. b. Click Browse and locate the file Click Upload to begin upgrading. Note: Firmware files normally have a .bin file extension.
-
Page 42: Save/Reload Settings
SR600EX USER’S GUIDE Save/Reload Settings Saving your current settings allows you to back-up your current settings which may be reloaded at a later Wi-Fi Range Extender Wi-Fi Range Extender time. This feature may be useful for testing new features and settings without having to worry about returning to a stable platform. -
Page 43: Password Settings
SR600EX USER’S GUIDE Password Settings By default, the Wi-Fi Range Extender does not require a password to login to the web menu. If you wish to enable a password to protect unauthorized access to the web menu and Smart Setup Wizard, you may enter one here. -
Page 44: Technical Specifications
TECHNICAL SPECIFICATIONS Wireless Standard: 802.11n (Backwards compatible w/ 802.11b/g) Frequency Band: 2.4 GHz Wireless Amplifier Power: 600 mW Wireless Output Power: Up to 29 dBm Wireless Sensitivity: -95 dBm Wireless Security: WEP, WPA, WPA2, WPA Mixed, WPS Antennas: 1 x High Gain Bi-Directional Panel Antenna 1 x RJ-RMA Port for Optional External Antenna Ports: Repeater: 2 x RJ-45 Ports (PoE, LAN) -
Page 45: Technical Specifications Default Settings
USER’S GUIDE SR600EX DEFAULT SETTINGS The default settings for your Wi-Fi Range Extender are listed here. If for some reason you need to return your Wi-Fi Range Extender back to default settings, hold down the Reset button on the back panel for 10 seconds. The Wi-Fi Range Extender will reset back to factory settings as listed below: IP Address: 192.168.1.240 DHCP: Auto... -
Page 46: Troubleshooting
SR600EX USER’S GUIDE SR600EX USER’S GUIDE Troubleshooting Troubleshooting The tips in this guide are listed in order of relevance. Try solution (a) before trying solution (b) etc… The tips in this guide are listed in order of relevance. Try solution (a) before trying solution (b) etc… I entered http://192.168.1.240 and it failed to open the Web Menu. - Page 47 SR600EX USER’S GUIDE I cannot connect to my Home Network/Hot Spot. I received an Error when running the Smart Setup Wizard. SR600EX USER’S GUIDE Your Home Network may be secured. Double check that you have the correct security key to connect SR600EX USER’S GUIDE to the Home Network.
- Page 48 SR600EX USER’S GUIDE My Wi-Fi Range Extender was working fine previously but now I can no longer access the Internet through the Wi-Fi Range Extender. The connection to your Home Network has been dropped. This can be caused by several events to your home wireless connection.
- Page 49 SR600EX USER’S GUIDE I have a dual-band router and I cannot repeat it. Log into the Web Menu for your dual-band wireless router and adjust the wireless settings. Change the wireless band to 2.4GHz single band mode only. Disable the 5GHz wireless band. I cannot find any wireless networks (Home Networks/Hot Spots) to repeat.
- Page 50 SR600EX USER’S GUIDE b. You may have a DNS issue and the Wi-Fi Range Extender is not obtaining the IP settings from your Home Network. Try to reboot the Wi-Fi Range Extender and then accessing a website. If that fails, then reboot the Home Router to see if that fixes it.
- Page 51 SR600EX USER’S GUIDE SR600EX USER’S GUIDE b. The connection to the Home Network may be down. Use an Ethernet cable and connect directly to b. The connection to the Home Network may be down. Use an Ethernet cable and connect directly to the Wi-Fi Range Extender .
- Page 52 SR600EX USER’S GUIDE The connection to the Home Network/Hot Spot seems slow. File transfers take a long time to transfer. The Wi-Fi Range Extender may be too far away from your Home Network/Hot Spot. The closer the Wi-Fi Range Extender is to your Home Network/Hot Spot, the better its connection will be. The Wi-Fi Range Extender must have a strong signal (70% or greater) in order to repeat the signal with fast speeds and further range.
- Page 53 SR600EX USER’S GUIDE Check the connections of the Antennas to the Wi-Fi Range Extender . Tighten them if necessary. d. Adjust the Antennas of the Wi-Fi Range Extender in different angles. My Wireless Access Schedule is being erratic and not working at the correct times. You need to adjust your Time Zone Settings from the Management Web Menu page.
-
Page 54: Notes
Notes: After Sales Support Telephone: 1300 663 907 Internet: www.winplus.com.au... -
Page 55: Repair And Refurbishedgoods Or Parts Notice Troubleshooting
Indoor / Outdoor Wi-Fi Range Extender Repair and Refurbished Goods or Parts Notice Unfortunately, from time to time, faulty products are manufactured which need to be returned to the Supplier for repair. Please be aware that if your product is capable of retaining user-generated data (such as files stored on a computer hard drive, telephone numbers stored on a mobile telephone, songs stored on a portable media player, games saved on a games console or files stored on a USB memory stick) during the process of repair, some or all of your stored... - Page 56 After Sales Support Telephone: 1300 663 907 Internet: www.winplus.com.au...
