  • Page 1 Sony DMX-R100 Set-up Guide...
  • Page 2 No part of this documentation may be reproduced in any form whatsoever or be stored in any data retrieval system without prior written permission of the copyright owners. This documentation is supplied on an as-is basis. Information contained within this documenta- tion is subject to change at any time without notice and must not be relied upon.

  • Page 3: Table Of Contents

    Introduction Overview Setup Requirements: Communication DMX-R100 Setup Connections Sony 9-pin (RS-422) DMX-R100 Settings Pyramix Set up Connections Pyramix Settings...
  • Page 4 MIDI Control for Sony DMX-R100 User Guide : User Guide MIDI Control for Sony DMX-R100 Document: Pyramix™ DMX-R100 Guide 05 Date: 21st July-2009 MIDI Control for Sony DMX-R100 User Guide : Page 4...

  • Page 5: Introduction

    The PC Workstation running Pyramix must be equipped with a MIDI interface. Communication Pyramix and the DM-2000 communicate using the Sony 9-pin (P2) protocol plus LTC and via MIDI. Please also refer to the DMX-R100 Operation Manuals. MIDI Control for Sony DMX-R100 User Guide : Introduction...

  • Page 6: Dmx-R100 Setup

    R100. Sony 9-pin (RS-422) Connect one of the serial RS-232 or RS-422 (better) ports of your PC to a REMOTE OUT RS-422 of the DMX-R100 Note: The RS-232 ports of a standard PC are slightly different from the RS-422 format used for the Sony P2 protocol.

  • Page 7: Dmx-R100 Settings

    Go to the MACHINE CONTROL MENU. Sony DMX-R100 MACHINE CONTROL MENU SCREEN • Add a machine under one of the six machines tabs. • Select the correct port (REMOTE OUT 1 OR 2) MIDI Control for Sony DMX-R100 User Guide : DMX-R100 Settings Page 7...

  • Page 8: Pyramix Set Up

    Make sure that the DMX-R100 is connected to your computer via RS-422, LTC and MIDI. Pyramix Settings In order to allow Pyramix to communicate with the DMX-R100, you have to ensure the Timecode settings are cor- rect, add and set-up a 9-pin controller and add and set-up a MIDI controller.
  • Page 9 DMX-R100 respectively. Checking the Off when stopped check-box sup- presses the display discrepancy. The displayed Timecode in the DMX-R100 (at the right top corner of the touch screen) will then be identical to the one in Pyramix. •...
  • Page 10 Controller Properties dialog Type a suitable Name for your Sony console, e.g. DMX-R100 and select Sony 9-pin from the Driver drop-down list. Make sure the Enable box is checked. MIDI Control for Sony DMX-R100 User Guide : Pyramix Set up...
  • Page 11 Click OK on all open dialogs to close them. MIDI Controller Each individual Pyramix control can be mapped to a specific MIDI message but before this can be achieved with the DMX-R100, it is necessary to add a MIDI Controller.
  • Page 12 Properties dialog: Controller Properties dialog Type a suitable Name for your Sony console, e.g. DMX-R100 midi and select MIDICONTROL from the Driver drop-down list. Make sure the Enable box is checked. Now click the Properties button to open the MIDI CONTROL Configuration dialog box: Midi Control Configuration dialog The MIDI Input and MIDI Output ports must be set here.
  • Page 13 Project Information & Settings Controllers page Go to the Settings > All Settings > Project > Controller Mapping page: Select DMX-R100 midi (or whatever you named the console as) in the list and click on the Properties button to open the Midi Control Configuration dialog:...
  • Page 14 Make sure the DMX fader layer is in MIX or MASTER mode. Now, when you move a DMX-R100 fader you will see the input MIDI commands on the monitor view. Mapping Select a MIDI message by clicking on it, select a Pyramix mapping in the tree view by clicking on it and then click the Learn button to associate the DMX-R100 control that generated the message with the selected function in Pyramix.
  • Page 15 MIDI Input MIDI Input and MIDI Output ports AUX Master Faders MIDI Mapping Aux Return Cuts Midi Output Channel Cuts Pan Encoders Channel Faders Pyramix Set up Communication Pyramix Set-up Connections CONTROL CHANGE Controller Properties Requirements DM2000 Settings Scope Driver...
