- Page 1 MANUFACTURING NUMBERS: 9 3 0 0 570 9 3 0 0 572 9 3 0 0 576 9 3 0 0 5 8 0 9 3 0 0 5 8 2 9 3 0 0 5 8 4 9 3 0 0 5 8 6 P/N 1010871 Rev.
-
Page 2: Table Of Contents
EGG STATION (ES-600 & ES-1200) Owner Information ...2 General ...2 Warranty Information ...2 Service/Technical Assistance ...3 Important Safety Information ...3 Electrical Ratings ...5 Specifications ...5 Model Designation ...5 Electrical Cord & Plug Configurations ...5 Dimensions ...6 Shipping Weight ...6 Net Weight ...6 Installation ...7 Unpacking ...7 Equipment Setup ...7... -
Page 3: Service/Technical Assistance
OWNER INFORMATION (continued) Service/Technical Assistance If you experience any problems with the installation or operation of your unit, contact your local Roundup Authorized Service Agency. They can be found in the service agency directory packaged with the equipment. Fill in the information below and have it handy when calling your authorized service agency for assistance. - Page 4 EGG STATION (ES-600 & ES-1200) IMPORTANT SAFETY INFORMATION (continued) In addition to the warnings and cautions in this manual, use the following guidelines for safe operation of the unit. • Read all instructions before using equipment. • For your safety, the equipment is furnished with a properly grounded cord connector.
-
Page 5: Electrical Ratings
- Routine cleaning should be done daily using soap, ammonia detergent and water. Electrical Ratings Model Mfg. Volts Number Number ES-600HI 9300570 ES-600HC 9300572 ES-600 9300576 ES-1200HI 9300580 ES-1200HC 9300582 ES-1200HG 9300584... -
Page 6: Dimensions
EGG STATION (ES-600 & ES-1200) Dimensions 7 9/32" Shipping Weight • ES-600: 48 lbs (21.7 kg) • ES-1200: 50 lbs (22.6 kg) SPECIFICATIONS (continued) 2'-00" 2'-30" POWER START/STOP 16 5/8" Net Weight • ES-600: 41 lbs (18.6 kg) • ES-1200: 43 lbs (19.5 kg) READY BACON COOKING... -
Page 7: Installation
Unpacking 1. Remove unit and all packing materials from ship- ping carton. NOTE: If any parts are missing or damaged, con- tact Antunes Technical Service IMMEDIATELY at 1-877-392-7854 (Toll free in the U.S. and Canada) or 630-784-1000.) 2. Remove information packet. 3. -
Page 8: Egg Cooking Procedure
EGG STATION (ES-600 & ES-1200) Preparing Unit 1. Turn the Rocker Switch (power On/Off) to ON (Figure 2). 2. Place Egg Ring into Egg Rack (Figure 3). 3. Vertically place the pins of the Egg Rack into the slots that are attached to the cover. 4. -
Page 9: Bacon Timer
Bacon Timer* If, during the standby mode, the blue Bacon LED light is not lit, it means that the Bacon Timer is disabled. To enable the Bacon Timer, with the unit turned on, press the Time 1 and Time 2 buttons simultaneously for 3 or more seconds. -
Page 10: Checking Cycle Times (Monthly)
EGG STATION (ES-600 & ES-1200) Checking Cycle Times (Monthly) CAUTION: Grill surfaces will be hot. Care should be taken when operating this piece of equipment. NOTE: A stopwatch is required for this procedure. 1. Turn the Rocker Switch (power On/Off) to ON. Allow the unit to preheat for 30 minutes. -
Page 11: Troubleshooting
To avoid possible personal injury and/or damage to the unit, inspection, test and repair of electrical equip- ment should be performed by qualified service personnel. The unit should be unplugged when servicing. Problem Unit fails to operate and No power/low power. control panel lights fail to signal on. -
Page 12: Control Board Leds
EGG STATION (ES-600 & ES-1200) TROUBLESHOOTING (continued) Control Board LEDs The Control Board has three onboard LEDs (Figure 5) to determine the status of the unit and to assist in troubleshooting. Green (Diagnostic): The LED should be off in normal operation however, if any of the 5 potential faults are detected by the Control Board, this LED will repeatedly blink either 1 through 5 times with a 2 second pause in... -
Page 13: Wiring Diagram
POWER CORD HEATER LINE LOAD FILTER P/N 1010871 Rev. D 08/05 EGG STATION (ES-600 & ES-1200) WIRING DIAGRAM NOTE: ALL WIRES TO BE 14 GA. TFE-200°C UNLESS OTHERWISE SPECIFIED. # 18 GA. TFE-200°C 22 GA. TFE-200°C ISOLATOR BOARD SWITCH BOARD TRANSFORMER 230VAC 12VAC... -
Page 14: Replacement Parts
EGG STATION (ES-600 & ES-1200) REPLACEMENT PARTS P/N 1010871 Rev. D 08/05... - Page 15 REPLACEMENT PARTS (continued) Item Part Description 0021327 Nose Piece Weldment 210K230 Bumper, Recess Leg 1” (Set of 4 including 4 screws) 7000379 Grill Platen 040P138* Lock-nut, Conduit - 1/2” NPT 0400315 Strain Relief - Cord Connector 0010192 Service Pan 0502900 Bracket , Sensor 7000363 Cover, Rack, &...
-
Page 16: Limited Warranty
Equipment manufactured by Roundup Food Equipment Division of A.J. Antunes & Co. has been constructed of the finest materials available and manufactured to high quality standards. These units are warranted to be free from mechanical and electrical defects for a period of one year from date of purchase or 18 months from shipment from factory, whichever occurs first, under normal use and service, and when installed in accordance with manufacturer’s recommendations.
