Summary of Contents for PhD Solutions PHD-VRX2
-
Page 1: Quick Start Guide
Full HD 1080p Dual Tuner Digital HDTV Recorder, Receiver and Media Center Box QUICK START GUIDE MODEL : PHD-VRX2 ©Copyright 2013, PrimeDTV Technologies, Inc. -
Page 2: Front View
To record, connect external USB Hard Drive (HDD) or USB Flash stick with either ext2 or NTFS format. PHD-VRX2 will record TV shows on the first USB device plugged in (assigned as “usba”). To Playback, connect any USB storage devices with either ext2, NTFS or FAT32 format. - Page 3 Note: PHD-VRX2 has built-in USB utility menu to test USB speed and partition USB to ext2 format. (3) VGA (RGB) w/ Audio inputs: Accept video and audio inputs from PC VGA port. (4) HDMI input: Accept HDMI input from the external devices like Blu-ray player and etc.
-
Page 4: Remote Control
Remote Control INPUT POWER Press to bring up input selection Turn PHD-VRX2 on and off ASPECT V.MODE Screen size change Toggle Display resolution (720p/1080p) SLEEP Turn on and off close caption Select preset timer for auto shut off AUDIO Instant jump to TV input and watch TV... -
Page 5: Connections And Setup
Connecting External USB Storage Devices 1. To record TV shows, plug USB 2.0 support Hard Disk Drive (HDD) or Flash stick with the size up to 2TB. PHD-VRX2 will record TV shows on the first USB device plugged in no matter which USB port. - Page 6 Connecting HDMI Input PHD-VRX2 has one HDMI input port. It can be connected to different HDMI devices such like Blu-Ray player, DVD player, PS3, HD cable or satellite boxes. Connecting Component (YPbPr)al PHD-VRX2 has one Component (Y-Pb-Pr) video input and audio (R/L) input, which can be connected to external HD devices with YPbPr output.
- Page 7 Connecting Networkal 1. Connect PHD-VRX2 Ethernet port to wired network from DSL, Cable modem or home network router. The network connection will prompt the unit to sync with NTP (Network Time Protocol) for precise timing reference as well as on-line video streaming and home network video server connection.
- Page 8 Powering Up and Initial Setup After connecting PHD-VRX2 with proper input/output sources, you need to power up unit and run initial setup including automatically scanning available channels. This initial setup is only required once during the first time turning on the unit.
