Foreseeson FS-L190*D User Manual

19”/24"/26"/32"/42"/55" medical lcd monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MEDICAL LCD MONIT
OR
MEDICAL LCD MONIT
OR
USER'S GUIDE
Before connecting, operating or adjusting this
product, please read this instruction booklet
carefully and completely.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FS-L190*D and is the answer not in the manual?

Questions and answers

Related Manuals for Foreseeson FS-L190*D

Summary of Contents for Foreseeson FS-L190*D

  • Page 1 MEDICAL LCD MONIT MEDICAL LCD MONIT USER'S GUIDE Before connecting, operating or adjusting this product, please read this instruction booklet carefully and completely.
  • Page 2 MEDICAL LCD MONITOR FS-L190*D (19”) FS-L190*DT(19”) FS-L240*D (24”) FS-L240*DT(24”) FS-L260*D (26”) FS-P260*D (26”) FS-L320*D (32”) FS-L420*D (42”) FS-L550*D (55”) Model definition F S- L X X X * D T 1. FS : Monitor manufacturer. 2. L : Panel manufacturer.

  • Page 3: Table Of Contents

    ● FS-L260*D / FS-P260*D (LED) ……………………………… 17 ● FS-L320*D …………………………………………………… 18 ● FS-L420*D / FS-L550*D……………………………………… 19 Connector ……………………………………………………… 20 ● FS-L190*D / FS-L240*D / FS-L260*D / FS-L260*D FS-L320*D …………………………………………………… 20 ● FS-L190*DT / FS-L240*DT ………………………………… 21 ● FS-L420*D / FS-L550*D …………………………………… 22 Mechanical Product Drawing ……………………………………...

  • Page 4: Symbol Definitions

    Symbol Definitions The following symbols appear on the product, its labels, or the product package. Each symbol carries a special definition, as defined below. Dangerous : High Voltage. Consult accompanying documents. Direct Current. lndicates protective earth ground. lndicates equipotential earth ground. DC Power control switch.
  • Page 5 Note: A printed copy of the manual in English is provided with the product. Users within EU member state, please contact local distributor or Foreseeson Custom Displays, Inc. for other languages or refer to the CD manual enclosed with the product. This applies to EU member state where the product has been purchased through authorized channels.

  • Page 6: Safety Instructions

    Safety Instructions On Safety 1. Before connecting the AC power cord to the DC adapter outlet make sure the voltage designation of the DC adapter corresponds to the local electrical supply. 2. Never insert anything metallic into the cabinet openings of the medical LCD monitor.
  • Page 7 Warning This medical LCD monitor is intended for connection to input/output signals and other connectors that comply with relevant IEC standard (e.g.,IEC60950 for IT equipment and IEC60601 series for medical electrical equipment). In addition, all such combination-system shall comply with the standard IEC 60601-1-1, safety requirements for medical electrical systems.
  • Page 8 10. Do not use other cable or accessary that are not provided. 11. Do not lay this monitor on the other equipment. Environmental Conditions for operation and Storage - Temperature range within 0°C to 40°C(operation), -20°C to 60°C(storage) - Relative humidity range 10% to 85% Atmospheric pressure range within 500 to 1060hPa.

  • Page 9: Caution

    CAUTION This symbol alerts the user that important literature concerning the operation of this unit has been included. Therefore, it should be read carefully in order to avoid potential problems. This symbol warns user that un-insulated voltage within the unit may have sufficient magnitude to cause electrical shock.
  • Page 10 Use 120V rating 5-15P type plug only in the U.S This medical LCD monitor complies to the above standards only when used with the supplied medical grade power supply. 19”(FS-L190*D / FS-L190*DT) - JMW190KA1200F02(BRIDGE POWER CORP.) 24”/26”(FS-L240*D / FS-L240*DT / FS-L260*D) JMW1150KA2400F04(BRIDGE POWER CORP.) 26”LED (FS-P260*D / FS-L260*D) - BPM150S24F10(BRIDGE POWER CORP.)
  • Page 11 Cleaning Instructions Follow your hospital protocol for the handling of blood and body fluids. Clean the display with a diluted mixture of mild detergent and water. Use a soft towel or swab. Use of certain detergents may cause degradation to the labels and plastic components of the product.

  • Page 12: Fcc Information

    FCC Information This medical LCD monitor unit has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against interference. This monitor can radiate radio frequency energy and, if not installed and used in accordance with the instructions, it may interfere with other radio communications equipment.
  • Page 13 1. Guidance and manufacturer's declaration - electromagnetic emissions The medical LCD monitor is intended for use in the electromagnetic environment specified below. The customer or the user of the medical LCD monitor should assure that it is used in such an environment. Emission test Electromagnetic environment -guidance Compliance...
  • Page 14 Surge 1kV differential mode 1kV differential mode Mains power quality should be that of a IEC 61000-4-5 2kV common mode 2kV common mode typical commercial or hospital environment. Portable and mobile RF communications Conducted RF 3 Vrms 3 Vrms equipment should be used no closer to any IEC 61000-4-6 150 kHz to 80MHz 150 kHz to 80MHz...
  • Page 15 IEC 60601 Test level Immunity test Compliance level Electromagnetic environment -guidance Recommended separation distance 80MHz to 800MHz 80MHz to 2.5GHz 3 V/m Radiated RF 3 V/m 80.0 MHz to 2.5 GHz IEC 61000-4-3 80.0 MHz to 2.5 GHz where P is the maximum output power rating of the transmitter in watts (W) according to the transmitter manufacturer and d is the recommended separation distance in meters...
  • Page 16 0.116 0.116 0.01 0.2333 0.368 0.3687 0.7378 1.166 1.1660 0.2333 3.687 3.6872 0.7375 11.660 11.6600 23.333 For transmitters rated at a maximum output power not listed above, the recommended separation distance d in meters (m)can be estimated using the equation applicable to the frequency of the transmitter, where p is the maximum output power rating of the transmitter in watts (W) according to the transmitter manufacturer.

  • Page 17: Parts

    Parts 19" FS-L190*D / FS-L190*DT Monitor Accessories User Manual D-SUB Cable AC-DC Adaptor S-Video (Y/C) Cable (6ft/1.8m) (JMW190KA1200F02) (Option) DVI Cable BNC Cable AC Power cord SCREW FH M3X6 (6ft/1.8m) (6ft/1.8m) (6ft/1.8/m US,UK,EU) (Hospital Grade) SCREW BH M4X10 English - 15...

  • Page 18: Fs-L240*D / Fs-L240*Dt

    24" FS-L240*D / FS-L240*DT Monitor Accessories User Manual D-SUB Cable AC-DC Adaptor S-Video (Y/C) Cable (6ft/1.8m) (JMW1150KA2400F04) (Option) DVI Cable BNC Cable AC Power cord DC Cable Terminal (6ft/1.8m) (6ft/1.8m) (6ft/1.8/m US,UK,EU) Male / female (Option) (Hospital Grade) SCREW FH M3X6 SCREW BH M4X10 16 - English...

  • Page 19: Fs-L260*D / Fs-P260*D (Led)

    26" FS-L260*D / FS-P260*D Monitor Accessories User Manual D-SUB Cable AC-DC Adaptor S-Video (Y/C) Cable (6ft/1.8m) (JMW1150KA2400F04) (Option) (BPM150S24F10) DVI Cable BNC Cable AC Power cord DC Cable Terminal (6ft/1.8m) (6ft/1.8m) (6ft/1.8/m US,UK,EU) Male / female (Option) (Hospital Grade) SCREW FH M3X6 SCREW BH M4X10 SCREW BH M4X6 English - 17...

  • Page 20: Fs-L320*D

    32" FS-L320*D Monitor Accessories User Manual D-SUB Cable AC-DC Adaptor S-Video (Y/C) Cable (6ft/1.8m) (JMW1180KA2400F01) (Option) DVI Cable BNC Cable AC Power cord DC Cable Terminal (6ft/1.8m) (6ft/1.8m) (6ft/1.8/m US,UK,EU) Male / female (Option) (Hospital Grade) SCREW FH M3X6 SCREW BH M4X10 Remote controller Battery(AAA) 18- English...

  • Page 21: Fs-L420*D / Fs-L550*D

    42" FS-L420*D / 55” FS-L550*D Monitor Accessories User Manual D-SUB Cable S-Video (Y/C) Cable DVI Cable(6ft) (6ft/1.8m) (Option) BNC Cable Battery(AAA) AC Power cord Remote controller (6ft/1.8m) (6ft/1.8/m US,UK,EU) (Hospital Grade) English - 19...

  • Page 22: Connector

    Connector FS-L190*D / FS-L240*D / FS-L260*D / FS-P260*D / FS-L320*D Input connector ▶ DVI fiber optic input DC INLET S-VIDEO /Y DC ON/OFF SWITCH S-VIDEO /C OPTICAL IN C-VIDEO DVI IN RED /Pr DVI OUT GREEN /Y VGA IN BLUE /Pb...

  • Page 23: Fs-L190*Dt / Fs-L240*Dt

    FS-L190*DT / FS-L240*DT input connector ▶ DVI fiber optic input DC INLET SDI OUT DC ON/OFF SWITCH S-VIDEO /Y OPTICAL IN S-VIDEO /C DVI IN C-VIDEO DVI OUT RED /Pr VGA IN GREEN /Y GPIO BLUE /Pb USB TOUCH C-SYNC/H-SYNC SERIAL TOUCH V-SYNC RS232C...

  • Page 24: Fs-L420*D / Fs-L550*D

    FS-L420*D / FS-L550*D Input connector ▶ DVI fiber optic input AC ON/OFF SWITCH S-VIDEO /Y AC INLET S-VIDEO /C OPTICAL IN C-VIDEO DVI IN RED /Pr DVI OUT GREEN /Y VGA IN BLUE /Pb GPIO C-SYNC/H-SYNC RS232C V-SYNC SDI IN EARTH GROUND SDI OUT ▶...

  • Page 25: Mechanical Product Drawing

    Mechanical Product Drawing 19” FS-L190*D / FS-L190*DT Dimension Front view 76.5 OSD MEMBRANE SWITCH Rear view (Without I/O Cover) Rear view (Installed I/O Cover) 4-M4X12(VESA MOUNT HOLE) 4-M4X12(VESA MOUNT HOLE) Unit : mm English - 23...

  • Page 26: 24" Fs-L240*D / Fs-L240*Dt

    24” FS-L240*D / FS-L240*DT Dimension Front view OSD MEMBRANE SWITCH Rear view (Installed I/O Cover) Rear view (Without I/O Cover) 4-M4X12(VESA MOUNT HOLE) 4-M4X12(VESA MOUNT HOLE) Unit : mm 24 - English...

  • Page 27: 26" Fs-L260*D

    26” FS-L260*D Dimension Front view 99.5 55.5 OSD MEMBRANE SWITCH Rear view (Installed I/O Cover) Rear view (Without I/O Cover) 4-M4X12(VESA MOUNT HOLE) 4-M4X12(VESA MOUNT HOLE) Unit : mm English - 25...

  • Page 28: 26" Fs-L260*D (Led) / Fs-P260*D (Led)

    26” FS-L260*D(LED) / FS-P260*D(LED) Dimension Front view Rear view (Without I/O Cover) Rear view (Installed I/O Cover) Unit : mm 26 - English...

  • Page 29: 32" Fs-L320*D

    32” FS-L320*D Dimension Front view OSD MEMBRANE SWITCH Rear view (Installed I/O Cover) Rear view (Without I/O Cover) 4-M4X12(VESA MOUNT HOLE) 4-M4X12(VESA MOUNT HOLE) 4-M6(VESA MOUNT HOLE) 4-M6(VESA MOUNT HOLE) Unit : mm English - 27...

  • Page 30: 42" Fs-L420*D

    42” FS-L420*D Dimension Front view 111.1 1024.6 55 50 OSD MEMBRANE SWITCH Rear view 10-M8(USER MOUNT HOLE) Unit : mm 28 - English...

  • Page 31: 55" Fs-L550*D

    55” FS-L550*D Dimension Front view 1293 86.3 1213.6 36.3 OSD MEMBRANE SWITCH Rear view 6-M8(VESA MOUNT HOLE) Unit : mm English - 29...

  • Page 32: Control

    Control OSD Button An 8 button keypad, located in bottom right corner on the front of the display, allows the user to make adjustments to various display parameters using the On Screen Display (OSD) system. ● Power Indicating LED Normal mode (ON): Green Standby mode : Blinking Green Off mode...
  • Page 33 6. PLUS (+) : With the OSD deactivated, it is a Hot key for increasing contrast. With the OSD activated, enter sub menu and increases the adjustment of the selected function. 7. MINUS (-) : With the OSD deactivated, it is a Hot key for increasing contrast. With theOSD activated, it decreases the adjustment of the selected function.
  • Page 34 Remote button function <Notice> Remote control is available in FS-L320*D / FS-L420*D / FS-L55*D models only. 1. SOURCE : Changes the display signal source. 2. POWER : Soft power turns the monitor ON or OFF. 3. UP (▲) : With the OSD deactivated,it is a Hot key for increasing brightness. With the OSD activated, moves the cursor upward.
  • Page 35 GPIO There are four pins on the RJ69 GPIO connector. Each pin has a preprogrammed function assigned to it. The function is initiated when the pin is grounded. Pin 1. Primary and Secondary Swap. Pin 3. Record Indicator The record indicator is displayed in the Grounding this pin will swap the primary and secondary image.

  • Page 36: Power Management

    Power management This monitor does not adhere to the VESA DPMS standard when no signal is present on the video input. Model Status LED sign Power Consumption FS-L190*D Normal mode Green on <60W Standby mode Green blinking <20W FS-L190*DT Normal mode Green on <60W...

  • Page 37: Osd

    DSUB ANALOG / RGBS input source ADJUST 1. BRIGHTNESS A D J U S T Increases or decreases the brightness. (Range : 0~100) B R I G H T N E S S 2. CONTRAST C O N T R A S T Increases or decreases the contrast.
  • Page 38 SETUP 1. LANGUAGE S E T U P Changes the OSD language (8 language) L A N G U A G E E N G L I S H 2. OSD COLOR O S D C O L O R Adjusts the OSD background from white opaque to translucent.

  • Page 39: Color Temp

    DVI OPTICAL / DVI DIGITAL input source ADJUST 1. BRIGHTNESS A D J U S T Increases or decrease the brightness. (Range : 0~100) B R I G H T N E S S 2. CONTRAST C O N T R A S T Increases or decreases the Contrast.
  • Page 40 SETUP 1. LANGUAGE S E T U P Changes the OSD language (8 language) L A N G U A G E E N G L I S H 2. OSD COLOR O S D C O L O R Adjusts the OSD background from white opaque to translucent.
  • Page 41 YPbPr input source ADJUST 1. BRIGHTNESS A D J U S T Increases or decreases the brightness. (Range : 0~100) B R I G H T N E S S 2. CONTRAST C O N T R A S T Increases or decreases the Contrast.
  • Page 42 SETUP 1. LANGUAGE S E T U P Changes the OSD language (8 language) L A N G U A G E E N G L I S H 2. OSD COLOR O S D C O L O R Adjusts the OSD background from white opaque to translucent.
  • Page 43 SVIDEO / CVIDEO input source ADJUST 1. BRIGHTNESS A D J U S T Increases or decreases the brightness. (Range : 0~100) B R I G H T N E S S 2. CONTRAST C O N T R A S T Increases or decreases the Contrast.
  • Page 44 SETUP 1. LANGUAGE S E T U P Changes the OSD language (8 language) L A N G U A G E E N G L I S H 2. OSD COLOR O S D C O L O R Adjusts the OSD background from white opaque to translucent.
  • Page 45 SDI input source ADJUST 1. BRIGHTNESS A D J U S T Increases or decreases the brightness. (Range : 0~100) B R I G H T N E S S 2. CONTRAST C O N T R A S T Increases or decreases the Contrast.
  • Page 46 SETUP 1. LANGUAGE S E T U P Changes the OSD language (8 language) L A N G U A G E E N G L I S H 2. OSD COLOR O S D C O L O R Adjusts the OSD background from white opaque to translucent.
  • Page 47 OSD System overview Menus Function Descriptions BRIGHTNESS Press the BRIGHTNESS botton to display the ADJUST menu or UP,DOWN hot key. Setting the brightness too high or too low will decrease the amount of visible grayscales. CONTRAST Press the CONTRAST button to display the ADJUST menu or +,- hot key. Setting the Contrast too high or too low will cause loss of some grascales.

  • Page 48: Function Descriptions

    Menus Function Descriptions H POSITION Adjusts the Horizontal position of the image. It will return to the default state when executing AUTO ADJUST or RESET SETTINGS. V POSITION Adjusts the Verticall position of the image. It will return to the default state when executing AUTO ADJUST or RESET SETTINGS.
  • Page 49 Menus Function Descriptions IMAGE SETTING Saves 5 user’s settings : BRIGHTNESS,CONTRAST,BACKLIGHT,COLOR,TEMP and FILTER separately.(PRESET1,2 / USER 1,2,3) ZOOM / PAN Controls the zoom in/out of the image. 0 Step : 4 Step : 9 Step : 13 Step : 18 Step : 22 Step : 26 Step : 30 Step :...
  • Page 50 Menus Function Descriptions OSD DURATION Adjusts the time the OSD menu remains on the screen. RESET SETTING Resets the monitor back to factory settings.. AUTO SOURCE When AUTO SOURCE SELECT is on, the monitor will automatically search for an active MAIN SELECT input Source.
  • Page 51 Menus Function Descriptions SWAP Changes main window and sub window position in PIP,PBP1,PBP2. PBP1 PBP2 3D MODE 2D to 3D Mode. (FS-L260*D,LED Model only) OFF (2D Mode) ON (3D Mode) SIDE BY SIDE MODE SIDE BY SIDE ON SIDE BY SIDE OFF 3D DEPTH Changes the 3D depth step 1 to step 15.

  • Page 52: Standard Signal Table

    Standard Signal table PC Supported Mode Horizontal Clock Vertical Resolution Frequency Frequency Frequency (KHz) (MHz) (Hz) 640 X 350 @70Hz 25.17 31.50 70.00 720 X 400 @70Hz 31.50 28.32 70.00 640 X 480 @60Hz 31.50 60.00 25.18 640 X 480 @75Hz 37.50 75.00 31.50...

  • Page 53: Signal Connector Pin Assignments

    Signal connector Pin Assignments VGA (15Pin D-SUB) Pin No. Assignment Pin No. Assignment No Connection Green Ground-Sync Blue Ground Ground DDC Data DDC 5V Standby H.Sync Cable Connection check V.Sync Ground-Red DDC Clock Ground-Green Ground-Blue DVI In,Out (24Pin DVI-D) Pin No. Assignment Pin No.
  • Page 54 S-Video (BNC) Pin No. Assignment S-VIDEO/Y (Luma) S-VIDEO/C (Chroma) Ground RS232C (D-SUB 9Pin) Pin No. Assignment No Connection No Connection Ground No Connection No Connection No Connection No Connection SDI (BNC) Pin No. Assignment SDI IN SDI OUT Ground 52 - English...
  • Page 55 RGBHV/RGBS/YPbPr (BNC) Assignment Pin No. RGBS Y Pb Pr Green Blue CS/HS B/Pb R/Pr H-Sync / C-Sync No Connection V-Sync No Connection Ground OPTICAL Pin No. Assignment OPTICAL Clock OPTICAL Blue OPTICAL Green OPTICAL Red GPIO Pin No. Assignment P,S Swap PIP,PBP1,PBP2 Select Record lndicator Ground...

  • Page 56: Specification

    Specification FS-L190*D / FS-L190*DT Model FS-L190*D / FS-L190*DT Type 19” TFT-LCD Screen Size 19 inch(5:4) Maximum Resolution 1280 X 1024 @ 60Hz Pixel Pitch 0.294(H) mm X 0.294(V) mm Optical Display Colors 16.7M Characteristics Contrast Ratio(Typical) 800:1 Viewing Angle 85° / 85° / 85° / 85°...

  • Page 57: Fs-L240*D / Fs-L240*Dt

    FS-L240*D / FS-L240*DT MODEL FS-L240*D / FS-L240*DT Type 24” TFT-LCD Screen Size 24 inch(16:10) Maximum Resolution 1920 X 1200 @ 60Hz Pixel Pitch 0.270(H) mm X 0.270(V) mm Optical Display Colors 1.06Billion Characteristics Contrast Ratio(Typical) 1000:1 Viewing Angle 89° / 89° / 89° / 89° Response Time 6 msec(Rising+Falling) ㎡...

  • Page 58: Fs-L260*D

    FS-L260*D MODEL FS-L260*D Type 26” TFT-LCD Screen Size 26 inch(16:10) Maximum Resolution 1920X 1200 @ 60Hz Pixel Pitch 0.2685(H) mm X 0.2685(V) mm Optical Display Colors 16.7M Characteristics Contrast Ratio(Typical) 1000:1 Viewing Angle 89° / 89° / 89° / 89° Response Time 6 msec(Rising+Falling) ㎡...

  • Page 59: Fs-L260*D(Led)

    FS-L260*D(LED) MODEL FS-L260*D(LED) Type 26” TFT-LCD Screen Size 26 inch(16:9) Maximum Resolution 1920X 1080 @ 60Hz Pixel Pitch 0.3(H) mm X 0.3(V) mm Optical Display Colors 16.7M Characteristics Contrast Ratio(Typical) 1000:1 Viewing Angle 89° / 89° / 89° / 89° Response Time 6 msec(Rising+Falling) ㎡...

  • Page 60: Fs-P260*D(Led)

    FS-P260*D(LED) MODEL FS-P260*D(LED) Type 26” TFT-LCD Screen Size 26 inch(16:9) Maximum Resolution 1920X 1080 @ 60Hz Pixel Pitch 0.3(H) mm X 0.3(V) mm Optical Display Colors 1.06B Characteristics Contrast Ratio(Typical) 1400:1 Viewing Angle 89° / 89° / 89° / 89° Response Time 8 msec(Rising+Falling) ㎡...

  • Page 61: Fs-L320*D

    FS-L320*D MODEL FS-L320*D Type 32” TFT-LCD Screen Size 32 inch(16:9) Maximum Resolution 1920X 1080 @ 60Hz Pixel Pitch 0.363(H) mm X 0.363(V) mm Optical Display Colors 1.06 billion Characteristics Contrast Ratio(Typical) 1300:1 Viewing Angle 89° / 89° / 89° / 89° Response Time 6msec(Rising+Falling) ㎡...

  • Page 62: Fs-L420*D

    FS-L420*D MODEL FS-L420*D Type 42” TFT-LCD Screen Size 42 inch(16:9) Maximum Resolution 1920X 1080 @ 60Hz Pixel Pitch 0.4845(H) mm X 0.4845(V) mm Optical Display Colors 1.06 billion Characteristics Contrast Ratio(Typical) 1300:1 Viewing Angle 89° / 89° / 89° / 89° Response Time 6 msec(Rising+Falling) ㎡...

  • Page 63: Fs-L550*D

    FS-L550*D MODEL FS-L550*D Type 55” TFT-LCD Screen Size inch(16:9) Maximum Resolution 1920X 1080 @ 60Hz Pixel Pitch 0.630(H) mm X 0.630(V) mm Optical Display Colors 1.06 billion Characteristics Contrast Ratio(Typical) 1300:1 Viewing Angle 89° / 89° / 89° / 89° Response Time 6 msec(Rising+Falling) ㎡...

  • Page 64: English

    ■ FORESEESON KOREA Gangnam main Tower #801, 1357-66 Seo-cho Dong Seo-cho Gu Soule Korea, 137-070 Tel.+82(2)521-5296 Fax. +82(2)521-5207 ■ FORESEESON CUSTOM DISPLAY INC 2210 E. Winston Road, Anaheim, CA 92806 USA http://www.foreseesonusa.com Tel.1-714-300-0540 Fax. 1-714-300-0546 EC Representative ■ FORESEESON GMBH Benzstr.9 61352.

This manual is also suitable for:
