VCL-MX Version 6 - E1 160Mbps Voice & Data Multiplexer

VCL-MX Version 6

80 E1, 160Mbps Voice & Data Multiplexer

System Guide

Orion Telecom Networks Inc.

16810, Avenue of Fountains,

Suite # 108, Fountain Hills,

AZ 85268 USA

PH: (+1) 480-816-8672,

FAX: (+1) 480-816-0115

E-mail: sales@oriontelecom.com

Web Site: http://www.oriontelecom.com

Orion Telecom Networks Inc. – 2013-2014

Table of Contents

Need help?

Do you have a question about the VCL-MX and is the answer not in the manual?

Questions and answers

Summary of Contents for Orion VCL-MX

Page 1 VCL-MX Version 6 - E1 160Mbps Voice & Data Multiplexer VCL-MX Version 6 80 E1, 160Mbps Voice & Data Multiplexer System Guide Orion Telecom Networks Inc. 16810, Avenue of Fountains, Suite # 108, Fountain Hills, AZ 85268 USA PH: (+1) 480-816-8672, FAX: (+1) 480-816-0115 E-mail: sales@oriontelecom.com...
Page 2 VCL-MX Version 6 - E1 160Mbps Voice & Data Multiplexer Warranty This Orion product is warranted against defects in material and workmanship for a period of one year from the date of shipment. During the warranty period, Orion will, at its discretion, either repair or replace products, which prove to be defective.
Page 3: Table Of Contents
VCL-MX Version 6 - E1 160Mbps Voice & Data Multiplexer Index S. No. Particulars Page No. Foreword Product Overview Key Features Additional Features Highlights Security and Password Features Transmission Mediums Multi-service platform Configuration and Flexibility Synchronization Application of VCL-MX System Overview and Architectural Details...
Page 4: Foreword
- 80 E1, 160Mbps Multiplexer. This user guide also gives an overview of the various applications in which VCL-MX Version 6 - 80 E1, 160Mbps Multiplexer can be used. These are explained with the use of application diagrams. These application diagrams are useful for the Network planning and design engineers.
Page 5: Product Overview
This technology offers savings on investments/power and space to service providers. Orion Telecom Networks, Inc., USA provides efficient solutions in this field using the E1 Multiplexer series products. E1 Multiplexer provides a full range of solutions in this evolving field of next generation telecom solutions.
Page 6: Additional Features
• Any combination ("mix-n-match") of Voice and Digital Data services deployed from a single • VCL-MX "Smart Shelf” - 4, 8, 12, 16 channels per card Integrated IEEE C37.94 Teleprotection Interface • Digital Data option may be used for internet access or video conferencing application •...
Page 7: Security And Password Features
Report Generation / Audit Trail • Security Administration. • Transmission Mediums The VCL-MX offers an excellent flexibility on the choice of transmission medium over which it may be deployed. The transmission medium can be either of the following: Copper • Optical Fiber •...
Page 8: Configuration And Flexibility
• Configuration and Flexibility VCL-MX Version 6 - E1 160Mbps Multiplexer can be configured as an Add-Drop Multiplexer (ADM) and Terminal Multiplexer (TMUX). It can support diverse topologies like point-to-point, ring, star and tree. It can be configured in various topologies supporting both electrical and optical interfaces. It can take modular cards, which would enable the customers to start small and grow as traffic demands scale.
Page 9: Application Of Vcl-Mx
E1 Link. The VCL-MX is a simple, yet powerful E1 Channel Bank for connecting and integrating analog communication equipment with digital E1 services.
Page 10: Front View
VCL-MX Version 6 - E1 160Mbps Voice & Data Multiplexer Front View Orion Telecom Networks Inc. – 2013-2014...
Page 11: Back View
VCL-MX Version 6 - E1 160Mbps Voice & Data Multiplexer Back View The Multiplexer may be used in Terminal or Drop-Insert configuration to provide: Toll Quality Voice Services • Interconnect LAN (Campus Network) • Interconnect computer terminals various types of data terminals •...
Page 12: Data Interfaces
All connections are made at the rear of the chassis, providing interconnections between the various plug-in cards and to the network. VCL-MX Version 6 - E1 160Mbps Multiplexer and supports high- density PDH cards. The line cards terminate a combination of Voice, Data and E1 Interfaces.
Page 13: Technical Specifications
VCL-MX Version 6 - E1 160Mbps Voice & Data Multiplexer Technical Specifications: E1 Interface: (Part No. VCL-MX-1520-E1-5.0) Maximum number of interface cards As per requirement and upto 10 (in a single chassis) Used to map with Voice and Data Interface...
Page 14 VCL-MX Version 6 - E1 160Mbps Voice & Data Multiplexer FXS, Voice Frequency Interface: (Part No. VCL-MX-1525-16-5.0) Maximum number of interface cards Number of channels per card FXS, Interface type A-law, 8 bit/sample, A=87.6 / 87.7, 13 segment coding Maximum number of channels...
Page 15 Overload level +3.14 dBm ± 0.5 dBm Dialing Ring-down E&M 2 Wire / 4 Wire Voice Frequency Interface (Part No. VCL-MX-1535-08-5.0) Number of channels per card Maximum number of interface cards Maximum number of channels 2W / 4W E&M, Type II and Type V Interface type A-law, 8 bit/sample, A=87.6 / 87.7, 13 segment coding...
Page 16 Stop bits 1 / 1.5 / 2 (auto-select) Parity Even / Odd / 0’s / 1’s / none (auto-select) GEN GEN / Magneto / Local Battery Interface Card: (Part No. VCL-MX-1587) Number of channels per card Magneto, 2-wire (GEN-GEN) Interface type A-law, 8 bit/sample, A=87.6 / 87.7, 13 segment coding...
Page 17 VCL-MX Version 6 - E1 160Mbps Voice & Data Multiplexer Longitudinal balance ≥ 46 dB between 300Hz to 3400Hz Overload level +3.14 dBm ± 0.5 dBm High Speed Data Interface Asynchronous 50bps to 115.2Kbps Asynchronous Data Interface (Part No. VCL-MX-1558-04-48AHS) Interface RS232, RS485, V.24...
Page 18 VCL-MX Version 6 - E1 160Mbps Voice & Data Multiplexer BRI ISDN, 2B+D Interface Card: (Part # VCL-MX-1550-04-5.0) BRI ISDN Interface "U" Interface Compliance Meets ANSI T1.601-1992 requirements Bit Rate 160 Kbits/s Frame Format 2B+D as per ITU-T (CCITT) Rec.1.430 Line Code 2B1Q as per ITU-T (CCITT) Rec.G.961...
Page 19 VCL-MX Version 6 - E1 160Mbps Voice & Data Multiplexer Dry Contacts Sensors Maximum number of dry contact sensors Maximum current 50 mA Typical current 20 mA Reference source voltage 3.3 Volts Universal Data Interface: High Speed Synchronous “n x 64” Data Interface Type - User Configurable DCE-DTE: (Part No.
Page 20 VCL-MX Version 6 - E1 160Mbps Voice & Data Multiplexer 8 E1 Plus 100Mbps Ethernet Fiber Optical Transport Interface (Part No. VCL-MX-1551-5.0-WLWL-DKM) Optical Number of optical ports 1+1 redundant, automatic link protection Channel capacity 8E1 Plus 100Mbps Ethernet Jitter character ITU-T G.742, G.823 complaint...
Page 21: Protection
VCL-MX Version 6 - E1 160Mbps Voice & Data Multiplexer Integrated IEEE C37.94 Teleprotection Interface (Part No. VCL-MX-1552-MM) Number of ports Standards IEEE C37.94 850nm Multi Mode (2KM) Optical 1310nm Multi Mode (2KM) Optical connector FC-PC / ST-PC / LC...
Page 22: Power Consumption
VCL-MX Version 6 - E1 160Mbps Voice & Data Multiplexer Power Consumption Power Consumption 50 to 200 watts depending upon configuration EMI, EMC, Surge Withstand and other Compliances EN 50081-2 EN 50082-2 IEC 60068-2-29 IEC 61000-4-6 (Conducted Immunity). IEC 60068-2-6...
Page 23: Dimensions
The VCL-MX Version 6 - E1 160Mbps Multiplexer can be configured in Linear and Bus architectures. It can be used in the core of the network to provide high-speed backbone network. The VCL-MX Version 6 - E1 160Mbps Multiplexer could provide the core for cellular or mobile networks between Mobile Switching Centers with subtended.
Page 24 VCL-MX Version 6 - E1 160Mbps Voice & Data Multiplexer Application Diagram Application 1: Providing Voice and Data Services on Microwave Radio Links VCL-MX E1, 160Mbps Voice & Data Multiplexers Connecting over Digital Microwave Radio Links Application 2: Providing Voice and Data Services on Optical Fiber VCL-MX E1, 160Mbps Voice &...
Page 25 VCL-MX Version 6 - E1 160Mbps Voice & Data Multiplexer Application 3: Transporting E & M Channels VCL-MX E1, 160Mbps Voice & Data Multiplexer Connecting at the Central Office/Switch - E & M Interfaces Application 4 VCL-MX E1, 160Mbps Voice & Data Multiplexer...
Page 26 VCL-MX Version 6 - E1 160Mbps Voice & Data Multiplexer Application 5: Providing Synchronous “n x 64” Kbps Data Interfaces VCL-MX E1, 160Mbps Voice & Data Multiplexer Providing Synchronous (V.11, X.21, V.35, V.36, RS422, RS530) “n x 64” Kbps Data Interfaces...
Page 27 VCL-MX Version 6 - E1 160Mbps Voice & Data Multiplexer Application 6: Providing Voice and Synchronous “n x 64” Kbps Data Interfaces VCL-MX E1, 160Mbps Voice & Data Multiplexer Providing Voice and Synchronous (V.11, X.21, V.35, V.36, RS422, RS530) “n x 64” Kbps Data Interfaces...
Page 28 VCL-MX Version 6 - E1 160Mbps Voice & Data Multiplexer Application 7: For providing Hybrid Voice and Data Services Orion Telecom Networks Inc. – 2013-2014...
Page 29 VCL-MX Version 6 - E1 160Mbps Voice & Data Multiplexer Application 8: VCL-MX E1, 160Mbps Voice & Data Multiplexer used in Add-Drop, Tree and Star Configuration Orion Telecom Networks Inc. – 2013-2014...
Page 30: Ordering Information
VCL-MX Version 6 - E1 160Mbps Voice & Data Multiplexer Ordering Information VCL-MX E1 Core System (Common Equipment) S. No. Part # Product Description E1 Control Card Central processor, cross-connect and system control Card VCL-MX-1500 may be used in a 1 + 1 redundant Configuration...
Page 31: Support
VCL-MX Version 6 - E1 160Mbps Voice & Data Multiplexer 8 Port, VF, E&M 2 Wire / 4 Wire Interface Card 64Kbps/Sec. (Programmable Tx and Rx settings / VF range -30 VCL-MX-1535-08-5.0 dB to +7dB in steps of 0.5 dB)
Page 32 VCL-MX Version 6 - E1 160Mbps Voice & Data Multiplexer 4 Port, High Speed RS232, RS485, V.24 (V.24/V.28 Line VCL-MX-1558-04-48AHS Drivers) 50bps to 115.2Kbps, DTE / DCE Asynchronous Data Interface Card (9 Cards / 72 Ports (Max) per Chassis) 8 Port, RS232 (V.24/V.28 Line Drivers) 50bps to 19.2Kbps DCE VCL-MX-1559-08-5.0...
Page 33 VCL-MX Version 6 - E1 160Mbps Voice & Data Multiplexer VCL-HRNS 1247- 75 Ohms Connectorized Cable (BNCM-BNCM, 3m) VCL-HRNS 1247- 75 Ohms Connectorized Cable [BNCM-BNCM, 5 meter] VCL-HRNS 1247- 75 Ohms Connectorized Cable [BNCM-BNCM, 10 meter] VCL-HRNS FXS/FXO/HTL 8 Port Connectorized Cable [DB25M-Open]...
Page 34 VCL-MX Version 6 - E1 160Mbps Voice & Data Multiplexer VCL-MX Version 6, TeleProtection (User Configurable Interfaces) S. No. Part # Product Description 4 Port, Integrated IEEE C37.94 Optical Interface, Duplex FC, 20KM, 1310nm, Single-Mode (SM) Teleprotection Interface Card used to connect upto 4, VCL-TP Teleprotection Terminals.
Page 35 VCL-MX Version 6 - E1 160Mbps Voice & Data Multiplexer Notes: Technical specifications are subjects to changes without notice. Revision 4.8 – June 10, 2014. Orion Telecom Networks Inc. 16810, Avenue of Fountains, Suite # 108, Fountain Hills, AZ 85268 USA...
