USER MANUAL
Model DTC-3010
DIGITAL CABLE RECEIVER
©
IndusInd Media & Communications Limited
for
v12041.9
Set Top Box USER MANUAL
Dear Subscriber,
Congratulations for choosing the digital service from IN Digital. Now, you can take total control of your
entertainment and avail of the best that digital television has to offer.
In our continuing commitment to you, our valuable subscriber, we present the digital Set Top Box (STB) -
your gateway to a whole new world of high quality pictures and sounds on your television. The STB also
comes with an in-built electronic program guide and an all-new remote control to make for the best
possible viewing experience.
The IN Digital service brings to you everything from program schedules /synopsis to 24/7 customer support
at your fingertips.
Welcome to the digital experience
Welcome to IN Digital
TECHNICAL SPECIFICATIONS
•
Memory of 8 MB Flash and 128 MB DDRAM.
•
Embedded Conditional Access System (CAS) Nagravision.
•
Software Update over the DVB Cable Network.
•
Radio Frequency Range 47 to 862 MHz for both VHF and UHF reception.
•
QAM 16 / 32 / 64 / 128 / 256 demodulation support (EN 300429).
•
Symbol Rate of 1.7 to 7M Symbols/sec.
•
Input and Output termination resistance 75 Ohms each.
•
Supports both PAY and Digital Free-To-Air channels.
•
Advanced Electronic Program Guide & Parental lock.
•
Automatic silent Channel List Update while using the device.
•
Prepared for PVR functionality via USB (Functionality to be activated by software update)
Digital Video Broadcast (DVB) Cable Standard ETS 300429 compliant Digital Set Top Box
based on NOVABASE DIGITAL TV TECHNOLOGIES technology (Germany – France – Portugal)
Model DTC-3010
with Conditional Access System (CAS) Nagravision
The package consists of
•
Digital Set-Top-Box unit with 12V DC Adaptor.
•
HDMI Cable (1.5 meters length).
•
Remote Control unit with 2 x 'AAA' type batteries.
•
User Manual in English.
2
Advertisement
Table of Contents
Related Manuals for in digital DTC-3010
Summary of Contents for in digital DTC-3010
-
Page 1: User Manual
Set Top Box USER MANUAL Dear Subscriber, Congratulations for choosing the digital service from IN Digital. Now, you can take total control of your entertainment and avail of the best that digital television has to offer. In our continuing commitment to you, our valuable subscriber, we present the digital Set Top Box (STB) - your gateway to a whole new world of high quality pictures and sounds on your television. - Page 2 Set Top Box USER MANUAL Set Top Box USER MANUAL TABLE OF CONTENTS Your REMOTE CONTROL Your Remote Control................4 Favourites Connecting your Digital Set-Top-Box.............. 5 Open favourite list On/Off Go into Standby/Wake up from Mute Insert your Smartcard................5 Standby Mute audio Operation &...
- Page 3 Set Top Box USER MANUAL Set Top Box USER MANUAL Connecting your Digital Set-Top-Box OPERATION & RECEIVER FUNCTIONS a. First Steps Refer to the page 5 to connect your Digital Set Top Box to your TV. Follow the steps below when using your box for the first time.
- Page 4 Set Top Box USER MANUAL Set Top Box USER MANUAL c. Channel Installation by User f. Electronic Program Guide - EPG Your STB is updating your channel list automatically while you are enjoying your digital programme. • Press the EPG key to enter the Electronic Whenever you want to reinstall or add channels you can Programme Guide (EPG).
- Page 5 Set Top Box USER MANUAL Set Top Box USER MANUAL TROUBLESHOOTING h. Parental Control Symptom Possible cause Remedy Your box has child protection options. Select the ‘Parental No picture and no sound Input cable connectors not fully Check Input cable connectors Control’...
- Page 6 • Please refer to the troubleshooting tips to resolve any problems with the STB. • Only IN Digital trained personnel are authorized to conduct repairs. Noncompliance can result in the warranty being null and void. • Please make sure that the air vents of the box are not covered by anything to avoid temperature jam in the device.
