Goalzero RockOut Speakers User Manual

Get to Know Your Gear
Getting Started
1. Be sure to ACTIVATE YOUR WARRANTY at www.GOALZERO.com/warranty
2. Connect the ROCK OUT to your audio player with the audio input cord.
3. Turn it on to start playing.
4. Recharge through any USB power source, with included USB cable.
How to Use
Audio input cord
Plug your audio device into the built-in 3.5mm audio input.
Power switch and Power LED
Slide power switch to "ON." Red indicates power is on.
HANG IT
Use the elastic cord to attach the
USB-mini charging port and Charging LED
speaker to your pack or ride.
Charge directly from any USB power source, with included USB
PROTECT IT
cable. Red light indicates charging and turns off when full.
Audio device and cable fit neatly
inside the internal pocket.
Audio output port
CONNECT IT
Chain an additional ROCK OUT speaker through this port.
Input cord works with any
standard headphone jack.
RECHARGE IT
Recharge directly from any USB power
source with the included cable.
CHAIN IT
Chain multiple speakers together
for even more boom.
ROCK IT
The wooden sound box produces an
impressively full range of sound.
Mini-USB, Audio output Power switch,
Charging LED port (chaining) Power LED
Technical Specs
Usage
Run time Up to 20 hours
Recharge time 2 hours
Inputs
Charging port Mini-USB jack, 5V
Audio input cord 3.5mm male plug, line-level
Outputs
Audio output port 3.5mm female audio jack, line-level (chaining)
Internal
Speakers 2x 40mm, 4 ohm, 2W drivers
Amplifier Stereo, 2W max, 70dB SNR, 70Hz-18KHz
Battery Lithium-ion, 3.7V, 0.6Ah (2.0 Wh)
Battery mgmt. Integrated and fully automatic
General
Weight 14.4 oz (0.40 kg)
Dimensions 6x5x3 in (15 x 12.7 x 7.6 cm)
Warranty 12 months
Certifications CE and FCC
Optimal operating temp. 32-104ºF (0-40ºC)
Comes With
charging cable
Mini-USB
Audio input cord (built-in, 3.5mm plug, 300mm cord)
