BC-450

BATTERY CHARGER

Instruction Manual

BEFORE USING OUR BATTERY CHARGER, READ IN DETAILS

ALL INSTRUCTIONS CONTAINED IN THIS MANUAL. KEEP

THIS MANUAL IN A SAFE PLACE AS YOU MAY NEED TO USE

IT LATER.

We draw the attention of all users of this device: please follow

the safety and maintenance instructions which are part of this

manual. Also read the caution markings on the charger, the

manual, and the gift box.

Table of Contents

Need help?

Do you have a question about the BC-450 and is the answer not in the manual?

Questions and answers

Summary of Contents for Digimaksas BC-450

Page 1: Battery Charger
BC-450 BATTERY CHARGER Instruction Manual BEFORE USING OUR BATTERY CHARGER, READ IN DETAILS ALL INSTRUCTIONS CONTAINED IN THIS MANUAL. KEEP THIS MANUAL IN A SAFE PLACE AS YOU MAY NEED TO USE IT LATER. We draw the attention of all users of this device: please follow the safety and maintenance instructions which are part of this manual.
Page 2 INTRODUCTION: Congratulations on purchasing this intelligent charging unit, which enables definitely quick and optimum charging to “AA” and “AAA” rechargeable batteries. With charging functions as well as individual LCD displays for the charging compartments, this charging unit is reliable, user-friendly and ideal for use in the home, office or on journey. The Charging unit CAUTIONS: The charger is restricted to charging NiCd and NiMH...
Page 3 Always follow the charging instructions for the rechargeable battery. Never use other kinds of the power cable and transformer apart from those originally supplied with the charging unit. The rechargeable battery may become hot during charging. User should take extra care when taking out the battery after charging. Unplug the charging unit from the power source when it is not in use.
Page 4: Inventory Of Contents
Test function to check the capacities of rechargeable batteries.  The LCD of charger displays the different operating status of  different modes. Trickle charging is available after the rechargeable battery is fully  charged. To prevent overcharge, charger timer is available to limit the ...
Page 5 START CHARGING THE RECHARGEABLE BATTERIES After the transformer has been plugged into the power source (Figure 1), user should insert a rechargeable battery into the charging unit and plug the DC jack into the battery charger. Shortly afterwards, the battery voltage (for example, “1.38V”) and the “CHARGE”...
Page 6: Setting Up The Charger
OPERATING MODES OF THE CHARGING UNIT This powerful charging unit provides three operating modes: Charge up the rechargeable battery (CHARGE) – to charge up the rechargeable battery, automatically switch to trickle charge after rechargeable battery is full. Discharge then charge up the rechargeable battery (DISCHARGE) –...
Page 7: Charging Mode
has to take off and reinstall all batteries for selecting the new mode. Only one mode can be used for all compartments at the same time! CHARGING MODE The unit can charge up the rechargeable battery. It will automatically switch to trickle charging after the rechargeable battery is fully charged. During the process of charging, the display of voltage (Figure 2) and percentage (Figure 3) will alternate with the “CHARGE”...
Page 8 Percentage Indication of battery charging (Figure 3) Once the battery is full, the voltage will display permanently with the “FULL” sign. (Figure 4) The trickle charging will start shortly and around 5% of the charging current to keep the rechargeable batteries being full. The only default charging current is around 450mA during the charging process.
Page 9 For proper reset, unplug the DC jack and wait for 5 seconds  before plugging it into the charger. The estimated charging time of different battery size is tabulated in Table 1. Table 1. Charging Time with Two Types of Battery Size Size of Battery Charging current (mA)
Page 10 defect batteries are placed to the charging unit, the “DEFECT“ sign (Figure 6) will show on the LCD of charger. The “DEFECT” sign will flash for a while on the LCD when the  charger detects the battery condition. When the defective condition of the battery is confirmed, the “DEFECT”...
Page 11: Discharge Mode
make sure that the charged batteries are either NiCd or NiMH type and should not use the alkaline or carbon batteries. Carbon or Alkaline batteries may be the cause of the defect.  Those types of batteries are NOT suitable for this charger. Another defect cause may come from the rechargeable batteries which voltage is too low.
Page 12: Test Mode
sign. The trickle charging will start shortly and around 5% of the charging current to keep the rechargeable batteries being full. TEST MODE To select the test mode, please refer to the SETTING UP THE CHARGER above. In the Test mode, the rechargeable batteries will first be fully charged and then discharged to determine the capacities and then fully charge the batteries again.
Page 13 When in the discharging stage, the voltage (Figure 10) and discharging capacity (Figure 11) are displayed alternatively. The voltage (Figure 10) Test mode The discharging capacity (Figure 11) Test mode In the second time of charging, the voltage and the capacity are displayed alternately.
Page 14: Trickle Charging
The capacity (Figure 12) Test mode The voltage (Figure 13) Test mode TRICKLE CHARGING After the rechargeable battery is fully charged, the charger will give a small amount of current to the rechargeable batteries to maintain the fully charged level. This stage is automatically launched after rechargeable batteries are fully charged and kept at the charging unit.
Page 15: Specifications
these may cause the damage to the unit. When cleaning the displays and casings, use a soft damp cloth  only. Do not wet the exposed metal part of the charging unit. Do not use solvents or scouring agents as they may mark the LCD and casing.
Page 16: Liability Disclaimer
LIABILITY DISCLAIMER: The manufacturer and supplier will not accept any responsibility  on the improper or incorrect use that makes any consequence occur. Any performance of repairs or alternations by any person other  than the original supplier will invalidate the warranty. This product is designed to be used only by people who have ...
Page 17 from the fire. Do not use any accessory not supplied with the charger. The  user should never use any power cable and transformer other than those originally supplied with the charging unit. Disconnect the AC/DC adapter when the unit is not in use. ...
