FARM STAR DCR-4 Owner's/Operator's Manual

3 pt. landscape rake

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

OWNER'S /

OPERATOR'S

MANUAL

MODEL NO.'s

DCR-4

MCR-6

DCR-5

MCR-7

LRHD-6

LRHD-7

LRHD-8

CAUTION

For Safe Operation

Read Rules And

Instructions Carefully

SINO LEEINGLES, PIDA AYUDA

A AIGUIEN Q UE SI LO LEA

PARA QUE LE TRADUZCA LAS

MEDIDAS DE SEGURIDAD.

THE FOLLOWING SAFETY PRECAUTIONS SHOULD BE THOROUGHLY UNDERSTOOD

1. Select an area for assembly that is clean and free of an y

debris which might cause persons w

assembly to trip.

2. Do not lift hea vy par ts or assemb lies. Use cr ane, jac k,

tackle, fork trucks or other mechanical devices.

3. Preview the assemb ly instr uctions in y our oper ator's

manual before proceeding further.

4. If the assembly instructions call for parts or assemblies to

be blocked up, use only b locking material that is in good

condition and is capab le of handling the w eight of the

assembly to be b locked. Also insure that the b locking

material is on a clean, dr y surface.

5. Never put hands , or an y par t of body, under b locked up

assemblies if at all possible.

LRHD-7

(Rakes shown with optional gauge wheels)

3 PT. LANDSCAPE RAKE

Safety Instructions

Tractor Preparation

Operating Instructions

CAUTION

BEFORE ATTEMPTING TO BEGIN ASSEMBLING THIS MACHINE

orking on the

Assembly & Mounting

Maintenance

Repair Parts

6. After completing assemb ly, thoroughly inspect the

machine to be sure that all n uts, bolts, hydraulic fittings

or any other f astened assemblies have been thoroughly

tightened.

7. Before oper ating the machine , thoroughly read the

operation section of your operator's manual.

8. Before oper ating, read the maintenance section of y our

operator's man ual to be sure that an

lubrication, such as gearbo xes, are full, to a

possible damage.

9. Before operating equipment – If y

questions regar ding the pr oper assemb ly or

operation, contact your dealer or representative .

DCR-4

y par ts requir ing

void an y

ou ha ve an y

Table of Contents

Need help?

Do you have a question about the DCR-4 and is the answer not in the manual?

Questions and answers

Summary of Contents for FARM STAR DCR-4

Page 1: Safety Instructions
OWNER’S / OPERATOR’S DCR-4 MANUAL MODEL NO.’s DCR-4 MCR-6 DCR-5 MCR-7 LRHD-6 LRHD-7 LRHD-7 LRHD-8 (Rakes shown with optional gauge wheels) CAUTION For Safe Operation 3 PT. LANDSCAPE RAKE Read Rules And Instructions Carefully Safety Instructions Assembly & Mounting SINO LEEINGLES, PIDA AYUDA...
Page 2: Table Of Contents
SINO LEEINGLES, PIDA A YUDA A TABLE OF CONTENTS AIGUIEN QUE SI LO LEA P ARA QUE LE TRADUZCA LAS MEDID AS DE WARRANTY ........2 SEGURIDAD.
Page 3: Limited Warranty
DISCLAIMER OF IMPLIED WARRANTIES & CONSEQUENTIAL DAMAGES Farm Star’s obligation under this w arranty, to the e xtent allowed by law, is in lieu of all w arranties, implied or expressed, including implied warranties of merchantability and fitness for a particular purpose and any liabili- ty f or incidental and consequential damages with respect to the sale or use of the items w arranted.
Page 4: Important Safety Information
To the Owner/Operator/Dealer All implements with moving parts are potentially hazardous. There is no substitute f or a cautious, safe-minded opera- tor who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to be used with all its saf ety equipment properly attached to minimize the chance of accidents. BEFORE YOU START!! Read the safety messages on the implement and sho wn in your manual.
Page 5 SAFETY INSTRUCTIONS (continued) All equipment is potentially hazardous . There is no substitute f or a cautious , saf e-minded oper ator who recognizes potential hazards and follows reasonable safety practices. Most accidents occur because of neglect or carelessness. Keep all helpers and bystanders fifty feet (50’) from an operating power unit and attached equipment.
Page 6 SAFETY INSTRUCTIONS (continued) Never allow children to operate or be around equipment. Use stabilizer bars, adjustable sway chains, or sway blocks on your tractor lift arms to keep the implement from swinging side to side. Adjust as tightly as pr actical for best performance. Keep alert and watch the front as w ell as the rear when w orking with the implement.
Page 7: Safety Signs
SAFETY SIGNS Keep children away from danger all day, every day. Please w ork, dr ive, pla y, and liv e each da y with care and concern f or y our saf ety and that of y our f amily and f ellow citizens.
Page 8: Preparation Instructions
INSTRUCTIONS TRACTOR REQUIREMENTS PACKAGING —————————————————— AND PREPARATION —————————————————— The landscape rake is shipped as tw o bundles: The DCR, MCR, and LRHD Ser ies Landscape Rak es 1. Main Frame with pull pins, bolts and nuts. will fit most Category I) tractors equipped with a standard 2.
Page 9 INSTRUCTIONS (continued) ASSEMBLY CONNECTING LANDSCAPE (continued) —————————————————— RAKE TO TRACTOR FOR MODEL LRHD RAKES —————————————————— ALL MODELS Place jack stands or suitab le blocking under tinebar so center pivot bolt and 3 pt. mount can be installed. The landscape r ake is compatib le with Categor y 1, 3 point tr actors equipped with side s wing-type lo wer lift Place 3 pt.
Page 10: Operating Instructions
OPERATION LEVELING OPERATION —————————————————— The rake should be str aight across, i.e., 90° to the line The operator is responsible for the safe operation of this of travel of the tractor, in other words 0° horizontal angle. equipment. The oper ator m ust be proper ly tr ained. There should be 0°...
Page 11: Service Instructions
OWNER SERVICE TRANSPORTING WARNING! —————————————————— Pay par ticular close attention to the Saf ety Messages NEVER GO UNDERNEA TH EQ UIPMENT. Never regarding tr ansport. Avoid unnecessar y injur ies and place any part of the bod y underneath equipment or equipment damage by exercising cautious, conscientious between mo veable par ts e ven when the engine has travel procedures.
Page 12: Trouble-Shooting
TROUBLE-SHOOTING GUIDE PROBLEM POSSIBLE CAUSE POSSIBLE REMEDY Rake will not pene- 1. Tinebar set too straight. Increase 3 pt. hitch toplink length. trate soil. 2. Soil too hard. Loosen soil with scarifiers or disk. Wait for rain. Rake teeth digging 1.
Page 13: Parts Drawings & Lists
DCR LANDSCAPE RAKE PARTS LIST SGW-10 GAUGE WHEEL PARTS LIST (OPTIONAL)
Page 14 MCR LANDSCAPE RAKE PARTS LIST...
Page 15 LRHD LANDSCAPE RAKE PARTS LIST DGW-20 GAUGE WHEEL PARTS LIST (OPTIONAL)
Page 16: Safety Precautions
MANUAL LRHD Series – Cat. I – up to 50 hp WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION: MODEL NO.’s 1. PART NUMBER 2. PART DESCRIPTION DCR-4 MCR-6 3. MODEL NUMBER 4. NAME OF ITEM DCR-5 MCR-7 LRHD-6...

This manual is also suitable for:

Mcr-6 Dcr-5 Mcr-7 Lrhd-6 Lrhd-7 Lrhd-8
