  • Page 1 NETWORK CAMERA GUIDE Install Browse Network Camera setup and installation guide. Browser setup with settings explained. Product Made in China under ISO9001 & ISO1400 standards 01.BSM.12.0092401 Manual Printed in China v1.0 eLineTechnology...
  • Page 2: Instruction Manual

    Eyeball Vandal Dome IP Camera CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER. NO USER SERVICABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of un-insulated "dangerous voltage"...
  • Page 3: Important Safeguards

    Service Important Safeguards In addition to the careful attention devoted to quality standards in the manufacturing process of 13. Servicing - Do not attempt to service this video 19. Cleaning - Unplug the video product from the wall equipment yourself as opening or removing covers outlet before cleaning.
  • Page 4: General Precautions

    Features General Precautions 1. All warnings and instructions in this manual should be followed. 2. Remove the plug from the outlet before cleaning. Do not use liquid aerosol detergents. Use a water dampened cloth for cleaning. 3. Keep enough space around the unit for ventilation. Slots and openings in the storage cabinet should not be blocked.
  • Page 5: Table Of Contents

    6.7.7 BNC Video Output ............32 TABLE OF CONTENTS 6.7.8 Language .
  • Page 6: Getting Started

    1. GETTING STARTED 1.2 Camera Interior Overview The system comes with the following components: • 1 x Camera Access panel. With Micro sd Card slot*. Status LED, camera reset & service • 1 x Mounting Screw Kit • 1 x Allen Key video Mounting Screw Kit: •...
  • Page 7: Onvif Compatibility And Included Software Overview

    1.3 ONVIF Compatibility and Included Software Overview This camera is ONVIF v2.1 compliant. It is designed for interoperability with 2. CONNECTION popular VMS’s and NVR’s*, with backwards compatibility to ONVIF v.1.02. For more information on ONVIF, visit www.onvif.org The camera has the following termination cables: NOTE: Provided software is PC compatible only;...
  • Page 8: Camera Installation

    Connection 3. Mount the camera to the surface using the included 3. CAMERA INSTALLATION mounting screws (4x). Make sure to follow the correct polarity if connecting the camera to DC power. Polarity is marked on the power connector. 1. Use the included allen key to remove make lose the top 4.
  • Page 9: Finding The Camera's Ip Address

    Finding the Address 6. If you need to adjust the viewing angle, loosen the 4. FINDING THE CAMERA’S IP ADDRESS screws on the sides of the ball camera and adjust the ball camera.. Tighten the Use the steps below to find the camera’s IP address and connect to the cover when finished.
  • Page 10: Finding The Camera's Ip Address Using Bonjour® In Mac Os

    Finding the Address Finding the Address 4. Click on a camera IP address in Device List to login. 1. Click Start>Computer>Network. The camera’s IP address appears under Network Infrastructure. 5. Under User Name, enter the user name for the camera (default: admin). Under Password, enter the password for the camera (default: admin).
  • Page 11: Finding The Camera's Ip Using The Bnc Test Cable

    Configuring Connection Finding the Address 2. Click Bonjour. The camera’s IP address appears in the Bonjour Devices list. 5. CONFIGURING REMOTE CONNECTION 3. Double-click the camera to open it in Safari®. Follow the steps below to configure your camera for connections over the Bookmarks Internet using a web browser, NVMS, or other VMS software.
  • Page 12 Configuring Connection Configuring Connection Step 3 of 6: Locate your camera’s MAC address: Step 5 of 6: Enable DDNS on the camera: 1. Open a web browser and enter the camera’s IP address in the address 1. Ent er the camera’s IP address in your web browser. Log in and then click bar in the following format: Network Service>DDNS.
  • Page 13: Connecting To A Ddns Address Using Nvms

    Configuring Connection Configuring Connection 5.1 Connecting to a DDNS address using NVMS 8. Close Device Maintenance and Device Manager, and return to the Live Video screen. The newly added camera will appear in Device List. NOTE: Complete all the steps above before performing the following method.
  • Page 14: Web Configuration

    Configuration Configuration 4. The main screen for the camera web interface opens. From here you can view and configure the camera. 6. WEB CONFIGURATION NOTE: If you do not see video from the camera, make sure your computer has the latest version of Adobe Flash Player installed (visit http:// The camera includes a built-in web interface that can be accessed using a www.adobe.com/...
  • Page 15 Configuration Configuration 4. If your computer has Flash Player installed, the main screen for the 3. Under Download unsigned ActiveX controls, click Prompt camera web interface opens. From here you can view and configure the (recommended) or Enable. camera. NOTE: The ActiveX plug-in may provide smoother video performance than Select Enable or Prompt under Flash Player.
  • Page 16: Web Interface/Live Video Overview

    Configuration Configuration 6.4 Web Interface/Live Video Overview The Live Video Menu contains the following options: Click and drag to zoom in. Right-click and • Full Screen: Open the video in full screen. Press ESC to exit full screen. Camera select ZoomOut to zoom out. configuration •...
  • Page 17: Device Info

    Configuration Configuration 6.5 Device Info 6.6 Stream Configuration The Stream Configuration page allows you to configure the camera’s video The Device Info page shows information about your IP camera, such as the streams. The camera supports three different video streams. This allows Device Name (which appears in the Device List in NVMS), firmware you to have a high quality recording stream (stream1), a lower quality stream version, MAC address, and camera inputs and outputs.
  • Page 18: Device Configuration

    Configuration Configuration 6.7.1 Local Network • Frame Rate: Select the frame rate for the stream up to maximum of 30FPS for stream1 or stream2 or 12FPS for stream3. NOTE: Frame rate may be automatically adjusted to account for bandwidth limitations. •...
  • Page 19: Device Port

    Configuration Configuration 6.7.3 Camera 4. Click OK to save changes. The camera will restart with the new IP address. 6.7.2 Device Port The Camera page (Device Configuration>Camera) allows you to configure the Channel Name, which appears on the camera OSD and the video system frequency.
  • Page 20: Osd

    Configuration Configuration 3. Un-check Enable NTP and click Apply at the bottom of the screen. You can set the camera’s date and time the following ways: 4. If your region observes daylight savings time, check Adjust clock for • Using an NTP server (recommended) daylight saving changes.
  • Page 21: Microphone

    Configuration Configuration Configure microphone settings for listen-in audio. Self-powered • Custom: Create a custom OSD message. Enter the custom OSD text under Custom OSD. microphone required (not included). Device Name To configure microphone settings: Channel ID 1. Click Device Configuration>Microphone. Channel Name 2.
  • Page 22: Alarm Configuration

    Configuration Configuration 3. Under Max Disk Space, enter the disk full percentage that will trigger an To change the language for the OSD and email alarms: alarm (e.g. a Disk Full Alarm will be triggered when the recording disk is 1.
  • Page 23: Local Record

    Configuration Configuration 6.9 Local Record 3. Click Schedule to configure a motion detection schedule. The Schedule Time Setting menu opens. Local Record contains the following sub-menus: • Record Policy NOTE: If the Schedule Time Setting does not open, disable any popup blockers.
  • Page 24 Configuration Configuration 4. Click Modify. The Record Disk Path menu opens. 2. Under Disk Name, select ftp. Select SD1 Select ftp Click Modify Click Modify 5. Check Enable. 3. Click Modify. The Record Disk Path opens. 4. Check Enable. Check Enable 5.
  • Page 25 Configuration Configuration 4. Configure the following: 6. Click OK. 7. Set up recording using the Record Policy sub-menu (see “6.9.1 Record Directory” on page 36). To access your recordings, use NVMS or manually access your FTP server. NOTE: On the Record Directory page, Status will be OK when FTP is selected if FTP is accessible and all settings have been entered correctly.
  • Page 26: Record Policy

    Configuration Configuration The Record Policy menu allows you to set the microSD/SD memory card, 6. Set up recording using the Record Policy sub-menu (see “6.9.1 Record Directory” on page 36). To access your recordings, use NVMS or NAS, and FTP recording parameters. Once configured, the device can record video directly to a microSD/SD card, NAS, and FTP.
  • Page 27: Privacy Masking

    Configuration Configuration 4. Click OK. An error message appears if the masks configured exceed 8% number of days and enter the Number of Days desired. Note that you must have sufficient storage space to save the number of days entered. of the total image area.
  • Page 28: Service Center

    Configuration Configuration To enable email alerts: • Password: Enter the Password you have set on the account. 1. Click Service Center>SMTP. 4. Click OK to save settings. 2. Check Enable SMTP. 6.12 Service Center 3. Configure the following: • SMTP Server Address: Enter the address for your SMTP server. Service Center contains the following sub-menus: •...
  • Page 29: Group

    Configuration Configuration 6.13.1 Group 1. Under Group, select the group you would like to modify. 2. Click Modify to change the group name if needed, enter a new group name and click OK. 3. Change permissions as needed and click OK. To delete a user group: 1.
  • Page 30: Unlocking User Accounts

    Configuration Configuration To add a user account: 2. Click Privilege Manager>User. 1. Click Add. The Add User window appears. NOTE: If the Add User menu does not appear, disable any popup blockers. Select the user Click Unlock 3. Under User, select the locked user account. 4.
  • Page 31: Default Settings

    Configuration Configuration 6.16 Default Settings • Click Save to save setting changes. • Click Reset to revert to the last saved changes. • Click Factory Setting to revert all camera sensor settings to factory defaults. • Click Cancel to exit. Click Default Settings.
  • Page 32: Gain Mode

    Configuration Configuration • Night Color: Select Black_White to have the camera switch to black and • MaxShutter: Sets the upper limit of the shutter speed when AutoShutter white during night mode or select Multicolor to have the camera remain is selected. in color during night mode.
  • Page 33: Ae Meter Mode

    Configuration Configuration 6.17.7 AE Meter Mode • WB Mode: Select Auto for automatic white balance or Manual to manually set the white balance. • Manual Mode: Select a mode for the lighting conditions or select Customized and manually adjust the RedGain and BlueGain. 6.17.9 WDR (solution may not feature this setting) Set the Auto-Exposure Meter Mode from one of the following: •...
  • Page 34: Mirror

    Configuration 6.17.10 Mirror 7. RESETTING TO FACTORY DEFAULTS Follow the steps below to revert all settings to factory defaults. The camera must be connected to power to perform a factory reset. Remove the camera access cover screws (2x) and camera cover. Cover is hinged Enable/disable image mirroring.
  • Page 35: Dimensions

    Dimensions 9. TROUBLESHOOTING 8. DIMENSIONS Can’t find the camera IP address using NVMS or other software: • Make sure Ethernet and/or DC power cables are correctly connected to Units: mm the camera. • Make sure the PoE switch or DC power source meets the camera’s power requirements (class 3 PoE / 450mA / 5.4W / 12V).
  • Page 36 Can’t connect to camera on a web browser using a DDNS address: • Port forwarding not set up. Make sure the HTTP port (default: 80) and Control port (default: 30001) are forwarded on your router to the camera’s local IP address. •...
