Summary of Contents for Heritage HM-560B
-
Page 1: Smoke Detector
Heritage MedCall Sentry E-Call Model HM-560B Photoelectric Smoke Detector 430-560B 0305 ©Heritage MedCall, Inc. Issue 1, March 2005... -
Page 2: Principle Of Operation
The HM-560B Smoke Detector includes automatic sensitivity testing. Once daily and upon power-up the detector performs a full diagnostic test that includes a dynamic test of the sensing chamber and internal electronics. - Page 3 Heritage Medcall Sentry Emergency Call System Model 560B Smoke Detector Installation and Service Instructions upper level, or in both locations. The basement height, high air movement, and other conditions or smoke alarm should be installed in close proximity to response requirements.
-
Page 4: Dust Protection
INSTALLATION 4 conductors as spare for future options. The detectors mount to standard single-gang electri- Heritage MedCall recommends the following wire or cal boxes, four-inch octagonal or four-inch square equivalent for installation of the Sentry smoke electrical boxes, or on WIREMOLD No. 5739 fixture detectors: boxes. -
Page 5: Installation Test
HEAT TEST 3. Open the cover and mount the detector, using the mounting holes provided. See Figure 4. The HM-560B Smoke Detectors sample for heat every 3 seconds. Test heat sensors by using a hot air gun. NOTE Aim the gun at the heat sensor from 6-10 inches (15- Positive air pressure from wire openings, conduit, 25cm) away. -
Page 6: Maintenance
Heritage Medcall Sentry Emergency Call System Model 560B Smoke Detector Installation and Service Instructions 3. Close the detector cover and verify sensitivity. See Sensitivity Test. FIGURE 5 SENSITIVITY TESTING MAINTENANCE The smoke detectors are designed for easy field service and maintenance. If a detector drifts beyond... -
Page 7: Troubleshooting
MAINTENANCE section. If the alarm does not The Model HM-560B Photoelectric smoke detector clear, the detector will need replacement. normally draws 70uA DC. It operates at 9 to 16 volts and is powered by the host panel. - Page 8 Heritage Medcall Sentry Emergency Call System Model 560B Smoke Detector Installation and Service Instructions FIGURE 7 SINGLE SMOKE DETECTOR WIRING FIGURE 8 MULTIPLE SMOKE DETECTOR WIRING Page 7 460-560B 0305 ©Heritage MedCall, Inc. Issue 1, March 2005...
