ITA-200 Technical Reference Manual
Rev 1.0
___________________________________________________________________
Intelligent Telephone Adapter Model ITA-200
Technical Reference Manual
Revision 1.0, October 26, 2006
_____________________________________________________________________________________
Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved
1 of 58

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ITA-200 and is the answer not in the manual?

Questions and answers

Summary of Contents for Quintum ITA-200

  • Page 1 ITA-200 Technical Reference Manual Rev 1.0 ___________________________________________________________________ Intelligent Telephone Adapter Model ITA-200 Technical Reference Manual Revision 1.0, October 26, 2006 _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 1 of 58...

  • Page 2: Table Of Contents

    2. Auto config Download timer. 3. Download the configuration file through a voice prompt . Appendix A. Dialing Plan Appendix B. Update File Appendix C. Config File Disclaimer _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 2 of 58...

  • Page 3: Chapter 1: Overview

    The WAN Port of the ITA-200 device connects to the Ethernet port of a Broadband Modem (ADSL or Cable); the LAN Port of the ITA-200 adapter connects to the Ethernet port of the PC, providing the PC with connectivity to the Internet. At the same time it provides the user with two (2) additional telephone lines.

  • Page 4: General Specifications

    Rev 1.0 ___________________________________________________________________ The ITA-200 is the ideal device to implement next generation telephone services using Voice over Internet Protocol (VoIP) technology. It offers clear and compelling benefits for individual or enterprise’s communications needs. The ITA-200 uses the most reliable and standard protocols in the market today to ensure compatibility and reliability with existing VoIP networks.
  • Page 5 Call Progress Tone Generation, Adaptive Jitter Buffer, Full Duplex Audio, Echo Cancellation (G.165/G.168), Voice Activity Detection (VAD) with Silence Suppression, Attenuation/Gain Adjustments, Message Waiting Indicator (MWI) Tones and Visual, _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 5 of 58...
  • Page 6 Ring Waveform Trapezoidal and Sinusoidal Maximum Ring Load 3 REN On-Hook Voltage (T/R) 50 V Off-Hook Current 25 mA Terminating Impedance Configurable North America 600 ohms, European CTR21 _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 6 of 58...
  • Page 7 ITA-200 Technical Reference Manual Rev 1.0 ___________________________________________________________________ Regulatory Compliance FCC Part 15 Class B VCCI CE Mark Front View Back View _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 7 of 58...
  • Page 8 ITA-200 Technical Reference Manual Rev 1.0 ___________________________________________________________________ Standing View _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 8 of 58...

  • Page 9: Chapter 2: Getting To Know The Ita-200

    Rev 1.0 ___________________________________________________________________ Chapter 2 Getting to Know the ITA-200 The ITA-200’s Front Panel LED’s on the ITA-200 front panel are shown in Figure 2. Figure 2. ITA-200 Front Panel LED description. Power Green ITA-200 is powered on. Phone 1 &...

  • Page 10: The Ita-200'S Back Panel

    ITA-200 Technical Reference Manual Rev 1.0 ___________________________________________________________________ The ITA-200’s Back Panel The access to the interfaces is located in the back panel of the ITA-200. The ports are described below in Figure 3. Figure 3. ITA-200 Back Panel Interfaces WAN RJ-45...

  • Page 11: Chapter 3: Connecting The Ita-200

    Connect the RJ-45 Ethernet cable provided with the ITA-200 between the Ethernet port of your broadband modem (Cable/ DSL Modem) and the WAN port of the ITA-200. b) Connect your PC’s Ethernet port to the LAN port of the ITA-200 using the other RJ-45 Ethernet cable.

  • Page 12: Power-Up Sequence

    Power up the Cable/DSL Modem and verify that the modem has successfully connected to the ISP’s (Internet Service Provider) network by checking its LED’s. Figure 5 indicates the power-up sequence for the ITA-200. Figure 5. Sequence to power-up ITA-200 _____________________________________________________________________________________ Copyright ©...

  • Page 13: Chapter 4: Configuring The Ita-200

    Chapter 4 Configuring the ITA-200 Your ITA-200 should be configured as shown in Figure 5, and all the LED’s should be ON except Phone 1 and Phone 2. To access the ITA-200’s configuration web page, type 192.168.10.1 in the address field of your Windows Internet Explorer.

  • Page 14: Unit Information Tab

    Serial Number This is the serial number assigned by the manufacturer. WAN IP Address This IP address uniquely identifies ITA-200 as a node in the IP network (for example, the Internet). WAN Subnet Mask The subnet mask is used to determine what subnet an IP address belongs to.

  • Page 15: Wan/Lan Configuration Tab

    Figure 8. Complete web pages for configuration WAN/LAN CONFIGURATION TAB WAN INTERFACE CONFIGURATION IP Address If you are connecting through DHCP to your ISP, keep this Assignment default setting. (DHCP) _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 15 of 58...
  • Page 16 To enable the ITA-200’s DHCP server. IP address will be Server assigned dynamically to the PC connected to its LAN port. Local IP Address It refers to the ITA-200’s local IP address. The default is 192.168.10.1. Subnet Mask The subnet mask is used to determine what subnet an IP address belongs to.
  • Page 17 The Product Key of the 3-Way Video Conferencing Control Panel software. Control Panel Port The port used by the ITA-200 to communicate with the Control Panel software. The default value is 60434. Use Control Panel Enable this option if you want to use the 3-Way Video...
  • Page 18 ITA-200 Technical Reference Manual Rev 1.0 ___________________________________________________________________ Figue 9. WAN/LAN Configuration Tab. _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 18 of 58...

  • Page 19: Sip Configuration Tab

    ITA-200 Technical Reference Manual Rev 1.0 ___________________________________________________________________ SIP CONFIGURATION TAB Figure 10. SIP Configuration Tab. _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 19 of 58...
  • Page 20 Rev 1.0 ___________________________________________________________________ SIP SERVER INFORMATION (PRIMARY & SECONDARY) These settings are used by ITA-200 to communicate with the SIP Proxy Server. SIP Proxy Server 1 or This field contains the URL string or IP address of the SIP SIP Proxy Server 2 Proxy Server.
  • Page 21 Specifies the volume of the speaker. Default is 0 dB. (Speaker) Range -12 to +12 dB. Handset Volume (Mic) Specifies the volume of the microphone. Default is 0 dB. Range -12 to +12 dB. _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 21 of 58...
  • Page 22 ITA-200 Technical Reference Manual Rev 1.0 ___________________________________________________________________ Figure 11. Services Tab. _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 22 of 58...

  • Page 23: Services Tab

    Call Conferencing is selected by default in the manufacturer configuration. Enable: *64 Disable: *65 _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 23 of 58...
  • Page 24 This service is used to forward your incoming calls to a (Option: On Busy) specific phone number when your line is busy. Enable: *74 plus telephone number Disable: *70 Option All: *72 _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 24 of 58...
  • Page 25 *89 to higher the speaker volume frequency. Prepend Local Code A prefix country code or local area code to easily route calls. _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 25 of 58...
  • Page 26 (SIP & RTP) SIP messages and RTP packets that are sent to the server. This encryption will depend on the service provider. Figure 12. Misc. Servers Tab. _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 26 of 58...

  • Page 27: Misc. Servers Tab

    Control Panel WAN Port The WAN port used to connect the control panel. NAT RTP Port Select this option to resolve the WAN RTP port. This is used when RTP proxy is not used for ITA-200-to-ITA-200 calls. ITA-200 connected behind a symmetrical NAT can communicate to an ITA-200 connected behind an asymmetrical NAT.
  • Page 28 Inter Digit Time Out When dialing a number, if you don’t press “#” at the end of the dialing, the ITA-200 will wait for the time specified in this field before proceed to make the call. The default is 4 seconds.

  • Page 29: Maintenance Tab

    This is used to download special firmware. (System Access Code The System Access Code for this feature is bootapp123. Required) Restore Factory Default Selecting this option restores the ITA-200 to the manufacturer settings. _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 29 of 58...
  • Page 30 Allow the user to access the SIP Configuration page. Services Allow the user to access the Services page. Misc. Servers Allow the user to access the Misc. Servers page. _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 30 of 58...

  • Page 31: Chapter 5: Firmware Upgrade Ita200

    4 Press UPDATE to save the changes. 5 Select Maintenance tab. 6 Select Download Firmware File (figure 15) 7 Press Submit Request. Figure 14. Misc.Servers Tab ( Firmware/Config Server) _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 31 of 58...

  • Page 32: Auto Firmware Update

    After set up have been done the ITA200 will automatically check on the update file, on every reboot, if new version of the firmware have been install. _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 32 of 58...

  • Page 33: Special Download

    6 In the System Access Code field enter the code bootapp123 and select Enable ( Figure 17) 7 Press Submit Request. 8 On the next screen click on Special Download. (Figure 18). _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 33 of 58...
  • Page 34 11 When finished, and to check the firmware upgrade, select the Unit Information page, the Firmware version is displayed and will display the new version number. Figure 19. Download Firmware. _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 34 of 58...

  • Page 35: Chapter 6: Voice Prompts

    Read Subnet Mask Read Gateway Read DHCP server Read Remote Access Read Firmware/Backup/Boot Version Read Firmware Version Read Backup Version Read Boot Version To Reset the Box. _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 35 of 58...

  • Page 36: Data Input For Voice Prompts Menu In Ita200

    - Press “10” to backspace (delete previous letter). - End the entry by pressing “#”. 5. At the end of the entry, you will hear the following: _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 36 of 58...
  • Page 37 IP = 202.123.45.67 Input: 2 0 2 * 1 2 3 * 4 5 * 6 7 # If the input value is not correct the data is rejected. _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 37 of 58...

  • Page 38: Chapter 7: Download Config File

    (Figure 20). 4 Press UPDATE to save the changes. 5 Select Maintenance tab. 6 Select Download Configuration File (Figure 21) 7 Press Submit Request. Figure 20. Firmware/Config Server _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 38 of 58...

  • Page 39: Auto Config Download Timer

    5 Press UPDATE to save the changes. 6 And Reset the box. After set up have been done the ITA200 will automatically download the config. File, on every reboot, and every N minutes. _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 39 of 58...

  • Page 40: Download The Configuration File Through A Voice Prompt

    5 Pick up the phone. 6 Dial ### to access the Voice Prompt Menu. - Voice: Please enter the commands 7 Press 52 to make the unit download config file. _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 40 of 58...

  • Page 41: Appendix A. Dialing Plan

    1900 followed by any 7 digit numerical sequence is not allowed to be dialed and is hence, blocked. • <:1727>[2-4]xxxxxxx: This dial plan option is used to replace some digits. _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 41 of 58...
  • Page 42 1 and more characters that matches the remainder of the dial string ([2- 4]xxxxxxx) then the character ‘1’ will be replaced by 1727 and leaving the remainder as it is. _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 42 of 58...
  • Page 43 Australia - police or otherwise), country code for Australia '61' area code for Sydney (2) and the number for the NSW police service '131444'. _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 43 of 58...

  • Page 44: Appendix B. Update File

    The content of the file should have the following format #TYPE#VERSION#FILENAME# If it is not on the above format, the auto update feature will not work. For example: #TYPE#VERSION#FILENAME# #firmware16MB#3.1.3.14#quta200-sip-ver3.1.3.14.bin.gz# #default16MB#3.1.2.14#quta200-default-ver3.1.2.14.bin.gz# #itawavefile_english# #itawavefile_mandarin# #itawavefile_spanish# #itawavefile_malay# _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 44 of 58...

  • Page 45: Appendix C. Config File

    2. Create a config file as shown on previous section and save in the folder of the binconv.exe (C:\ConfigFile) the file name must be “prfMacaddress.txt” in . txt format. Example: If the ITA-200 has the Mac Address number 000F26001234 save the template with the following name prf000f26001234.txt...
  • Page 46 (US Eastern Time, New York) secondaryNTPTimeZone:GMT-5:00 (US Eastern Time, New York) configVersion:0 autoNatDetection:0 encryptCfg:0 blockT38ReinviteOrig:0 dtmfPayload:0 resolveDnsOnce:1 unitOnOff:0 allowAutoUpdate:0 dialString:[1]xxxxxxxxxx|[0]xxxxxxxxxxxxxxxxxxxxxx|[0-9*#]x+#|###|***|xx+* enableDialString:0 _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 46 of 58...
  • Page 47 _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 47 of 58...
  • Page 48 3,*87,*89 voicePromptLanguage:0 pstnEmergencyNumber1: pstnEmergencyNumber2: pstnEmergencyNumber3: pstnEmergencyNumber4: pstnEmergencyNumber5: enablePstnEmergencyNumber1:0 enablePstnEmergencyNumber2:0 _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 48 of 58...
  • Page 49 If the Config File encrypted. Enable 1, Disable 0 For Changes the SIP Server Information: These settings are used by ITA-200 to communicate with the SIP Proxy Server. proxyIp: This field contains the URL string or IP address of the SIP Proxy Server.
  • Page 50 ITA-200 Technical Reference Manual Rev 1.0 ___________________________________________________________________ bckRegPort: The local port used by ITA-200 to communicate with the secondary SIP Proxy Server. The default value is 5060. For configurate the SIP Client Information: This is where you specify the telephone number for the line 1 to be registered to the SIP Proxy Server.
  • Page 51 4. Use binconv to crate configuration file, for this execute the command as follows: binconv prfmacaddress.txt watamacaddress Example: if the Mac Address is 000f26001234 then command should be binconv prf000f26001234.txt wata000f26001234 Figure 24. Execute binconv. _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 51 of 58...
  • Page 52 – 0 */ /* Number of frame size to be used on line 2. voiceFrameSize2: Default 4 frames */ voiceCodec2 [1]: G.723.1A /* First codec on line 2 */ _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 52 of 58...
  • Page 53 /* Stun Server Ip/Domain Address to resolve Nat stunServer: 0.0.0.0 stunenable: /* Stun Server option. Enable 1, Disable 0 */ configServer: 66.111.47.107 /* Tftp/Http Server IP/Domain Address */ _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 53 of 58...
  • Page 54 (US Eastern Time, New York) /* Time Zone2 */ /* To Connect automatically to either autonetworkconnect: dhcp/pppoe server. enable 1, disable 0 */ enableCallWaiting1: /* Call Waiting one line 1. Enable 1, Disable 0 */ _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 54 of 58...
  • Page 55 Xxxxxxxxxxxxxxxxxxxxxx |[0-9]xx+#|#xx|[*]xx+# |###|***|xx+* enableDialString: /* Enable Dial String. Enable 1, Disable 0 */ /* Block Anonymous calls on line 1. Enable 1, blockAnonymousCall1: 0 Disable 0 */ _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 55 of 58...
  • Page 56 /* Do Rtp Proxy Enable – 1 , Disable – 0 */ t38Port1: 15000 /* T38 port for channel 1 */ t38Port2: 15004 /* T38 port for channel 2 */ dtmfPayload: /* DTMF payload for ex: 103 */ _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 56 of 58...
  • Page 57 /* Emergency number */ fxo911Enable: /* Emergency number function: Enable – 1 , Disable – 0 */ fxoRegene /* Regenerate DTMF: Enable – 1 , Disable – 0 */ _____________________________________________________________________________________ Copyright © 2004-2006 Quintum Technologies, Inc. All Rights Reserved 57 of 58...

  • Page 58: Disclaimer

    The information furnished by Quintum Technologies, Inc. Is believed to be accurate and reliable. However, Quintum Technologies, Inc. Does not assume any liability arising out of the particular network configuration example provided in this technical manual.
