Summary of Contents for Intelix AMIX-4
- Page 1 AMIX Series Automatic Mixers AMIX-4 Installer’s Manual AMIX-8...
- Page 2 All repair and service of Intelix products should only be provided by qualified service personnel. Please contact Intelix for a list of authorized service agents. Other attempts at service or repair will void the warranty. Warranty service is only offered after a return authorization number has been generated by an authorized Intelix representative.
-
Page 3: Table Of Contents
3.8 AMIX Software Version....................... 4.0 Installation..................... 4.0 Installation of the AMIX Mixer.................... 4.1 Unpack, Connect, and Power-up..................4.2 Connect Inputs........................4.3 Channel 4 or 8........................4.4 Connect Output........................4.5 Power Up..........................4.5.1 Connect the mixer power supply................4.5.2 Power up the mixer....................intelix... - Page 4 8.4 Master Output Insert Patching....................26 9.0 Passive Mixer Linking..................27 9.0 Passive Mixer Linking......................27 9.1 Making the Cables......................... 27 9.2 Connecting the Cables......................27 10.0 AMIX-LINK Module..................28 10.0 AMIX-LINK Module......................28 10.1 Quick Start for AMIX-LINK....................29 intelix...
-
Page 5: Intelix
10.5.1 Tapping and patching with the AMIX-LINK............37 10.5.2 Using the link in port as a balanced link input............10.5.2.1 If your source is balanced..............10.5.2.2 If your source is unbalanced..............39 11.0 Troubleshooting Tips..................40 12.0 Technical Specifications and Line Drawings..........41 intelix... - Page 6 AMIX Series Automatic Mic/Line Mixer User Manual intelix...
-
Page 7: Introduction
AMIX Series Automatic Mic/Line Mixer User Manual 1.0 Introduction This manual describes the components and operation of the Intelix AMIX Automatic Mic/line Mixer and the Intelix AMIX-LINK link module. A sophisticated auto-mixer, AMIX provides several modes of automatic mixing: last mic on, first-come, first-serve, and priority override. -
Page 8: Quick Start For The Amix Mixer
All AMIX mixers may be linked together serially (“daisy chained”) in one of two ways. The simplest and most flexible method is by using the Intelix AMIX-LINK module. If the application does not require the use of the AMIX-LINK (e.g., simple linking of two mixers), the mixers may be daisy chained using interconnect cables. -
Page 9: Panel Descriptions
-18 (green) to +12 (red) dB. Master Output Volume Knob: controls output signal level. Power Indicator LED (red): displays powered state. Lit when power is on. Power Switch Button: push to power unit (“in” position). Push to power down unit (“out” position). intelix... -
Page 10: Mixer Front Panel Accesswindow
AMIX Enable/Disable LED (Red): indicates AMIX module’s functional state. Lit when AMIX is enabled. Enable/Disable Button: push (“in” position) to enable AMIX functions. Push (“out” position) to disable. intelix... -
Page 11: Mixer Rear Panel
Channel Input Gain/Trim Control Potentiometer: adjusts gain of input stage over a range of 40 dBu. XLR input Jack: balanced male XLR input connection, one per channel. Input Mic/Line Switch: selects mic level (-50 dBu) or line level (0 dBu) for correspond- ing channel. intelix... -
Page 12: Amix Functions
This pot (RP2) controls the level to which the signal of an open mic is reduced when it is not active (not gated on). Reducing the signal rather than turning the mic off completely makes the gating off and on less obvious, resulting in a smoother sound. The amount of reduction intelix... -
Page 13: User Selectable Modes Of Operation
LEDs should be lit on the temporary bargraph. 3.6 Priority Override Channel 8 (on AMIX-8) or channel 4 (on AMIX-4) becomes active while all other channels are muted. This mode is activated by an external switch connected to the DC control connec- tor on the rear of the mixer. -
Page 14: Amix Channel Exclusion
If the LED is off, that channel will be excluded from automix. This process is also available through RS232 commands. 3.8 AMIX Software Version AMIX Software version is indicated by patterns in the LEDs on the front panel of the unit during power up or during reset. intelix... -
Page 15: Installation
Turn external amplifier volume controls to zero. 4.2 Connect Inputs For each input channel (up to 4 for AMIX-4; up to 8 for AMIX-8), insert the XLR input connector into the desired XLR Input Jack on the rear panel. Press the XLR Input Pad Microphone/Line Switch to appropriate position: “in” for line input or “out”... -
Page 16: Connect Output
4.5.2 Power up the mixer 1) Press the Power Switch to the “in” position (the power indicator LED will light if mixer is powered). 2) Set the Master Output Volume Knob to “7”. 3) Power up the external amplifier. intelix... -
Page 17: Gain Structure
In order to maintain the highest level of S/N in the mixer, the audio signals are never brought through the front panel controls of the Intelix mixer. Instead, each front panel pot controls a Voltage Controlled Attenuator (VCA), which controls the associated amplification stage. The channel VCAs do not control an amplifier, but are attenuation only devices which determine the amount of each channel’s contribution to the summing bus. -
Page 18: Setting The Amix Mixer Channels
5) Adjust individual channel volume knobs to the desired levels, as indicated on the bar graph (the bar graph monitors the output, but if one channel is adjusted at a time, the graph will reflect only that channel). intelix... -
Page 19: Mixer Fine Tuning
If during ordinary use one or more inputs occasionally exceed the maximum input levels set up during the set up procedure (sec. 5.0) (i.e., the red (+12 dB) LED on the bar graph meter occasionally lights), press the Output Limiter Switch to the on position. intelix... -
Page 20: Select Bar Graph Readout
Install the mixer in the rack or other cabinet where it will be when in use. The mixer should be located away from heat sources, including other electronic components which generate a large amount of heat, such as amplifiers. Verify the unit is well-secured. intelix... -
Page 21: Setting Amix Functions
4) Turn on the amplifier and set the mixer’s master volume to 6 or 7. Adjust the front panel volume control knob for each channel to the desired level (rather than using the clip LED as a guide because of its dual function as a signal detect LED). intelix... -
Page 22: Channel Isolation
(clip) channel LEDs. The LEDs act as a temporary bargraph for the two pots: when the pots are full-on, the LEDs are all lit (AMIX-4 has four LEDs and AMIX-8 has eight LEDs). When the pots are full-off, none of the LEDs are lit. This bargraph function begins when the pots are rotated and lasts for a few seconds after the adjustment stops. -
Page 23: External Control
8.1 The Connectors All external controls and signal sources are attached via the DB25 Control Pin Connector. Note that AMIX-4 has external control over all channels, while the AMIX-8 has external control only over even numbered channels. The female DB25 pinout for AMIX-4 The female DB25 pinout for AMIX-8 mixers. -
Page 24: Dc Control
8.2.3.1Wiring an external mute switch The following instructions show how to connect a single channel for remote muting. Repeat this process for each channel to be remotely muted. intelix... -
Page 25: Wiring An External Combination Mute Switch And Volume Control
AMIX functions. The components include potenti- ometers RP13 and RP14, as well as the ground lift jumper J4 and the Premaster Insert Patch Jumper J1. Some components in this picture may be hidden from sight by the AMIX board. intelix... -
Page 26: Master Output Insert Patching
DB25. The external device’s output is sent back to the mixer on pin 13 of the mixer’s DB25. Note that jumper J1 is removed for insert applications. Note: If a patched application is no longer de- sired, jumper J1 must be replaced. intelix... -
Page 27: Passive Mixer Linking
There are two methods of linking AMIX mixers, passive or active linking. Passive linking uses only cables, whereas active linking uses the Intelix AMIX-LINK. Passive linking is suitable for linking two mixers, whereas active linking is easier and more flexible. Using the AMIX-LINK, up to six AMIX mixers can be linked into a single stack. -
Page 28: Amix-Link Module
10.0 AMIX-LINK Module This section describes the capabilities, operation and use of the AMIX-LINK Module. The Link Module is an accessory to the Intelix AMIX-4 and AMIX-8. The Link Module attaches to the rear of the AMIX mixer chassis, dramatically extending the capability of the AMIX mixer. -
Page 29: Quick Start For Amix-Link
Using the included audio cables (they have an RCA phono plug on both ends), connect the slaves “Link Out” port to the master’s “Link In” port. Note: There should be no connection to the master’s “Link Out” ports. The only connection to the slave’s “Link In” port should be the supplied shorting plug. intelix... -
Page 30: Installation Of The Amix-Link
If you never intend to use the insert/patch functions of the AMIX mixer, leave J1 installed (as it comes from the factory). The position of J1 on the AMIX mixer board. The drawing is looking down on the mixer from behind. Remove J1 by pulling straight up. The jumper may be discarded after removal. intelix... -
Page 31: Amix-Link Connector Descriptions
Insert 10.3.4 The ReO port description The ReO port allows the user to connect an Intelix mini-mixer controller to the AMIX. The mini-mixer is a small, portable controller. This device permits all AMIX channel levels, includ- ing the master, to be adjusted from a remote location. -
Page 32: The Rs232 Port Description
The wire from the channel becomes active (high) when that channel is gated on. This +5V TTL signal may be used for any signaling or control function (i.e., LEDs, 5 Volt logic, and relays). The Gate Logic Output port pinout intelix... -
Page 33: Connecting To The Reo Port
When remote control of all channels levels is required, the ReO port can be used to connect an Intelix mini-mixer to the AMIX mixer. This is accomplished by inserting an RCRJ11 adap- tor into the ReO port of the AMIX-LINK. Then the cable provided with the mini-mixer can be connected between the adapter and the mini-mixer. -
Page 34: Connecting To The Rs232 Port
DB9 connector to the AMIX-LINK’s RJ12 connector is made through the AMIX RS232 adaptor available from Intelix. AMIX RS232 port adaptor wiring diagram. Typical connection of a laptop PC to the AMIX mixer, using the Intelix RS232 adaptor and a null modem cable. intelix... -
Page 35: Connecting To The Control Pin Port
With proper connections to the Control Pin Port, the user can remotely control volume and muting of the following channels: 2, 4, 6, 8, and the master output. If it is necessary to have individual remote control over all channels, an Intelix mini-mixer connected through the ReO port should be used. -
Page 36: Setting Internal Jumpers For The Control Pin Port
Note: While the cover is off, confirm that all channels without external remote controls have the correspond- ing jumper installed. Channels 1, 3, 5, and 7 should also have jumpers installed. Replace the cover on the mixer, securing with the ten screws. intelix... -
Page 37: Wring The Link In And Link Out Ports
Pinout for AMIX-4 Pinout for AMIX-8 The pin assignment of jumper block SK12 on the AMIX module logic board. The AMIX-4 channel pinout is shown above the connector drawing. Note: For the connection of Control Pin Port control devices, it should never be necessary to move any jumpers except Vol2, Vol4, Vol6, Vol8, and MSTR. -
Page 38: Using The Link In Port As A Balanced Link Input
This input goes directly to the summing bus and has no input volume control, thus input level control must be provided by the input device. The Link In Port is an ungrounded differential input. To correctly wire this input to the AMIX-LINK RCA port, follow the following direc- tions. intelix... -
Page 39: If Your Source Is Balanced
RCA Plug Balanced Source 10.5.2.2 If your source is unbalanced √ Tie the ground lead to the RCA connector case. √ Tie the positive signal lead to the RCA connector center pin. Unbalanced source hookup. Unbalanced RCA Plug Source intelix... -
Page 40: Troubleshooting Tips
If the hum is “in” the mixer, first check to see if the Ground Lift Jumper (J4) is present. It should be removed, unless the mixer is in a nonmetal cabinet. Check for unbalanced connections; use balanced connections, if possible. For all unbalanced connections, try to disconnect the signal line ground to “lift” the ground. intelix... -
Page 41: Technical Specifications And Line Drawings
AMIX Series Automatic Mic/Line Mixer User Manual 12.0 Technical Specifications and Line Drawings AMIX-4 Front and Rear AMIX-8 Front and Rear Specifications INPUTS GENERAL Frequency Response ±.5 dB from 20 Hz to 20 kHz Input Trim Range 40 dB +0, -3 dB from 10 Hz to 30 kHz Input Impedance 3.5 kOhms Mic / 15 kOhms Line... - Page 42 AMIX Series Automatic Mic/Line Mixer User Manual Notes intelix...
