Autopilot AP3003 gold
Navicontrol

INSTRUCTION MANUAL

FOR
USE & INSTALLATION
NAVICONTROL s.r.l.
Via dei Comparini, 39/24 - 55049 VIAREGGIO (LU) - ITALY
tel. +39 0584 384144
fax. +39 0584 384447
www.navicontrol.com
info@navicontrol.com
Instruction manual for use and installation -
page 1
rel. 1.21 / 02.08

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AP3003 gold and is the answer not in the manual?

Questions and answers

Summary of Contents for Navicontrol AP3003 gold

  • Page 1: Instruction Manual

    Autopilot AP3003 gold Navicontrol INSTRUCTION MANUAL USE & INSTALLATION NAVICONTROL s.r.l. Via dei Comparini, 39/24 - 55049 VIAREGGIO (LU) - ITALY tel. +39 0584 384144 fax. +39 0584 384447 www.navicontrol.com info@navicontrol.com Instruction manual for use and installation - page 1...
  • Page 2: Table Of Contents

    Autopilot AP3003 gold Navicontrol Contents FOREWORD ......................3 WARRANTY ......................4 THE AP3003 AUTOPILOT ................5 GOLD EEC 89/336 ........6 ECLARATION OF COMPLIANCE TO THE DIRECTIVE USER’S MANUAL ...................... 7 IMPORTANT WARNINGS ..................8 ..................9 ULTISENSOR ECHNOLOGY PRELIMINARY OPERATIONS AND START OF NAVIGATION......10 Starting .......................
  • Page 3: Foreword

    Autopilot AP3003 gold Navicontrol FOREWORD Thank you for purchasing a NAVICONTROL product and congratulations for your excellent choice. You have now become the owner of a powerful and versatile electronic instrument which will make your moments of relax or work, at sea, more pleasant and secure.
  • Page 4: Warranty

    5. Navicontrol will not accept responsibilities on its products other than those mentioned above. It is also understood that Navicontrol will in no case be considered responsible for any kind of direct or indirect damage that may occur to people, animals or things due to the use of its products.
  • Page 5: The Ap3003 Gold Autopilot

    Navicontrol THE AP3003 gold AUTOPILOT The AP3003 gold autopilot belongs to the latest generation in marine equipment where advanced research, sophisticated electronic technology and special care in quality standard, blend together so as to ensure a highly efficient, reliable, versatile and extendible product at a competitive cost.
  • Page 6: Declaration Of Compliance To The Eec 89/336 Directive

    Fabbricante: NAVICONTROL S.r.l. Manufacturer: Via dei Comparini, 39/24 55049 Viareggio (LU) Italy Prodotto: AP3003 GOLD / AP801 Eut: AP303 GOLD / AP401 AP103 GOLD / AP201 with FB30, FGX90/N, PB 80/250/350 TELECOMANDO PORTATILE RS32 TELECOMANDO REMOTO RC34 TELECOMANDO REMOTO ART35...
  • Page 7: User's Manual

    Autopilot AP3003 gold Navicontrol USER’S MANUAL Instruction manual for use and installation - page 7 rel. 1.21 / 02.08...
  • Page 8: Important Warnings

    Autopilot AP3003 gold Navicontrol IMPORTANT WARNINGS Seafaring experience is made exclusively at sea and not on land. So when you go out at sea, please do remember to take this manual with you and you will quickly learn to use the autopilot in the simplest and most logical way: actually using it.
  • Page 9: Multisensor Technology

    (FGX90, FGX60), GYRONAV rate sensor stabilizer, GPS receiver. The Multisensor Technology can be enabled in the entire Navicontrol Gold series autopilots only if: 1) the software release is 1.18 or higher 2) the Gyronav sensor is correctly installed and enabled 3) the “MULTISENSOR”...
  • Page 10: Preliminary Operations And Start Of Navigation

    Autopilot AP3003 gold Navicontrol PRELIMINARY OPERATIONS AND START OF NAVIGATION. Starting Switch on the control panel and wait until the autopilot has performed the autodiagnostic test and visualizes the software identification codes. At this stage, the system is in STANDBY so ready to be set.
  • Page 11 Autopilot AP3003 gold Navicontrol The display of the Control Unit visualizes the number of the program which is operating at that time. In some other autopilots, it is also named SEA or WEATHER and indicates the width of the channel in which the vessel navigates. The higher the value is and the higher the slack is respect to the course to be followed.
  • Page 12: Setting Of The Route And Automatic Navigation

    Autopilot AP3003 gold Navicontrol C.RUDD too low C.RUDD too high T.RATE This parameter, which corresponds to the turn rate expressed in degrees per second, restricts the quantity of rudder during the turns. The higher the value is and the faster the turns are.
  • Page 13 Autopilot AP3003 gold Navicontrol Geographical course If the system is equipped with a GPS or a chart-plotter correctly installed and interfaced with the autopilot, it is possible to change any followed magnetic course (AUTO mode) in a geographical course and any leeway or drift will be automatically corrected (AUTO-TRACK mode).
  • Page 14 Autopilot AP3003 gold Navicontrol Navigation with wind direction sensor If provided with a wind direction sensor, correctly installed and interfaced with the autopilot, it is possible to set a tack angle to be followed automatically. In fact, you only need to select the WIND mode of the autopilot by pressing the key NAV until the WIND is visualized).
  • Page 15 Autopilot AP3003 gold Navicontrol In automatic mode (AUTO) and by pressing the TURN key, it is possible to execute one of the following turns:  U TURN (180 turn)  O TURN (360 turn)  8 TURN (360 turn followed by another 360 turn in the opposite direction) The selection of the kind of turning is activated by pressing and releasing the TURN key until the desired kind is shown.
  • Page 16: Signaled Alarms

    Autopilot AP3003 gold Navicontrol  FLASHING: during the pressing of the two keys (P and S and the following seconds. Remote Control RC34, RS34 It is similar to the RS32: it differs from it for the fact that is designed to be flush-mounted and the P and S key here are replaced by a joystick.
  • Page 17: Installation Manual

    Autopilot AP3003 gold Navicontrol INSTALLATION MANUAL Instruction manual for use and installation - page 17 rel. 1.21 / 02.08...
  • Page 18: Installation Procedures

    Autopilot AP3003 gold Navicontrol INSTALLATION PROCEDURES The autopilot is powerful and sophisticated but its reliability strictly depends on a scrupulous installation and a proper configuration, of all devices and optional accessories included. For safety reasons, the best way is to section the power supply of the processor box (and so of the whole autopilot) with a switch installed in the electric panel of the vessel, only for this purpose.
  • Page 19: Processor Box Ap Gold

    Autopilot AP3003 gold Navicontrol Processor Box AP gold It is the heart and the brain of the autopilot: in fact it contains the main calculator of the system. Install it far from direct heating, continuous vibrations and shocks; places like engine-room, bilge area or other similar locations must be avoided.
  • Page 20: Electrohydraulic Unit

    FLOW-RATE (cc/min.) = RAM_VOLUME (cc.) x 5 When you use Ax or Crux Navicontrol.it pumps, you don’t need any calculation: you must choose the pump with the nearest value to the ram volume (i.e.: RAM = 100cc.  PUMP = R100 or CR100).
  • Page 21: Preliminary Test

    Autopilot AP3003 gold Navicontrol PRELIMINARY TEST. After the installation of all mechanical and electrical components of the autopilot, a first testing must be executed when still anchored or at the shipyard. In order to obtain the best performance of the system, it is necessary to carry out at least a trial at sea.
  • Page 22: Gps And/Or Chart-Plotter

    Autopilot AP3003 gold Navicontrol GPS and/or Chart-Plotter In these instruments, select the output data to NMEA0183 standard (usually is the default configuration and no manual operation is required). Insert a course on these instruments and verify that the autopilot receives correctly the bearing from them by placing it on NAV mode.
  • Page 23: Operating Parameters Pre-Set

    Autopilot AP3003 gold Navicontrol If the autocompensation failed (result = Bad), it means that the chosen location for the installation of the compass is too interfered and therefore the location must be changed. Warning: the autocompensation procedure can be interrupted by pressing STBY key or by removing the power supply to the autopilot.
  • Page 24: Software Installation Procedure

    Autopilot AP3003 gold Navicontrol SOFTWARE INSTALLATION PROCEDURE WARNING: the software installation procedure of the system is very delicate and implies a profound knowledge of its functioning. Thus, we advise you to avoid the changing of the values supplied with the default if you do not exactly know the effects.
  • Page 25 Autopilot AP3003 gold Navicontrol F5 HYDR UNIT Model of electrohydraulic unit installed: SOL (with solenoids) – REV (reversing). REV can be equal to 1, 2 and 3 respectively with correct units, fast units and very fast units. F6 ENERG SAVE...
  • Page 26 Autopilot AP3003 gold Navicontrol F16 INFO DISPL It selects the data on the info-display: SOG (speed over ground, received by the GPS), COG (course over ground, received by the GPS) or COMP (compass reading). F17 RC FUNCT Action of the remote controls (RS32, RC34, RS34 and ART35). The values...
  • Page 27: Technical Specification

    Autopilot AP3003 gold Navicontrol TECHNICAL SPECIFICATION Operating specifications. Supply voltage 12 - 24 Vdc (-15% / + 30%) 4W (min) 8W (max) Power consumption (electronic parts only) Maximum solenoids load 4A (each one) Maximum hydraulic unit load (“CR” type) 25A @ 12V, 20A @ 24V 80 ...
  • Page 29 Autopilot AP3003 gold Navicontrol ALARMS SIGNALING MEANING POSSIBLE CAUSES REMEDY : (two dots between the numbers of the Interfered magnetic compass. Magnetic interference nearby the compass sensor. Remove the interference. course) Relevant magnetic interference nearby the compass sensor or Remove the interference.
