Masterclock shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
Input Connections Connect the TC to the Input BNC connector or the appropriate pins on the DB-9 on the rear of the TCA100. The input is balanced, isolated from chassis ground and has an input impedance of > 100K ohm.
I/O is routed simultaneously to Channel 1 and Channel 2 BNC connectors and pins on the DB-9 connector. To simultaneously use some combination of DB-9 I/O, a custom I/O cable would be necessary. Such cables can be fabricated locally by a competent electronic technician or, on a custom basis, by Masterclock. TCA100 -01/19/10...
ACCESS TO PC BOARD In order to gain access to the pin jumpers it is necessary to remove the case from the TCA100 as follows: First disconnect the power and other cables from the unit. Even though the highest voltage inside the TCA100 is 12 VDC (which is generally not dangerous to touch), accidentally shorting a trace or wire inside the unit with power on could destroy or damage any one of the extremely sensitive electronic components.
PROBLEMS - TROUBLE SHOOTING All TCA100 units are checked for proper operation before shipment and unless physical damage is found, the unit is probably functional. If you have problems in getting the unit to work: • double check all input and output connections •...
OPTIONS RACK MOUNT – RM4 The RM-4 is a standard 19” wide, 1RU kit for mounting up to four Masterclock stand-alone units. TCA100 -01/19/10 (C) Masterclock, Inc.
Masterclock will, at its option, either repair or replace products which prove to be defective. Should Masterclock be unable to repair or replace the product within a reasonable amount of time, the customer's alternate remedy shall be a refund of the purchase price upon return of the product to Masterclock.
