  • Page 1 Speedsolar Solarcollector Deluxe OWNER’S MANUAL Solar Collector DELUXE 2011_V2 page 1 of 11...
  • Page 2 Speedsolar Solarcollector Deluxe Basic safety precautions are always observed. Errors caused by not following the instructions below could result in serious injury or serious accidents. CAUTION Read all instructions before assembling and using this product. Failure to follow instructions can cause severe and/or fatal injury.
  • Page 3: Table Of Contents

    Speedsolar Solarcollector Deluxe Table of Contents: Safety Warnings ............................4 General Information ............................4 2.1.1 Requirements for the installation of a solar collector ................. 4 2.1.2 How It Works ............................. 4 2.1.3 Unpacking Your Solar Collector ......................4 2.1.4 Tools & Equipment Required ......................4 2.1.5 Know Your Pool ..........................
  • Page 4: Safety Warnings

    Speedsolar Solarcollector Deluxe 1 Safety Warnings Read all instructions BEFORE assembling and using this product. Caution: Failure to follow instructions can cause severe and/or fatal injury.  Carefully read this manual and all CAUTION and NOTE notices located throughout this manual. ...
  • Page 5: Solar Collector Location

    Speedsolar Solarcollector Deluxe 2.1.6 Solar Collector Location Your solar collector needs a place with maximum possible sunlight.  You will need to position the collector lower than the pool’s water level.  There has to be a safe distance away from the pool (safety distance). ...
  • Page 6: Technical Data

    Speedsolar Solarcollector Deluxe Do NOT allow standing water inside the solar collector to freeze. Water expands as it freezes and can rupture the solar coils on the heater. 3 Technical Data 3.1.1 Technical Data  Dimensions: L 780mm x W 780mm x H 420mm ...
  • Page 7: Parts List/Reference

    Speedsolar Solarcollector Deluxe 4 Parts List/Reference 4.1.1 Primary Components 2 x HOSE REDUCER 38/32 mm 1x MAIN BASE WITH STAND 2 x HOSE CLAMP 1 x INTEX SPECIAL ADAPTER WITH O-RING Only used, if you connect the solar collector to an INTEX- Pool with a filter pump power starting from 5.700 l/h.
  • Page 8 Speedsolar Solarcollector Deluxe When put the product out, at the bottom there have one con- nector which is not screwed. Put the connector at the correct location and use plastic part and screws to fix it. After you fix the connector, please continue with the next steps.
  • Page 9 Speedsolar Solarcollector Deluxe 1) Collector - Filter Pump Connection a) Turn off filter pump. b) Block water flow at both the pool return inlet and the filter pump outlet to prevent water from flowing through the hoses. c) Detach the pool return hose from your filter system and set aside. d) Locate the inlet connector and the long filter hose.
  • Page 10: Initial Operation

     Consumable parts are not covered by warranty! 8 Service Processing For technical information, missing parts or in the case of a complaint, please contact our customer service: Steinbach VertriebsgmbH Aistingerstrasse 2 4311 Schwertberg Tel. Austria: (0820) 200 100 103 (0,145€ per minute from all networks) Tel.
  • Page 11 Speedsolar Solarcollector Deluxe 2011_V2 page 11 of 11...
