Summary of Contents for EchoLife ET655
- Page 1 EchoLife ET655 IP Phone User Manual HUAWEI TECHNOLOGIES CO., LTD.
- Page 2 EchoLife ET655 IP Phone V100R001C01LENT02 User Manual Issue Date 2012-02-08...
- Page 3 Huawei Technologies Co., Ltd. provides customers with comprehensive technical support and service. Please feel free to contact our local office or company headquarters. Huawei Technologies Co., Ltd. Address: Huawei Industrial Base Bantian, Longgang Shenzhen 518129 People's Republic of China Phone:...
- Page 4 Copyright © Huawei Technologies Co., Ltd. 2011. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. Trademarks and Permissions and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
-
Page 5: Table Of Contents
Features ........................6 Hardware specifications.................... 7 Technical specifications.................... 8 3 Installing the ET655 .................10 Cable Connections of the ET655 ................10 Starting the ET655 ....................11 Safety Compliance ....................11 Warranty of Quality ....................12 4 Configuring the ET655 ................13 Configuring the Phone Through the Keypad ............ - Page 6 EchoLife ET655 IP Phone User Manual Contents Handset, Speakerphone, and Headset Modes ..........24 Multiple SIP Accounts and Lines..............25 Making a Call ....................25 Answering a Call ................... 27 Do-Not-Disturb ..................... 27 Call Waiting/Call Holding ................27 Muting ......................27 Call Transfer ....................
- Page 7 EchoLife ET655 IP Phone User Manual 1 Safety Precautions EchoLife ET655 IP Phone User Manual Thank you for purchasing the EchoLife ET655 IP Phone (the ET655 for short). ET655 is an high-quality IP phone.
-
Page 8: Safety Precautions
Without prior written consent, no organization or individual is permitted to make any change to the structure or safety design of the device. Huawei Technologies Co., Ltd. is not liable to any consequences or legal issues due to such changes. -
Page 9: Operating Requirements
EchoLife ET655 IP Phone User Manual 1 Safety Precautions Operating Requirements: Do not let a child operate the device without guidance. Do not let a child play with the device or any accessory. Swallowing the accessories may lead to peril. -
Page 10: Cleaning Requirements
EchoLife ET655 IP Phone User Manual 1 Safety Precautions Cleaning Requirements: Before cleaning the device, stop using it and disconnect it from the power supply. Use a piece of soft dry cloth to clean the device. Keep the power plug clean and dry. Using a dirty or wet power plug may lead to... -
Page 11: Product Overview
EchoLife ET655 IP Phone User Manual 2 Product Overview Product Overview Packing List The following items are included in the ET655 package. Verify the packing items. Contact your distributor immediately if any one is missing. Table 2-1 Packing items Item... -
Page 12: Features
IP phone. The ET655 provides rich functions, is easy to use, and supports integrated PoE and HD Voice. Features Table 2-2 Key features of the ET655 Feature Description Open standard compatibility SIP 2.0, TCP/IP/UDP, RTP/RTC, HTTP/HTTPS, ARP/RARP, ICMP, DNS (A record and SRV record), DHCP, PPPoE, TFTP, NTP and Telnet. -
Page 13: Hardware Specifications
EchoLife ET655 IP Phone User Manual 2 Product Overview Feature Description Advanced features Customized ring tones Download of ring tones Download of address book in xml format and screensaver files SRTP voice call encrypted with the Advanced ... -
Page 14: Technical Specifications
EchoLife ET655 IP Phone User Manual 2 Product Overview Technical specifications Table 2-4 Technical specifications of the ET655 Item Specification Lines Four straight-through lines. Supported protocol Supporting the SIP 2.0, TCP/UDP/IP, HTTP, HTTPS, PPPoE, RTP/RTCP, SRTP by SDES, HTTP, ARP/RARP,... - Page 15 EchoLife ET655 IP Phone User Manual 2 Product Overview Item Specification Telephony features Intuitive GUI, download of the phone book (XML), voice mail indicator, download of custom ring tones Call holding, call transferring (consultation/blind), Do-Not-Disturb, call forwarding, call waiting, call waiting...
-
Page 16: Installing The Et655
EchoLife ET655 IP Phone User Manual 3 Installing the ET655 Installing the ET655 Cable Connections of the ET655 Figure 3-1 Connecting the ET655... -
Page 17: Starting The Et655
RJ-9 port. If you want to use the headset for communication, install the headset socket to the port. Starting the ET655 After the ET655 is powered on, a progress bar is displayed on its screen. This progress bar disappears after the startup page is accessed. Safety Compliance... -
Page 18: Warranty Of Quality
3 Installing the ET655 Warranty of Quality If you purchased the ET655 from a distributor, contact the distributor for replacement, repair, or refund. If you purchased the product directly from Huawei, contact Huawei sales and service representatives for a return materials authorization (RMA) number before you return the product. -
Page 19: Configuring The Et655
EchoLife ET655 IP Phone User Manual 4 Configuring the ET655 Configuring the ET655 Configuring the Phone Through the Keypad To enter the configuration menu, press MENU. View the menu by pressing UP, DOWN, LEFT, or RIGHT. Press MENU to confirm the selection of a menu item, and delete an entry by pressing BackSpace. - Page 20 EchoLife ET655 IP Phone User Manual 4 Configuring the ET655 Menu Configuration Description Preference Displays the preference submenus of a user. [Do Not Disturb] Choose this menu to enable or disable the DND function. [Ring Tone] Choose this menu to set different ring tones.
- Page 21 EchoLife ET655 IP Phone User Manual 4 Configuring the ET655 Menu Configuration Description Config Display the configuration submenus. [SIP] Set the SIP server for each account, including account, SIP proxy, Outbound proxy, SIP user ID, SIP Auth ID, SIP password, SIP transport, and Audio CODECs.
-
Page 22: Configuring The Phone Through Web Browser
4 Configuring the ET655 Configuring the Phone Through Web Browser The Web server embedded in the ET655 responds to the HTTP, HTTPS GET, or POST requests. Embedded HTML pages allow a user to configure the IP phone through any Web browser such as Microsoft Internet Explorer or Mozilla Firefox. -
Page 23: Configuration Page
EchoLife ET655 IP Phone User Manual 4 Configuring the ET655 Figure 4-1 Login page Configuration Page This section describes the options of Status and Basic Settings on the Web configuration page. The functions available for the end user are as follows: ... - Page 24 System Up Time The power-on duration since the last reboot. System Time The current time of the system. Registered Whether accounts are registered on the related SIP server(s). The ET655 supports four unique SIP accounts.
- Page 25 EchoLife ET655 IP Phone User Manual 4 Configuring the ET655 Field Description PPPoE Link Up Whether the PPPoE connection is enabled when the phone is connected to a DSL modem. Figure 4-3 Basic setting page Table 4-3 Description of the basic setting page...
- Page 26 Flash memory. The ET655 acquires its IP address from the first DHCP server that the ET655 detects on its LAN. To use the PPPoE feature, set the PPPoE account. The ET655 establishes a PPPoE session if any of the PPPoE fields are set.
- Page 27 EchoLife ET655 IP Phone User Manual 4 Configuring the ET655 Field Description Time Zone This parameter controls the date and time display according to the specified time zone. If the DHCP Option 2 is enabled, the DHCP server overrides and centrally controls the setting of Time Zone in the phone.
-
Page 28: Saving The Configuration Changes
If you want to change an item after submitting the setting, click a tab to access the configuration page. Then click Reboot to reboot the phone, and all the changes take effect. Rebooting the ET655 Remotely Click Reboot in the configuration menu to reboot the ET655 remotely. Wait 60 seconds to log in again. -
Page 29: Using The Et655
EchoLife ET655 IP Phone User Manual 5 Using the ET655 Using the ET655 Getting to Know the Keyboard Figure 5-1 Getting to know the keypad Table 5-1 ET655 keypad Description LINE1x Four line keys with dual-color LED indicator lights. ... -
Page 30: Instructions Of Using The Phone
EchoLife ET655 IP Phone User Manual 5 Using the ET655 Description HOLD Hold the current call, and press the corresponding LINE key to resume the call. Press the key to enter the hands-free mode. Press it again to exit the hands-free mode. -
Page 31: Multiple Sip Accounts And Lines
SPEAKER, that is, Multiple SIP Accounts and Lines The ET655 supports four independent SIP accounts. Each SIP account matches with a SIP server, users, and NAT. Each of the four line keys matches with one SIP account. In off-hook state, when you press the corresponding LINE key or continuously press the same LINE key, the phone will switch among the four accounts. - Page 32 EchoLife ET655 IP Phone User Manual 5 Using the ET655 You can press the LINEx key again to switch the four accounts between each other. For example, press the LINE1 key to use the account1, press the LINE1 key again to change it to the account2（The setting of LINE1 and LINE2 are the same）.
-
Page 33: Answering A Call
(discontinuous tone) is displayed. Muting To enable or disable the muting function during a call, press MUTE. Then "LINEx: MUTE" is displayed on the LCD for the muted call. Call Transfer The ET655 supports both blind and attended (or supervised) transfer: Blind transfer:... - Page 34 If the call is canceled and terminated before the call of the third party is connected, the ET655 rings, indicating that a call is held. To transfer calls across different SIP domains, the VoIP service providers must support this feature.
-
Page 35: Three-Way Conference Call
EchoLife ET655 IP Phone User Manual 5 Using the ET655 Three-Way Conference Call ET655 can host conference calls and support three-way conference calls. Initiating a Conference Call Step 1 Pick up the handset, press , or enable the headset by pressing HEADSET to establish a call. -
Page 36: Manager And Secretary Function
If two secretaries serve a manager, only one secretary answers the call and transfers it to the manager. BLF Function After the BLF function is enabled for ET655, you can press the corresponding DSS... - Page 37 For details on how to configure the BLF service, see the ET635&ET655&ET685 Administrator Guide or contact the administrator. A user assigns the BLF function to a DSS key on phone A, and configures phone B as the monitored phone.
-
Page 38: Restoring Factory Default Settings
Restoring Factory Default Settings Restoring the factory default settings can clear all configuration information about the ET655. Back up or print all the settings before you restore factory default settings. Huawei is not responsible for parameter loss or failier to connect to your VoIP service provider due to the operation of restoring the factory default settings. -
Page 39: Faqs
7 FAQs FAQs Question: What codecs are supported by the ET655? Answer:The ET655 supports a wide range of codecs: G711 a/µ , G729, G723.1, G726-32k, G722 (broadband), GSM, and iLBC. Question: How many VoIP accounts are supported on the ET655? Answer:The ET655 IP phone supports four different SIP (VoIP) accounts. - Page 40 HUAWEI TECHNOLOGIES CO., LTD. Huawei Industrial Base Bantian, Longgang Shenzhen 518129 People's Republic of China www.huawei.com...
