System Description
Ascom IP-DECT System
2

Ascom IP-DECT System Overview

The Ascom IP-DECT system is modular. It is designed for small installations as well as large
multi-site installations with remote offices.
The Ascom IP-DECT system is built up by the following components:
• Portable Devices
• IP-DECT Base Station (IPBS)
• IP-DECT Gateway (IPBL)
• Radio Fixed Part (RFP)
• IP-PBX
• Integrated Message Server (IMS2/UPAC)
• Unite System
PSTN
(Public Switched Telephone Network)
Unite
platform
Figure 1. Ascom IP-DECT System Overview
2.1

System Size

The Ascom IP-DECT system is very modular and scalable. Systems for more than 100 000
users can be built.
2.2

System Components

2.2.1 Portable Devices
The Ascom IP-DECT system has support for all Ascom DECT Portable Devices. No changes
of the Portable Device is needed.
5 Mars 2010 / Ver. H
IMS2 / UPAC
IPBS
IP-PBX
RFP
IPBL
LAN
IPBL
IPBS
TD 92375GB
RFP RFP
RFP RFP
3
