QuietPower 1800 (QP-1800)
DC to AC Power Inverter
Document 287.F701 / 100412 / Rev 12 APR 2010
Supersedes Document 287.F701 / 070901 / Rev 01 SEP 07
Iris Technology Corporation
PO Box 5838, Irvine, CA 92616-5838
949.975.8410 tel / 949.975.8498 fax
Toll free 866.240.9540 / www.iristechnology.com
TM 11460A-OR/1 A
Operator's Manual
Operator's Manual
[CAGE 78535]
APRIL 2010
PCN 500 114600 00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QuietPower 1800 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IRIS QuietPower 1800

Summary of Contents for IRIS QuietPower 1800

  • Page 1 TM 11460A-OR/1 A QuietPower 1800 (QP-1800) DC to AC Power Inverter Operator’s Manual Operator’s Manual Iris Technology Corporation [CAGE 78535] PO Box 5838, Irvine, CA 92616-5838 949.975.8410 tel / 949.975.8498 fax Toll free 866.240.9540 / www.iristechnology.com Document 287.F701 / 100412 / Rev 12 APR 2010 Supersedes Document 287.F701 / 070901 / Rev 01 SEP 07...
  • Page 2 This permission includes but is not limited to posting on U.S. Government websites. This document is subject to periodic revision and the user is encouraged to check the Iris Technology website (www.iristechnology.com) for the most current version of this document.

  • Page 3: Table Of Contents

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 ABLE OF ONTENTS ............................3 ABLE OF ONTENTS ..............................5 PPENDICES ............................... 5 IST OF IGURES ..............................5 IST OF ABLES ..........................6 YMBOLS AND ONVENTIONS ..................7 PECIFIC...
  • Page 4 Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 ECTION TEST AND ROUBLESHOOTING ................................. 34 GENERAL ................................34 TESTING ............................35 TROUBLESHOOTING 4.3.1 ........................ 35 FAULT CONDITIONS AND INDICATORS 4.3.2 ..........................36 TROUBLESHOOTING TIPS ECTION REVENTATIVE AINTENANCE ................................. 37 GENERAL ............................

  • Page 5: Appendices

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 PPENDIX EHICLE ONSIDERATIONS ............................48 VEHICLE ALTERNATOR ............................48 MILITARY BATTERIES ............................50 LOAD AND RUNTIME PPENDIX TECHNICAL DDENDUM -1800 ............51 PERFORMANCE WITH VEHICLE AND ENVIRONMENTAL FACTORS B.1.1 ..................

  • Page 6: Symbols And Conventions

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 Symbols and Conventions The following conventions are used in this manual to communicate hazards to the operator, device or associated equipment that may occur with improper installing, operating, maintaining and servicing this equipment. These symbols are also used to make the operator aware of the inherent and potential hazards associated with this type of equipment.

  • Page 7: Specific Warnings And Hazards Of This Device

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 Specific Warnings and Hazards of this Device The following are specific warning, cautions and hazards related to the installation, use, maintenance and service of this device. WARNING FIRE AND SHOCK HAZARD.
  • Page 8 Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 WARNING MAKE SURE INVERTER IS ELECTRICALLY DISCONNECTED FROM 24 VDC POWER SOURCE (NATO PLUG) PRIOR TO SERVICING. FAILURE TO DISCONNECT INVERTER FROM 24 VDC POWER SOURCE (NATO PLUG) FIRST MAY RESULT IN FIRE, SEVERE ELECTRIC SHOCK, OR DEATH.
  • Page 9 Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 CAUTION Do not disassemble the QuietPower inverter. Only qualified electronics maintenance technicians are permitted to replace the fuse. Attempts to service the inverter by unqualified personnel may result in a risk of electric shock or fire.

  • Page 10: General Safety Precautions

    Overheating may result.  Do not use attachments not recommended or sold by Iris Technology. Doing so may result in a risk of fire, electric shock, or injury to persons.  The QuietPower Inverter is designed to connect to a military vehicle 24 VDC power system through an available and/or supplied NATO Cable.

  • Page 11: Explosive Gas Precautions

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 Explosive Gas Precautions  This equipment contains components which can produce arcs or sparks. prevent fire or explosion do not install in compartments containing batteries or flammable materials or in locations which require ignition protected equipment. This includes any space containing gasoline-powered machinery, fuel tanks, or joints, fittings, or other connection between components of the fuel system.

  • Page 12: Fcc Information

    Department of Defense Product Evaluation This equipment has been tested extensively by the Department of Defense (DoD) and is approved and recommended for use in wheeled military vehicles. Contact Iris Technology for details about obtaining a copy of these data (Restricted Distribution, FOUO).

  • Page 13: Introduction

    Introduction Introduction Thank you for your purchase of the QuietPower 1800 Inverter. As a high quality, true sine wave output inverter, you can expect the QuietPower Inverter to deliver exceptional performance and give you years of dependable operation. The true sine wave AC output from the QuietPower Inverter ensures all AC loads operating from the unit perform efficiently and correctly.

  • Page 14: Equipment Identification And Description

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 Equipment Identification and Description Table 1 lists the QuietPower systems and components that can be ordered. The parts you receive depend on the part number ordered. Three different systems can be ordered, as well as individual components.
  • Page 15 Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 Iris PN / NSN Image Description / Components QP-1800 Operator‟s Manual 287F701 TM 11460A-OR/1 A PCN 500 114600 00 Installation Kit Replacement Fuse (1) 287A109 Battery Terminal Covers (2)

  • Page 16: Inverter Key Features

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 Inverter Key Features The QuietPower Inverter utilizes advanced high frequency switching technology in the power conversion process. The circuits are similar to those used in power supplies for computers and other electronic equipment.

  • Page 17: Figure 1: Front Panel Of The Qp-1800

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 Duplex (AC) Outlet Display Control GFCI Panel (Ground Fault Circuit Interrupter) Off/On Circuit (O/I) Breaker Figure 1: Front Panel of the QP-1800 Serial Number Ground Isolators (4) (Not Shown)

  • Page 18: Installation

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 Section 2 Installation CAUTION Review the Important Safety Instructions found at the beginning of this manual and read this entire section, paying particular attention to the CAUTION and WARNING statements, before proceeding with the installation.

  • Page 19: Locating The Inverter

    Refer to paragraph 2.6, Wiring the Inverter, for more information. Before turning the inverter on, refer to Section 3, Operation. Iris Technology makes available a vehicle mounting plate for use with the Expanded-Capacity HMMWV Fleet or HMMWV (ECV) which have Air Conditioning installed (PN 287A125). This plate allows for direct bolt-on attachment without vehicle modification.
  • Page 20 Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412  Safe: DO NOT install the QuietPower Inverter in the same compartment as batteries or in any compartment capable of storing flammable liquids such as gasoline. DO NOT install the QuietPower Inverter in an engine compartment or other location where ignition protected equipment is required.

  • Page 21: Mounting The Inverter

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 Mounting the Inverter Before mounting the QuietPower Inverter, test the chosen location for adequate space around the unit to allow for connections and ventilation. Mounting hardware should be corrosion resistant ¼”...

  • Page 22: Control Panel Orientation

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 2.5.1 Control Panel Orientation The QuietPower QP-1800 control panel can be detached and reoriented to facilitate accessing the panel in various mounting positions. Remove and re-attach the control panel depending on the orientation of the base unit itself.
  • Page 23 Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 WARNING BEFORE MAKING CONNECTIONS, ROUTE THE POSITIVE AND NEGATIVE BATTERY WIRES DIRECTLY TO THE DC CONNECTION TERMINALS ON THE QUIETPOWER INVERTER FIRST. Before making connections, route the positive and negative battery wires directly to the DC connection terminals on the QuietPower Inverter.

  • Page 24: Dc Grounding (On-Vehicle)

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 2.6.2 DC Grounding (On-Vehicle) The QuietPower Inverter has a lug on the rear panel labeled Chassis Ground. This lug is used to connect the chassis of the QuietPower Inverter to your DC ground as required for safety.

  • Page 25: Section Operation

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 Section 3 Operation General This section details how the unit functions as an inverter, provides information on the control panel, describes operating limits, and provides performance data and system specifications.

  • Page 26: Control Panel

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 There are many advantages of true sine wave over other waveforms delivered by other inverters:  AC powered equipment is designed to operate with true sine wave. Many loads will perform better when connected to the QuietPower Inverter.

  • Page 27: To Operate The Quietpower Inverter

    2.5 seconds. Full output power is available with the detection of a load. The unit will remain in POWERSAVE mode if the load it detects is less than 10W for the QuietPower 1000 and less than 20W for the QuietPower 1800. This is a factory set search mode setting and cannot be changed.

  • Page 28: Inverter Operating Limits And Protection Features

    QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 Inverter Operating Limits and Protection Features Power Output: The QuietPower 1800 delivers 1800 watts continuously. Table 2 displays the continuous and peak current ratings as well as surge rating. Table 2: Operating Limitations...
  • Page 29 Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 WARNING DO NOT DISASSEMBLE THE QUIETPOWER INVERTER. ONLY QUALIFIED ELECTRONICS MAINTENANCE TECHNICIANS PERMITTED TO REPLACE THE FUSE. ATTEMPTS TO SERVICE THE INVERTER BY UNQUALIFIED PERSONNEL MAY RESULT IN A RISK OF ELECTRIC SHOCK OR FIRE.

  • Page 30: Performance Graphs And Specifications

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 Performance Graphs and Specifications 3.7.1. Power Derating Curve As with all inverters, the amount of continuous power that the QuietPower Inverters can deliver without overheating is limited by ambient (surrounding air) temperature.

  • Page 31: Efficiency Curve

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 3.7.2 Efficiency Curve The efficiency rating of the QuietPower Inverter indicates what percentage of DC power is converted to usable AC power at given power output levels. The higher the rating, the less power is lost in the way of heat from the inverting process.

  • Page 32: Technical Specifications

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 3.7.3 Technical Specifications Table 4 provides equipment specifications for the QuietPower 1800 Inverter system. Table 4:Technical Specifications Parameter Characteristic Continuous Power 1800 W Surge Power 2900 W Peak Efficiency...

  • Page 33: Usage Guidelines For The Qp-1800

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 3.8 Usage Guidelines for the QP-1800 When using the QP-1800 in vehicle installations, it is important to understand that the vehicle battery holds a limited amount of power from which the QP-1800 inverter draws to supply voltage.

  • Page 34: Test And Troubleshooting

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 Section 4 Test and Troubleshooting General This section provides testing and troubleshooting instructions for the QuietPower Inverter. CAUTION Do not disassemble the QuietPower inverter. Only qualified electronics maintenance technicians are permitted to replace the fuse. Attempts to service the inverter by unqualified personnel may result in a risk of electric shock or fire.

  • Page 35: Troubleshooting

    ‘O’ and then to PS_FAULT SHUTDOWN Overload or system hardware fault ‘I’. If unit still does not operate, contact Iris DC-DC SHUTDOWN Technology for service warranty replacement. Turn system off, remove load, reset circuit...

  • Page 36: Troubleshooting Tips

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 4.3.2 Troubleshooting Tips Table 6 provides some troubleshooting tips. Table 6: Troubleshooting Tips Problem and symptoms Possible Cause Solution Refer unit to qualified electronics Dust or other foreign matter in unit or...

  • Page 37: Preventative Maintenance

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 Section 5 Preventative Maintenance General This section provides the procedures to inspect and clean the QuietPower Inverter (externally), replace the NATO Cable, store the inverter, and prepare the inverter for shipment.

  • Page 38: Cleaning

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 5.2.2 Cleaning The QuietPower Inverter contains sophisticated internal electronic circuits that can be damaged if debris or foreign matter enters the inverter casing. Clean the QuietPower Inverter and NATO Cable in accordance with Table 8.

  • Page 39: Nato Cable Replacement

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 NATO Cable Replacement The following paragraphs detail the procedure to replace the NATO Cable for connection to the inverter and the vehicle. 5.3.1 NATO Cable Removal Remove the NATO Cable from the inverter and the vehicle as follows:...

  • Page 40: 5.3.2 Nato Cable Installation

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 5.3.2 NATO Cable Installation WARNING MAKE SURE INVERTER IS ELECTRICALLY DISCONNECTED FROM 24 VDC POWER SOURCE (NATO PLUG) PRIOR TO SERVICING. FAILURE TO DISCONNECT INVERTER FROM 24 VDC POWER SOURCE (NATO PLUG) FIRST MAY RESULT IN FIRE, SEVERE ELECTRIC SHOCK, OR DEATH.

  • Page 41: Storage

    Approved shipping methods are as follows:  Save the original packaging material. The inverter shall be shipped back to Iris Technology for repair and the preferred method of shipping is to use the same packaging material that was used when first shipped from the factory.

  • Page 42: Corrective Maintenance

    Perform Inspection (External) procedure. Remove 14 screws attaching the outer housing. Check inverter for displaced components indicating If any components are displaced, contact Iris Technology for signs of mechanical failure. repair and/or replacement. Check inverter for debris buildup. Perform Cleaning (Internal) procedure.

  • Page 43: Cleaning

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 6.2.2 Cleaning The QuietPower Inverter contains sophisticated internal electronic circuits that can be damaged if debris or foreign matter enters the inverter casing. Clean the QuietPower Inverter and NATO Cable in accordance with Table 10.

  • Page 44: Fuse Replacement

    Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 Fuse Replacement The following paragraphs detail the procedure to replace the MEG125 internal fuse (Iris PN 287.0128 / Littlefuse Mega 125 [125 A]). WARNING MAKE SURE INVERTER IS ELECTRICALLY DISCONNECTED FROM 24 VDC POWER SOURCE (NATO PLUG) PRIOR TO SERVICING.

  • Page 45: Fuse Installation

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 Figure 11: Inverter Cover Removal Blow out dust from inverter using a compressed air duster. 10. Using an ohmmeter, measure the resistance of the installed fuse and determine whether it has blown. A good fuse should measure as a short circuit.

  • Page 46: Warranty And Service

    Proof of purchase is required for warranty service. During the warranty period, Iris Technology will, at its option, repair or replace the defective product free of charge. This warranty will be considered void if the unit has suffered any physical damage or alteration, either internally or externally, and does not cover damage arising from improper use or from use in an unsuitable environment.

  • Page 47: Warranty Service

    QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 Warranty Service If your QuietPower Inverter requires service, please return it to Iris Technology directly. Contact Iris before returning your unit to obtain an RMA number and to verify shipping information. Updated warranty service...

  • Page 48: Vehicle Considerations

    This appendix explains important vehicle and battery systems information necessary to optimize the performance of the QP-1800 inverter system. The QuietPower 1800 is a 24 VDC (nominal) device. It will not operate from personal vehicles which have a 12 VDC (nominal) electrical system.

  • Page 49: Table 11: Comparison Of Military Battery Specificaitons

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 Two batteries are commonly used in military vehicle applications, the 6T/6TMF Series and the Hawker Armasafe Plus. Table 11 compares the performance of these two batteries. As seen below, the Armasafe Plus exceeds all military specifications and offers significant performance benefits in CCA, capacity, reserve, shelf life, cycle life, and internal resistance.

  • Page 50: Load And Runtime

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 Load and Runtime The user must understand two key concepts relating to equipment load and runtime. First, the total load must never exceed the temperature derated capacity of the QP-1800 (see Figure 9).

  • Page 51: Technical Addendum

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 Appendix B TECHNICAL ADDENDUM This technical addendum has been prepared to address concerns raised in regards to degraded inverter performance specifically: shortened runtime - in the field. Root cause investigation has revealed that in cases where the inverter malfunction is not the cause, vehicle condition and environmental factors can severely affect the function and performance of the inverter.

  • Page 52: B.1.2 Age And Condition Of The Vehicle Battery

    (GFCI) discussed next. Operation with Downstream EMC Components The QuietPower 1800 is delivered with a Ground Fault Circuit Interrupter (GFCI) type duplex outlet. Occasionally, when operated with certain types of electronics, the GFCI would trip for no apparent reason. The following discussion provided a basic understanding of the operational issues.

  • Page 53: Frequenty Asked Questions ( Faqs )

    We have verified the operation of the QuietPower 1800 for compatibility with the PAC-216/U and VB-90 adapters for SINCGARS, the PAC-24V adapter for the Falcon series, the StarPower...

  • Page 54: Figure 14: Energy Flow

    Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 Energy Flow The only energy source put into your military vehicle enters in the A fraction of this electrical energy is stored in the batteries for form of diesel fuel...
  • Page 55 Iris Technology Operator's Manual QuietPower 1800 (QP-1800) Doc 287.F701 / 100412 Notes Appendix A Page 55 of 56 Rev 12 APR 2010...
